XT-160AMP Amplifier - User Manual
Functional summary
 160W Amplifier- 8 ohms , (20Hz-20kHz)
 8-Ports Audio- maximum 160W(8×20W) , Can support up to 16 Speakers X 10W
maximum each Port .
 Built-in 2-UHF microphones A+B Chipset,UHF Frequency Range: 820MHz - 850MHz
(Mic Optional).
 Built-in Bluetooth Audio SoC,APT-X,HD audio-15m Distance Qualcomm.
 Extra microphone input Port- with a 6.5mm interface.
 AUX Audio Input , Rj09 Port
 Wireless Remote uses 433Mhz frequency low power device UHF frequency Control-
360-degree direction signaling technology-20M coverage.
 Support pairing multiple Amplifiers with 2 UHF microphones A&B Channel.
 Support Playing Music , Audio Sharing from one Mobile to multiple Amplifiers ( Work
with Android Mobiles Only ).
 Power Supply : AC115V-230V （47-63Hz）

Advertisement

loading
Need help?

Need help?

Do you have a question about the XT-160AMP and is the answer not in the manual?

Questions and answers

Summary of Contents for XONTEL XT-160AMP

  • Page 1 XT-160AMP Amplifier - User Manual Functional summary  160W Amplifier- 8 ohms , (20Hz-20kHz)  8-Ports Audio- maximum 160W(8×20W) , Can support up to 16 Speakers X 10W maximum each Port .  Built-in 2-UHF microphones A+B Chipset,UHF Frequency Range: 820MHz - 850MHz (Mic Optional).

  • Page 3: General Notes

    General Notes : 1- Use Cable Cat6 wire between Speakers & XT-160AMP , normal sound cables can be used but Cat6 will be more easy for you to fix inside the Amplifier Ports. 2- Use the External 1M Bluetooth antenna (PIC-01) Free included inside the XT-160 AMP box ,when you install the XT-160AMP inside the room ceiling.
  • Page 4 Remote Control : In the Normal situation The Remote control is already PAIRED with the XT-160AMP( Amplifier )from the factory. Just try to Power ON/OFF the device using the Remote to check if the PAIR is OK . make sure the new Remote control has a new battery and the Red LED...
  • Page 5 3- start using the Remote Control. Second way to Pair the Remote Control : 1- Power OFF and Power On again the XT-160AMP ( Pic-1 ) ,until you will hear a sound prompt tone saying : ( BlueTooth Ready ).

  • Page 7: Remote Control Functions

    - The BT button in the remote control is for ON/OFF the Bluetooth only. - Bluetooth coverage distance between 10m-15m in an open area. - XT-160AMP Limited to connect only one Mobile using Bluetooth at the same time . - If someone is using the Bluetooth and you do not know him, then you can Discharge (Dismissed) him from using the bluetooth by long pressing the BT button turn OFF/ON in the remote control.
  • Page 8 Name Icon Function 1- ON / OFF for the Amplifier. Power 2- Pair New Remote Control. 3- Press and hold to restore factory Settings. 1- Mute / Unmute for the Amplifier sound. 2- When long press for 4 sec, The MUTE microphone sensitivity will change.

  • Page 9: Reset Amplifier

    Reset Amplifier : Long press the (Power) button for 2 Seconds in the Remote control will restore factory Settings as below : 1- Reset device volume to Level 15 (15/32) 2- Clear the Bluetooth connection of any connected devices. 3- Reset and open BT, AUX, MIC channels (same as BT ON\AUX ON\MIC ON) 4- Mic PAIR will not be lost.
  • Page 10 UHF Hand - Mic-02 XT-160AMP Support Max 2 Mic A+B Channels...
  • Page 11 7- One short press the SET key to switch between A/B channels. 8- Long press the SET key for 2-3 seconds will take the microphone to the PAIR mode with the Amplifier XT-160AMP. 9- Distance between Amplifier and Mic is Not more than 30m.
  • Page 12 UHF Clip microphone instructions MIC-03...
  • Page 13 The setting takes effect after that the microphone is restarted. 8- Hold down the CH+ key for 2 seconds to control the microphone to enter the pairing mode,and then pair the microphone with the XT-160AMP for the pairing mode within 5 seconds.
  • Page 15 Do the Pair step again for the Remote Control . Can I Play Music from my Mobile to Multiple XonTel Amplifiers at the same time? Yes you can , but Unfortunately this feature is working only with all Android Mobiles , while Apple Company limited this feature ( Audio Sharing ) for only their headphones and earbuds.
  • Page 16 Put the firmware on the USB flash drive, plug the USB flash drive to USB line, and then connect the XT-160AMP Upgrading port, Prompt tone: “Upgrading firmware, pls wait’’ will be played, and when it is done, broadcast: Firmware upgrading completed. If fail, will broadcast: Firmware upgrade failed.
