- Page 1 CONTRACTOR SERIES CONTRACTOR SERIES LOUDSPEAKER SYSTEMS LOUDSPEAKER SYSTEMS From Fender Pro Audio Owner's Manual for CS-215 Subwoofer P/N 051345 REV A...
- Page 2 Whether you simply need loudspeaker systems to compliment your existing setup or a complete sound system, Fender has the sound reinforcement equipment that will meet your needs. Likewise, your decision to purchase Fender pro audio gear is one you will appreciate with each performance for years to come.
- Page 3 This design results in low 101 dB Sensitivity @ 1W / 1m distortion, very high power handling and very high SPL output. Likewise, large ports on the CS-215 Two 15” Woofers with 4” Voice Coils cabinet prevent compression at high SPL due to and 110 Ounce Magnets large exit velocities.
- Page 4 (Fender P/N 071-1359-000) and using the subwoofer as a base. In permanent installations, the CS-215 may be placed under a stage, table or podium. For each particular situation, a compromise among these three factors should yield the best solution possible.
- Page 5 CROSSOVER SUGGESTIONS After the speaker system has been placed, the crossover point needs to be set for maximum benefit. While the 15" drivers in the CS-215 are fully capable of accurately reproducing frequencies above 350 Hz, the bandpass enclosure has been designed to acoustically roll off frequencies above 170 Hz.
- Page 6 PCN-2 ELECTRONIC CROSSOVER UNPOWERED MIXER MONITOR MAIN HIGH INPUT A IN B IN SPA-13000 A OUT B OUT FULL RANGE INPUT FULL C-12 C-12 RANGE INPUT C-15 C-15 M-500 MONITOR AMPLIFIER CS-215 SPL 1285 MK-II SPL 1285 MK-II MONITOR MONITOR SPEAKER SPEAKER...
- Page 7 MULTIPLE SPEAKERS IN A BI-AMPED SYSTEM WITH MONITORS C-12 C-12 C-12 C-12 C-15 C-15 C-15 C-15 SUBWOOFERS CS-215 CS-215 A Out B Out UNPOWERED MIXER MONITOR MAIN SPA-13000 (Dual mono operation) A Out B Out SPA-13000 (Dual mono M-500 operation)
- Page 8 Nominal Impedance: 4Ω DIMENSIONS Weight 130 lbs. (59 kg) Height 27.25" (69.2 cm) Width 25.75" (65.4 cm) Depth 20.56" (52.2 cm) Product specifications are subject to change without notice. A PRODUCT OF: FENDER MUSICAL INSTRUMENTS CORP. CORONA, CA 91720 USA...
