1
Engine
911
911 GT3 RS
General
The engine of the 911 GT3 is used in the 911 GT3 RS in model year 2004.
The geometry of the inlet ports in the cylinder head have been optimised.
This resulted in a new engine type, which for this vehicle is designated M79/80.
Additional information is available in the existing Technical Service Information
brochures and in the Corporate Porsche Academy.
1.5 / 2004
