OPERATING MANUAL FOR GEM MULTIDECK DISPLAY
CABINETS
IMPORTANT INFORMATION (PLEASE RETAIN THIS DOCUMENT)
This Manual covers the installation, operation and routine maintenance requirements for the
following Williams Refrigeration products:
R-Series / M-Series / G-Series
A refrigerated display cabinet is designed to maintain the temperature of pre-chilled produce
within the temperature range set out below.
Please read this Manual carefully before connecting the appliance.
Provided the instructions in this Operating Manual are read and implemented correctly, the
optimum performance and reliability of your equipment should be maintained.
We assume the installer, user and service provider are appropriately trained, skilled and
competent to properly and safely carry out the work, and will use the necessary safety
equipment, and take the necessary precautions required of their intended work.
Improper installation, maintenance or repair may put the user at considerable risk.
GEM Temperature Range
+3°C(37°F) / +5°C (41°F)
Regulations
Declaration of Conformity:
Refrigerant Designation
HFC/HFO - R452a
HC - R290
Williams Refrigeration declares that all products manufactured by Williams Refrigeration comply with the
above directives as they apply to those products, and those products are therefore declared to be in
conformity with the provisions of the above legislation.
Model No.: ...............................................................................
Serial No.: ................................................................................
GEM Climate Class
3M2
Global Warming Potential
2140
3
GEM dB(A)
70
