Dock Bench
PN 10619
Scan for Online Help:
FAQ, Online support
Assembly Instructions
RECOMMENDED TOOLS
Wrenches or sockets:
15mm (or 5/8")
14mm (or 9/16")
10mm (or 13/32")
Cordless Drill:
7/16" Drill Bit
Rubber Mallet
Screwdriver:
Phillips #3
Work Gloves
(651) 674-2450
info@patriotdocks.com
Advertisement
Summary of Contents for Patriot Docks Dock Bench 10619
- Page 1 Dock Bench Assembly Instructions RECOMMENDED TOOLS PN 10619 Wrenches or sockets: 15mm (or 5/8”) 14mm (or 9/16”) 10mm (or 13/32”) Cordless Drill: 7/16” Drill Bit Rubber Mallet Screwdriver: Phillips #3 Work Gloves (651) 674-2450 Scan for Online Help: FAQ, Online support info@patriotdocks.com...
- Page 2 Dock Bench Components Description Qty. 10619-1 Bench Frame 10619-2 Seat and Backrest 10619-3 Left Armrest 10619-4 Right Armrest 10619-5 End Caps (Pre-assembled on bench) N6-a M10x60mm Serrated Bolt and Nut N6-b M10x80mm Serrated Bolt and Nut N6-c M10x100mm Serrated Bolt and Nut N6-d Rubber Strip N6-a...
- Page 3 Dock Bench Assembly Instructions Mount the Bench Frames (N1) to the Dock Frame: Patriot Low Profile Frames: The Bench Mounting Kit is required Patriot Truss Frames: Loosely attach Bench Frames (N1) to your truss frame for Low Profile Mounting. Orienting the square tube outward, in the desired location.
- Page 4 Dock Bench Assembly Instructions Next, attach the Bench Seat (N2) and Armrests (N3 & N4) Insert Plastic Cup Holders (N7). using the M10x100mm bolts/nuts (N6-c). Notice the Armrest have a left and right, where the Armrest protrudes out from the bench for more seating space.
