Infinitybox inMOTION NGX Installation Manual

Door control module kit

Table of Contents

Quick Links

Download this manual

Infinitybox inMOTION NGX Door Control Module Kit

Warnings ....................................................................................................................................................... 2

Introduction .................................................................................................................................................. 3

inMOTION NGX- J1939 Door Control Module Technical Details .................................................................. 4

Contents of inMOTION NGX Kit .................................................................................................................... 5

inMOTION NGX Connector & Harness Details .............................................................................................. 6

Installation Steps: .......................................................................................................................................... 8

STEP 1: Mounting the inMOTION NGX Cells ............................................................................................. 9

STEP 2: Running Power and Ground ....................................................................................................... 11

STEP 3: Connecting the CAN Cables ........................................................................................................ 12

STEP 4: Wiring the inMOTION NGX Outputs........................................................................................... 15

STEP 5: Wiring the Switches .................................................................................................................... 17

Warranty Information ................................................................................................................................. 19

Contact Information .................................................................................................................................... 20

Revision 25031701

Installation Manual

INFINITYBOX, LLC

6460 West Cortland Street

Chicago, Illinois 60707

www.infinitybox.com

Table of Contents

Need help?

Do you have a question about the inMOTION NGX and is the answer not in the manual?

Questions and answers

Summary of Contents for Infinitybox inMOTION NGX

Page 1: Table Of Contents
Installation Manual Table of Contents Warnings ............................... 2 Introduction ..............................3 inMOTION NGX- J1939 Door Control Module Technical Details ..............4 Contents of inMOTION NGX Kit ........................5 inMOTION NGX Connector & Harness Details ....................6 Installation Steps: ............................8 STEP 1: Mounting the inMOTION NGX Cells .....................
Page 2: Warnings
INFINITYBOX, LLC 6460 West Cortland Street Chicago, Illinois 60707 www.infinitybox.com Warnings INFINITYBOX MOTION NGX K IT IS AN ADVANCED ELECTRICAL POWER MODULE ROPER CARE MUST BE TAKEN TO FUSE THE INPUT FEEDS TO THE MODULE MPROPER FUSE SELECTION CAN CAUSE DAMAGE TO THE VEHICLE ELECTRICAL SYSTEM RESULTING IN FIRE...
Page 3: Introduction
You can easily scale the number of inMOTION NGX modules that you need in your car or truck project. You can easily add two or 4 inMOTION NGX modules depending on the number of doors you have.
Page 4: Inmotion Ngx- J1939 Door Control Module Technical Details
INFINITYBOX, LLC 6460 West Cortland Street Chicago, Illinois 60707 www.infinitybox.com inMOTION NGX- J1939 Door Control Module Technical Details Number of Outputs: • Two H-Bridge Pairs for Polarity Control Four High-Side Switched MOSFET Outputs Current Carrying Capability • H-Bridge Pairs 15-Amp intermittent use (10% duty cycle) ...
Page 5: Contents Of Inmotion Ngx Kit
Chicago, Illinois 60707 www.infinitybox.com Contents of inMOTION NGX Kit Component Quantity Part Number J1939 inMOTION NGX Module 852-086A8 inMOTION NGX Power & Output Harness 858-501 inMOTION NGX CAN & Input Harness 858-502 4-Position ATO Holder 904-001 15-AMP ATO Fuse 904-420 14-16 AWG ¼”...
Page 6: Inmotion Ngx Connector & Harness Details
The inMOTION NGX module has two sealed Deutch/TE connectors and harnesses. These wires connect the inMOTION NGX to the rest of your Infinitybox J1939 network. They bring power and ground to the module plus connect the switches and outputs. The following picture identifies these two connectors on the inMOTION NGX module.
Page 7 The following table shows the cavity ID, the wire color and the function for each of the wires in the Power and Output harness. The Infinitybox part number for this harness is 858-501. The following table shows the cavity ID, the wire color and the function for each of the wires in the CAN and Input harness.
Page 8: Installation Steps
Installation Steps: ***STOP & READ CAREFULLY!*** You are about to wire your car with the next generation Infinitybox system. There is no system on the market that can give you the power and flexibility that you can get with Infinitybox.
Page 9: Step 1: Mounting The Inmotion Ngx Cells
There are 4 primary versions of the inMOTION NGX and they are identified by their intended location in the car. If you have a 2-door vehicle, you will be only using inMOTION NGX modules identified as front. If you have a 4-door vehicle, you will have inMOTION NGX modules identified as front &...
Page 10 Checklist for Step 1- Mounting the inMOTION NGX Cells Do you have the inMOTION NGX module securely installed in your door using the mounting holes on the housing? Did you mount your inMOTION NGX modules in the correct locations based on the label on the housing? Revision 25031701...
Page 11: Step 2: Running Power And Ground
STEP 2: Running Power and Ground The inMOTION NGX modules need to get power from your battery. They also need to be grounded to the chassis. The Power and Output harness that comes with the kit includes these wires.
Page 12: Step 3: Connecting The Can Cables
These wires correspond to the green and yellow wires in the CAN cable that comes with your Infinitybox IPM1 kit. The CAN LO and CAN HI wires from the inMOTION NGX modules need to be connected to their corresponding colors in the IPM1 CAN cable and to the CAN wires connected to the other inMOTION NGX modules.
Page 13 INFINITYBOX, LLC 6460 West Cortland Street Chicago, Illinois 60707 www.infinitybox.com Revision 25031701...
Page 14 Is your CAN cable routed away from high-voltage ignition coil wires? Did you properly splice the green and yellow CAN wires together to the CAN cables connected to the other modules in your Infinitybox network? Did you properly protect the splices in your CAN cables?
Page 15: Step 4: Wiring The Inmotion Ngx Outputs
Output harness. You are going to connect these output wires to the wires on your power lock actuator and your power window motor. Please note that the inMOTION NGX module is intended to be used to power 2-wire, DC motors for your lock actuators and power window regulators. Check the wiring diagram that came with your power locks or window kit to make sure that the motors only require 2 wires to properly power them.
Page 16 Contact Infinitybox technical support for more details on using door poppers. The inMOTION NGX also has standard outputs that can be used for turning low-current outputs on and off. These outputs can be used to control indicator lights on switches, interior lighting, accent lights, puddle lights and other low-current loads.
Page 17: Step 5: Wiring The Switches
NGX input. It is very important that you are only connecting ground to the inMOTION NGX inputs. Do not connect positive voltage to the inputs. This will damage the inMOTION NHX module and void the warranty.
Page 18 Connect the red lead of your meter to the terminal that will connect to your inMOTION NGX input. When the switch is off, the meter should read a very high resistance, typically megaohms or M Ω. The meter may also read “OL” for overload, meaning that the measured resistance value is out of range.
Page 19: Warranty Information
United States. In order to receive warranty service, purchaser must provide Infinitybox with a copy of the receipt stating the dealer name, product purchased and date of purchase. Products found to be defective during the warranty period will be replaced (with a product deemed to be equivalent or better) at the discretion of Infinitybox.
Page 20: Contact Information
INFINITYBOX, LLC 6460 West Cortland Street Chicago, Illinois 60707 www.infinitybox.com Contact Information The INFINITYBOX™ Intelligent Power Management System is a product of Infinitybox, LLC 6460 West Cortland Street Chicago, Illinois 60707 (847) 232-1991 sales@infinitybox.com www.infinitybox.com Revision 25031701...
