HD X-SSD H a rd D is k P l ay e r O verv iew
1.1.4 The Web Browser Interface
If the HDX-SSD is installed in a home network the External
Display and Front Panel Display interfaces can be
duplicated by any Flash enabled web browser
To access the External Display Interface from a web
browser, open the web browser and type the unique
"name" of your HDX-SSD into the browser address field.
The name is the last four characters of the MAC address
(excluding the colon separators) printed on the rear
panel preceded by NSHDX). A typical "name" would be
NSHDX4567.
To access the Front Panel Display interface from a web
browser add the suffix:
/index.html?movie=fp.swf to the HDX-SSD name.
E.g. NSHDX89B5/index.html?movie=fp.swf
Note:
Depending on your web browser you may need to
type "http://" immediately before the HDX-SSD name.

1.2 HDX-SSD Interface Options

Interface
Front Panel Display
External Display
Web Browser
Desktop Client
NaimNet/StreamNet
n-Serve iPod/iPhone App
Note: An internet connection is required for detailed CD data lookup. Without an internet connection, limited information is
available from a locally held database.
2
Control Display
Touch screen. Front Panel display.
Remote handset.
Remote handset. TV or monitor with VGA,
Keyboard/mouse. S-video or composite input.
USB/VGA touch screen. USB/VGA touch screen.
Flash enabled web browser.
Computer running Windows XP,
Windows Vista or Windows 7.
StreamNet compliant network touch screen.
iPhone or iPod touch
1.1.5 The Desktop Client
If the HDX-SSD is installed in a home network that includes
a personal computer running Windows XP, Vista or 7, it can
Desktop Client
be operated via the
Client application provides the most comprehensive
operational and search functionality. The
covered in a separate manual that can be downloaded
from the Naim Audio web site at
Some setup, file management and maintenance facilities
are only available via the Desktop Client.
1.1.6 iPod/iPhone App
The n-Serve app, available from the iTunes App Store,
enables wireless touch screen control of HDX-SSD from an
iPhone or iPod touch.
Notes
Enables control of both HDX-SSD local outputs in
stand-alone installations and network streams in
network connected installations.
Controls local outputs only.
Duplicates functionality of Front Panel and
External Display Interfaces. Network connection
required. Controls local outputs only.
Provides music database management and
advanced HDX-SSD setup functions. Can also
control local outputs. Network connection
required.
Controls network streams only.
Does not control local outputs.
Network connection required.
Controls HDX-SSD local output only.
Wireless network connection required.
Interface. The Desktop
Desktop Client is
www.naimaudio.com.
