Summary of Contents for ERM StarLink Tracker SF iRF
- Page 1 StarLink Tracker SF iRF Installation Manual 2G/GPRS, 3G and 4G LTE CAT4 models Release 4.2 © Copyright 2023 ERM Electronic Systems Ltd. ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313...
-
Page 2: Table Of Contents
Green LED blink patterns: ............16 8.1.2 Red LED blink patterns: ..............16 ERM CONTACT INFORMATION ..................... 16 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. -
Page 3: General Information
• Install ERM devices away from any heat sources. • Do not install ERM devices in the engine compartment or on the vehicle’s exterior. • Install ERM devices away from large metallic bodies and never install them in small gaps between metallic objects. - Page 4 Use a heater-gun to heat the insulation. The insulation shrinks until it sits snugly on the solder joint. • Tie the wire with a cable tie in such a way as to relieve stress from the new solder joint ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313...
-
Page 5: Product Details
PRODUCT DETAILS 3 Description StarLink Tracker SF iRF is a tracking device with multiple dedicated functions and features. The device includes several I/O ports to monitor vehicle data and triggers, external Add- Ons and Accessories. It uses cellular communication to communicate with a cloud server, and several location technologies to determine its exact location. -
Page 6: Technical Specifications
Analogs ports 2 inputs using an external adaptor 0-12V and 0-5V (optional using EDA Analog) Dedicated port Ignition port, one wire data wire for ERM accessories (eNet protocol) Accelerometer Highly sensitive 3D accelerometer, +/-8G Power Supply 9-32VDC, 20-30mA, Low power mode (GPS off) < 10mA, Power save mode (Standby) <... - Page 7 Water and vibration resistance Max. relative humidity 90+/-5% Note: iRF (Bluetooth) Supported Devices: To pair a device, please refer to the instructions/config as listed in the StarLink protocol. iRF illustration Diagram ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313...
-
Page 8: Installation Procedure
This procedure describes the standard connections required to operate StarLink devices. 6.1 I/O Ports Specification • Before connecting the harness refer to the StarLink wiring/color connector diagram blow: StarLink Harness: 10-pin connector, 20AWG thickness, 1m wiring length ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313... - Page 9 Unused wires should be isolated and tied neatly so they do not interfere with any other parts or systems. Keep in mind that you may need to use some of the wires in the future ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313...
-
Page 10: Configuring The Device Per Vehicle Type
Prior to installing the device, make sure the device is properly configured with the vehicle and gear type. Failure to configure essential parameters will prevent the functionality of the device and result with bad performances. For assistant: refer to ERM Protocol or use ERM support services 6.3 SIM card insertion •... -
Page 11: Positioning Starlink Devices In The Vehicle
THIS SIDE UP marking). Do not cover this area with metallic parts. • For Optimal Reception Quality, Identify the desired location for the device installation. This location should be concealed (inaccessible to ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313... - Page 12 The StarLink device should not be installed behind the fuse box. • The StarLink device should be facing upwards to enable good GPS reception. • Never install the StarLink device with the antenna side next to metal objects. ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313...
-
Page 13: Configuration
Power and eNet cable Ignition cable eNet spare cable • Using the eNet cable, connect the eNet hub to the USB Adapter, then connect the other end to the eNet hub: ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313... - Page 14 (see section 5) • Connect the power supply cable to a 12V power supply. you can use the red and black connectors as described in the pictures below: ERM Electronic Systems LTD | www.ermtelematics.com support@ermtelematics.com | +972-3-9413313...
- Page 15 You are now ready to configure your StarLink device. Connect the USB cable to your PC and install the USB DRIVER as follows: • Use your ERM username (given by ERM support) and password to enter the ERM Portal at: http://erm.co.il/protocol •...
-
Page 16: Configuring And Setting Starlink Functions
For more details, configuration information and instructions such as selecting and setting the right vehicle type for the SF functionality or setting up Bluetooth nodes to communicate with the StarLink device, additional software programs to use etc... please refer to ERM portal at: http://erm.co.il/protocol 8 Troubleshooting •... -
Page 17: Green Led Blink Patterns
Unit is connecting to network Always on Modem is connected to server ERM CONTACT INFORMATION ERM Support: Skype: erm.support StarLink online protocol site: http://erm.co.il/protocol ERM’s YouTube Channel: http://www.youtube.com/ermtelematics ERM Advanced Telematics 16 Hasar Shapira Street, Rishon Lezion, 7570418, Israel Telephone: +972-(0)3-941-3313, Fax: +972-(0)3-941-3330 Web: www.ermtelematics.com...
