Summary of Contents for Condura CONWM10TWTSASTD
- Page 1 CONWM10TWTSASTD...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS Safety Precautions INSTALLATION Product description Unpacking the washing machine Installation area Position of the drain hose OPERATIONS Control panel Preparation before washing Washing Rinse Spin Laundry quantity with corresponding to different capacities Laundry volume and detergent dosage reference Special functions Maintenances Cleaning and Care... -
Page 3: Safety Instructions
. bed and breakfast type environments; . areas for communal use in blocks of flats or in launderettes. Spin rated Maximum Water Wash rated Model capacity capacity Pressure CONWM7.0TWTSASTD 7.0 kg 5.0 kg 0.6MPa CONWM10TWTSASTD 10.0 kg 6.0 kg 0.6MPa... -
Page 4: Explanation Of The Symbols
SAFETY INSTRUCTIONS Explanation of the symbols: Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries unless it’s avoided. Caution! This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries or damage to property and the environment. - Page 5 SAFETY INSTRUCTIONS Do not dismantle the machine This appliance is for indoor use Do not place inflammable only. Do not install the machine in by yourself. materials like burning candle, damp or rainy environment to mosquito incense, cigarette etc. avoid electric shock, fire, or heating source like electric machine failure, or deformation.
-
Page 6: Installation
• The product line chart is for reference only, please refer to real product as standard Accessories Inner spin cover Water inlet hose Condura manual Unpacking the washing machine Warning! • Packaging material (e.g. Films, Styrofoam) can be dangerous for children. -
Page 7: Installation Area
INSTALLATION Installation area Warning! • Stability is important to prevent the product from • Make sure that the product should not stand on the power cord. W > 20mm Before installing the machine, the location characterized as follows shall be selected: 1.Rigid, dry, level surface and avoid direct sunlight 2.Sufficient ventilation, room temperature is above 0 3.Keep far away from the heat resources such as coal or... -
Page 8: Operations
OPERATIONS Control Panel Normal Heavy Drain Washing Spinning Soak Wash-Drain Selector Wash inlect sector Wash timer Drain selector Spin timer Water inlet selector Note! • The product line chart is for reference only, please refer to real product as standard Wash timer: be used to select required washing time. -
Page 9: Rinse
OPERATIONS Rinse Normal Normal Drain Drain Heavy Heavy Wash-Drain Selector Wash-Drain Selector Open tap Close the tap after Choose washing Choose the washing time Drain the water level program To start washing clothes Spin spin cover Spin cover Spin tub Safety cover Correct Incorrect... -
Page 10: Laundry Volume And Detergent Dosage Reference
OPERATIONS Laundry volume and detergent dosage reference 7.0kg Capacity Fabric type Laundry Water Water flow Wash time Detergent capacity (kg) level (minutes) amount (g) Synthetics, silk, 0-3.0 Normal About 39 Delicate fabrics 3.0-5.0 About 51 Cotton or linen 0-5.0 Normal About 51 Heavy soils 5.0-6.5/7.0... -
Page 11: Maintenances
MAINTENANCES Cleaning and care Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning the cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. If there is any water overflow, use the wet cloth to wipe it off immediately. -
Page 12: Trouble Shooting
3. Fit the water inlet hose and turn on the water tap to confirm water filling and draining work properly. Objects are dropped into the outside of the spin tub Frame 1. Remove all screws on the frame with a screw driver and loosen the connector of the brake belt . -
Page 13: Technical Specifications
MAINTENANCES Energy efficiency test program: CONWM7.0TWTSASTD and CONWM10TWTSASTD During "Normal" Washing program, washing 6minutes;rinse once for 1minutes,and then spin twice, 6minutes each, Water level "M" used for all wash and rinse. Technical Specification Model Washing Dimension Rated Capacity (W*D*Hmm) Weight Power CONWM7.0TWTSASTD... - Page 14 Covered Region/Areas: National Capital Region (NCR), Ilocos Region (Region I), Cordillera Administrative Region (CAR), Central Luzon (Region III), CALABARZON (Region IV-A), MIMAROPA except Romblon (Region IV-B), Bicol Region except Masbate (Region V) Email Address: customercare@condura.com CEBU Regional Office Address: Dr. A Esperanza Building. A.C Cortes Ave. Mandaue City...
-
Page 15: Customer Care
MOBILE NO.: I consent to the collection, processing and use by Concepcion Durables, Inc. (CDI) of the data above for the purpose identified in its Data Privacy Notice published in its website (www.condura.com), which is deemed incorporated into this Warranty Card.
