  • Page 1 Quick Guide MGS5 EV...
  • Page 3 Contacts and Details Before starting the journey, it is recommended that you read the Owner's Manual on the MG Motor website or iSMART App to understand all the information required for the use of the vehicle. Please scan the QR code to select your region and download the iSMART APP. Register and view the user manual.
  • Page 4 Nature of breakdown  Exact location UK Roadside Assistance Emergency Contact: 0800 072 3338 MG UK Website: www.mg.co.uk Nearest Authorised Repairer - Consult MG Touchpoint Company Address: MG Motor UK Ltd Lowhill Lane Birmingham England B31 2BQ Version Details: Version 1.30...

  • Page 5: Interior Layout

    Interior Layout 1. Headlamp Levelling Adjustment Switch & Mirror Adjustment Switch 2. Wiper Stalk Switch 3. Instrument Pack 4. Direction Indicator & Main Beam Stalk Switch 5. Intelligent Display 6. Passenger Airbag 7. Glove Box 8. Instrument Panel Central Switch Pack 9.

  • Page 6: Instrument Pack

    Instrument Pack 1. Warning Lamps and Indicators 5. Power Meter 9. Driver Assistance 2. Power System State 6. Information Display Cards 10. Clock 3. Gear Information 7. Energy Regeneration Mode 11. Electricity Meter 4. Driving Mode 8. Vehicle Speed 12. Electricity Driving Range Please consult Owners Handbook for detailed warning light description and function...
  • Page 7 Underbonnet Locations 1 2 3 1. High Voltage Battery Pack Coolant Expansion Tank 3. Brake Fluid Reservoir 2. Electric Drive Transmission Coolant Expansion Tank 4. Washer Fluid Reservoir...
  • Page 8 Recommended Fluids, Capacities and Pressures High Voltage Battery Pack Coolant Glycol (OAT) 4.2 Litres Electric Drive Transmission Coolant Glycol (OAT) 5.8 Litres Rear Electric Drive Transmission Oil _125kW * Shell E-Fluid E6 iX (SL2808) 0.85 Litres Rear Electric Drive Transmission Oil _170kW * Shell E-Fluid E6 iX (SL2808) 0.9 Litres Brake Fluid...
  • Page 9 Starting and Stopping Power System Starting Power System When the driver opens the driver’s door, and sits in the driver’s seat, the instrument pack and touch screen are powered on. 1 When pressing the brake pedal, the vehicle enters READY state. 2 Select ‘D’...

  • Page 10: Locking And Unlocking

    Locking and Unlocking 1. Lock Button 4. Mechanical Key 2. Tailgate Release Button 5. Find My Car Button 3. Unlock Button 6. Smart Key Passive Entry The passive entry system can unlock the doors as long as you carry the smart key and approach the car.

  • Page 11: Emergency Starting

    Emergency Starting Emergency Starting NEVER attempt to power the vehicle by pushing or towing. Make sure that both batteries are of the same rated voltage (12 volts), and that the booster cables are approved for use with 12 volt car batteries. Ensure sparks and naked flames are kept well away from the front compartment.
  • Page 12 Emergency Starting Emergency Starting cont Start the donor vehicle and allow it to run for a few minutes. Start the disabled vehicle. If the disabled vehicle does not start after several attempts, it may need to be repaired. Please contact an MG Authorised Repairer. After both the vehicles have normally started/powered, turn off the donor vehicle power.
  • Page 13 Towing for Recovery Vehicle Recovery Towing for Recovery Towing Hook When pushing or towing the vehicle from a dangerous situation or onto the transporter, the speed must remain below 3mph and be completed within 3 minutes. When pushing or towing the vehicle for temporary situation, the driver's side seat belt should be inserted into the buckle and maintained in the inserted state, then turn the shift knob to N and release the EPB, otherwise the vehicle may be damaged.
  • Page 14 Towing for Recovery Towing points are intended for use by qualified recovery specialists to assist in the recovery of your car when a breakdown or accident occurs. They are not designed for towing other vehicles. The vehicle can be towed using a tow rope but a towing bar is recommended. NEVER use a twisted tow rope, may cause the towing eye to unscrew.
  • Page 15 Towing for Recovery Towing for Recovery When towing, DO NOT suddenly accelerate or brake suddenly, this can cause accidents. Suspended Towing Suspended towing is the best method for recovering a vehicle that needs to be towed. ALL DRIVEN WHEELS MUST BE SUSPENDED ABOVE THE GROUND. Ensure the EPB is released when the rear wheels are in contact with the road surface.
  • Page 16 Emergency Tyre Inflation Tyre Repair Tool Identification 1. Towing Hook 2. Wheel Bolt Cap Removal Tool 3. Repair Fluid 4. Electric Air Pump Tyre Repair 1. Remove the label at the bottom of the repair fluid reservoir and attach it to the steering wheel to remind the driver not to exceed 50 mph.
  • Page 17 Emergency Tyre Inflation 3. Switch on the power switch of the electric air pump (i.e., press " - "), to start pumping sealant into the tyre. The repair fluid reservoir will become empty after approximately 30 seconds. The tyre should reach the specified pressure within 5 or 10 minutes.
  • Page 18 Emergency Tyre Inflation Please follow different guidelines based on the tyre pressure measured:  If the tyre pressure has dropped to less than 0.8 bar (11.6 psi), do not continue driving, seek assistance instead.  If the tyre pressure is between 0.8 bar (11.6 psi) and specified pressure, use the electric air pump to inflate the tyre until it reaches the specified pressure.

  • Page 19: Battery Safety Information

    Battery Safety Information Batteries pose potential risks, and appropriate protective measures must be taken during operation and maintenance! Only the correct tools and suitable protective equipment must be used when handling batteries! Maintenance of batteries must only be performed by individuals with approved certification, specialized battery knowledge and the correct safety training! Failure to adhere to any of the above warnings may result in severe accidents or even death! 12V Lead-acid Battery...
  • Page 20 Battery Safety Information High Voltage Battery Pack The high voltage battery pack contains several lithium-based battery cells and high voltage wiring harness.  High Voltage Safety: ONLY qualified personnel are allowed to work with the high voltage system - there is danger of DEATH.

  • Page 21: Battery Information

    Battery Information According to REGULATION (EU) 2023/1542, provide CE marking and manufacturer information for portable batteries that come with the vehicle. Please refer to the following information: Tyre Pressure Monitor Sensor Battery Product Information Manufacturer Manufacturer Product Name Model Name Address NO.38, Hui Feng 7th Lithium-Manganese...
  • Page 22 Battery Information TBOX Battery Product Information Product Manufacturer Model Manufacturer Address Name Name Shibaura Crystal Shinagawa, NiMH 3HR-AAA- 1-6-41 Konan, Battery CORPORATION Minato-ku, Tokyo 108-8212 Pack Japan...
  • Page 24 MG Motor UK Ltd Lowhill Lane, Birmingham, England B31 2BQ www.mg.co.uk...
