LGE Internal Use Only
Service Manual
TABBOOK
11T540 Series
REV. 00
Copyrightⓒ 2014 LG Electronics, Digital Mate Co., Ltd .
All rights reserved. No part of this manual may be used, copied,
reproduced, modified, distributed, displayed, stored in a retrieval
system, or transmitted in any form by any Means (electronic,
2014. 01. 15
photocopying, recording or otherwise), without the Prior written
Retention period until : 2018-01
authorization of LG Electronics.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TABBOOK 11T540 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LG TABBOOK 11T540 Series

Summary of Contents for LG TABBOOK 11T540 Series

  • Page 1 TABBOOK 11T540 Series REV. 00 Copyrightⓒ 2014 LG Electronics, Digital Mate Co., Ltd . All rights reserved. No part of this manual may be used, copied, reproduced, modified, distributed, displayed, stored in a retrieval system, or transmitted in any form by any Means (electronic, 2014.

  • Page 2: Table Of Contents

    Using LG Recovery Center Recovering from Boot Failure Backup and Restore Security Platform Data Symptom-to-part index Power system checkout LCD-related symptoms Indeterminate problems Removing and replacing a part (FRU) Part lists Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 3: Important Service Information 69 Lcd

    The drive startup sequence in the computer you are servicing may have been changed. Be extremely careful during write operations such as copying, saving, or formatting. If you select an incorrect drive, data or programs can be overwritten. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 4: Safety Notices 71 Keydeck

    Though the main batteries have low voltage, a shorted or grounded battery can produce enough current to burn personnel or combustible materials. WARNING Before removing any part (FRU), turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 5: Safety Information 73 Main

    3 Removing or installing main units Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the customer to power-off the wall box that supplies power Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 6: Safety Inspection Guide

    This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-LG features or options not covered by this inspection guide. If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem.

  • Page 7: Handling Devices That Are Sensitive To Electrostatic Discharge

    4 Check the power cord for : 5 Check for any obvious non-LG alterations. Use good judgment as to the safety of any non-LG alterations. 6 Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 8: Laser Compliance Statement 75 Etc

    Emits visible and invisible laser radiation when open. Do not stare into the beam , do not view directly with optical instruments, and avoid direct exposure to the bean. Backup (Standby) RTC battery safety information When replacing or disposing of the backup (standby) RTC battery, note the following : Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 9: Read This First

    Before you go to the checkout guide, be sure to read this section. IMPORTANT NOTE Only trained personnel certified by LG should service the computer. Read the entire FRU removal and replacement page before replacing any FRU. Use new nylon-coated screws when you replace FRUs.

  • Page 10: Name Of Each Part

    Sound Volume Control Button (low/high) Slide Button Built-in Speakers Reader Mode Button Power Button Built-in Microphone Power Port HDMI Port USB Port (USB 3.0 / Fast Charge Port) USB Port (USB 2.0) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 11 Y-type cable or external power source to supply the power needed to the digital device. Front View Webcam status lamp Web Camera Illumination Sensor Windows Start Screen button Keyboard Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 12: System Information

    Manufacturers and installers cannot provide services related to human safety as this wireless device may cause radio interference. Web Camera 2.0 M Web Camera Product Weight Approx. 0.93 kg (a battery included) The weight may differ according to the model. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 13: System Block Diagram

    System information System Block Diagram Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 14: Using Hot Keys

    Fn + Caps Lock Use [Scr LK] key. Fn + ▲ Use [PgUp] key. Fn + ▼ Use [PgDn] key. Fn + ◀ Use [Home] key. Fn + ▶ Use [End] key. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 15 On (orange) : The system is turned on. Off : The system is turned off or in the Sleep Mode. Webcam Lamp On : The web cam is operating. Off : When the webcam is not operating Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 16: Bios Flash

    To boot into EFI Shell, you must disable “Secure Boot option”. To boot from a USB device, use [Fn+2] key to move the USB device to the top of the list in Boot menu after entering BIOS Setup, or press [Fn+10] key to display Boot menu while the LG logo is being displayed, and the select a device you want to use.
  • Page 17 CAUTION For details, refer to [Check Secure Boot]. It selects the :” Load Optimized Defaults” on the “Exit” menu or [Fn+9] Key and it summons a BIOS settings at initial value. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 18: Check Secure Boot

    Upon the system rebooting, enter BIOS Setup again and check if Secure Boot has the values in the following figure. (Check UEFI Secure Boot, Protected Signatures, CertNames and Secure Boot Option.) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 19: Bios Setup

    Downgrading from Windows 8 to Windows 7 (SecureBoot Disable) In Windows 8, select “Restart”. Once the system restarts and “LG” Logo appears, press [Fn+2] key. The booting speed is faster than the existing models. You’d better press it as soon as the system restarts.
  • Page 20 This shows the size of L2 Cache RAM for the CPU. Total Memory This shows size of system memory. System Date / Time Drag the Date or Time button to change the system date/time. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 21: Advanced Menu

    Select whether to support the charging function by using the USB port (Enable/Disable). Haptic Feedback Select the vibration (Enable/Disable) for the Windows button on the center of the bottom of the LCD panel. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 22: Security Menu

    Select On to enable Secure Boot (only when Protected Signatures is Enabled; user mode). Select Off to disable Secure Boot. (Default: On) Install Default Secure Boot Keys Reset the Protected Signatures option to Enable (User Mode) if it is Disabeld (Setup Mode) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 23 Delete All Secure Boot Keys Set the Protected Signatures option to Disabled (Setup Mode). Once you do so, the Secure Boot option stays Disabled until you click the Reset to Default option. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 24 System information Boot menu Edit Boot Order To change the booting order of the system, drag the decive icons up or down. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 25 This changes the parameters in the Setup menu to the factory default settings. When it is selected or [F9] key is pressed, the confirmation message appears. Click [Yes] to change the settings. Discard Changes This returns to the factory default settings for each parameter in the Setup menu. Save Changes Save change value. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 26: Using Lg Recovery Center

    If you have deleted the restoration data in the protected area of the hard disk, or have arbitrarily installed another operating system, the restore function may not work. Click the [ ] icon in Desktop to run LG Recovery Center. PC Recovery: Recovers the PC without losing any personal files. CAUTION PC settings are reset to default and any user-installed software will be deleted.
  • Page 27 When the following screen appears, select the USB flash drive and click [Next]. CAUTION This process deletes all the data on the storage device designated as a recovery drive. Make sure to back up its data in advance. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 28 Select [Remove the Recovery Partition] while creating a recovery drive to remove the recovery partition in the PC. Once the recovery partition is removed, you cannot use the recovery function of the PC. You can only recover the system using the recovery media. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 29: Recovering From Boot Failure

    System information Recovering from Boot Failure If booting is impossible due to a serious error with the system, you can recover the system through LG Recovery Center RE. CAUTION If you have deleted the restoration data in the protected area of the hard disk, or have arbitrarily installed another operating system, the restore function may not work.
  • Page 30 If it is impossible to recover by using [F11], you can recover the system through a recovery drive. To recover by using a recovery drive, you must have the recovery drive made through LG Recovery Center [Create Recovery Drive]. Connect the recovery drive to the USB port of the computer.

  • Page 31: Backup And Restore Security Platform Data

    PSD configuration settings are included in both automatically written Backup Archives and manually written Backup Archives. y PSD backup file (e.g. SpPSDBackup.fsb): A backup copy of the PSD image file may be created during a Security Platform User's manual backup. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 32 Please note that automatic backups are only executed if your PC is not shut down at the scheduled time.Please note that the user account chosen for the scheduled backup must be member of the group “Administrators” or “Backup Operators”. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 33 This button is disabled, if the Infineon Security Platform is disabled or not yet set up. Click here to create a backup authentication device. This feature is only available, if Enhanced Authentication is enabled. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 34: Symptom-To-Part Index

    If the voltage is not correct, remove the power code form AC adapter. 10 seconds later, connect the power code, then measure the output voltage. If the voltage is not correct, change the AC adapter. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 35 To check the battery pack, do the following : Power off the computer. Remove the battery pack and measure the voltage between battery terminals 1(-) and 5(+). See the following figure : Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 36: Lcd-Related Symptoms

    LCD Assembly. LCD screen unreadable. System board. Wrong color displayed. Horizontal or vertical lines displayed LCD Assembly. on LCD Power-on indicator on, and a blank\LCD LCD Assembly. during POST. System board. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 37: Indeterminate Problems

    If the problem remains, replace the following FRUs one at a time. (do not replace a non-defective FRU) a. LCD Assembly (Check external monitor whether the same problem recurs or not). b. Keyboard. c. Keydeck (TouchPad and Scroll Button Assembly). d. System board. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 38 As for the screw, every Torque 3 ± 0.2Kgfcm(0.196Nm) * The system hinge part apply to 2.5 ㎏fcm. For further information on Removing and Replacing a Part(FRU), refer to Explore view Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 39 Removing and replacing a part (FRU) 1010 Cover Hinge Remove the sheet. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 40 Remove 5 screw. FRU No. Specification FAB31738702 Screw, M2.0 X L1.5 X D4.7 X H0.5 After removing 3 screws, remove cover hinge FRU No. Specification 1SZZBA4080A Screw, M2.0 X L4.0 X D4.0 X H1.0 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 41 Removing and replacing a part (FRU) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 42 Remove the following parts in order before replacing this part a. Cover Hinge(1010) CATUION Remove in a direction towards the Windows logo when you remove the Display Module Remove 1 cable Cable Remove the Display Module. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 43 Cover Hinge(1010) b. Display Module(1020) Remove 5 screws. FRU No. Specification 1SZZBA4080A Screw, M2.0 X L4.0 X D4.0 X H1.0 1SZZBA4041J Screw, M2.0 X L3.0 X D3.3 X H0.3 Remove the Hinge Plate Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 44 Removing and replacing a part (FRU) 1040 Bottom Case NOTE Remove the following parts in order before replacing this part a. Cover Hinge(1010) b. Display Module(1020) c. Hinge Plate(1030) Remove 6 sheet. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 45 Removing and replacing a part (FRU) Remove 6 screw FRU No. Specification 1SZZBA4080A Screw, M2.0 X L4.0 X D4.0 X H1.0 Remove the Rubber. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 46 Separate from the upper hook as if the key deck were raised upwards and then remove the hook clockwise. CATUION When it is disassembled by inserting a jig into the displayed inserting part, the open switch may be broken or lost. Be careful when it is disassembled. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 47 Removing and replacing a part (FRU) Remove the Bottom Case Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 48 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030) d. Bottom Case(1040) After removing battery cable, remove 2 screw Cable FRU No. Specification 1SZZBA4080A Screw, M2.0 X L4.0 X D4.0 X H1.0 Remove the Battery Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 49 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030) d. Bottom Case(1040) e. Battery(1050) After removing 4 cable, remove 3 screw NOTE Disconnect the cable on the USB port board to remove one screw. Cable Cable Cable Cable Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 50 Removing and replacing a part (FRU) FRU No. Specification 1SZZBA4019J Screw, M2.0 X L3.0 X D4.0 X H1.0 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 51 Removing and replacing a part (FRU) Remove the Main board Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 52 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030) d. Bottom Case(1040) e. Battery(1050) f. Main Board(1060) Remove 2 screws. FRU No. Specification 1SZZBA4019J Screw, M2.0 X L3.0 X D4.0 X H1.0 Remove the USB Port Board. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 53 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070) Remove 2 screws. FRU No. Specification 1SZZBA4019J Screw, M2.0 X L3.0 X D4.0 X H1.0 Remove the Ear Jack Cover Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 54 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070) After removing 2 antena cable, remove 2 screws. Cable Cable FRU No. Specification FAB31738702 Screw, M2.0 X L1.5 X D4.7 X H0.5 remove the WLAN Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 55 Removing and replacing a part (FRU) remove the antena cable. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 56: 1090 Sub Board

    Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070) remove the main to sub cable Cable remove 3 screws. FRU No. Specification 1SZZBA4019J Screw, M2.0 X L3.0 X D4.0 X H1.0 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 57 Removing and replacing a part (FRU) remove the Sub Board Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 58 Remove the following parts in order before replacing this part a. Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h Sub Board(1090) remove the Speker Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 59 Remove the following parts in order before replacing this part a. Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h. Sub Board(1090) remove the Ear jack Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 60 If you apply excessive force to separate the LCD, you may give damage to the display. Use a tool to separate while it is prevented from being bent as much as possible. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 61 Removing and replacing a part (FRU) Remove the Rear Case. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 62 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h. Sub Board(1090) i. Ear Jack(1110) j. Rear Case(1120) Remove LCD cable. Cable Cable Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 63 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h. Sub Board(1090) i. Ear Jack(1110) j. Rear Case(1120) Remove the Webcam Cable Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 64 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h. Sub Board(1090) i. Ear Jack(1110) j. Rear Case(1120) Remove the Mic holder. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 65 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h. Sub Board(1090) i. Ear Jack(1110) j. Rear Case(1120) k. LCD Cable(1130) l. Webcam(1140), m. Mic Holder(1150) Remove the Interface Board. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 66 Cover Hinge(1010), b. Display Module(1020), c. Hinge Plate(1030), d. Bottom Case(1040), e. Battery(1050), f. Main Board(1060), g. USB Port Board(1070), h. Sub Board(1090) i. Ear Jack(1110) j. Rear Case(1120) k. LCD Cable(1130) l. Webcam(1140), m. Mic Holder(1150), n. interfase board(1160) Remove the Webcam Holder. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 67: Part Lists

    EBR77975103 Interface Board NLCD04 EBR77975305 LCD Cable (Main to Interface, FPCB) NLCD05 MCQ67394201 Rubber, Cap Screw NLCD06 MHK64073801 Sheet, Cap Screw front NLCD07 EBP61921701 Camera Module NLCD08 MCQ67394001 Rubber, Webcam Holder Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 68 KOREA, AW-NB136NF, Normal LABEL NLAB03 MEZ65270202 KOREA, AW-NB136NF, LTE NLAB03 MEZ65270301 GLOBAL, AW-NB136NF, Normal NLAB03 MEZ65270401 BRAZIL, AW-NB136NF, Normal CUTTING PU Hybrid SYSTEM POCKET NO PRINT NBAG01 MAF63367302 11T540_ 11T740 Pouch Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...

  • Page 69: Explode View

    Explode view Explode view NLCD02 NLCD07 NLCD08 NLCD10 NLCD04 NLCD03 NLCD06 NLCD09 NLCD05 NLCD06 NLCD05 NLCD01 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 70 LCD Cable (Main to Interface, FPCB) NLCD05 MCQ67394201 Rubber, Cap Screw NLCD06 MHK64073801 Sheet, Cap Screw front NLCD07 EBP61921701 Camera Module NLCD08 MCQ67394001 Rubber, Webcam Holder NLCD09 MCQ67394101 MIC Holder NLCD10 SJMY0007120 Vibration Motor Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 71 Explode view Keydeck NKDECK04 NKDECK02 NKDECK03 NLAB03 NKDECK05 NLAB02 NKDECK06 NKDECK06 NKDECK05 NKDECK05 NKDECK01 NKDECK05 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 72 COMPLEX CPU Label Convertible Intel NLAB02 MEZ65058205 Inside(Celeron, Atom) Label, Silver (328478-001) NLAB03 MEZ65270201 KOREA, AW-NB136NF, Normal LABEL NLAB03 MEZ65270202 KOREA, AW-NB136NF, LTE NLAB03 MEZ65270301 GLOBAL, AW-NB136NF, Normal NLAB03 MEZ65270401 BRAZIL, AW-NB136NF, Normal Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 73 Explode view Main NKDECK12 NKDECK10 NMLB02 NMLB01 NMINI01 NMINI03 NKDECK08 NMINI02 NKDECK09 NKDECK07 NKDECK11 NMLB03 NKDECK13 NKDECK14 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 74 NKDECK08 MBG64849701 Button, Power NKDECK09 MBG64827501 Button, Volume NKDECK10 MGJ63671401 EarJack holder NKDECK11 EBR77975203 FPCB, Port (Port Board) NKDECK12 EBR77707202 FPCB, Audio BD NKDECK13 EAA63184901 Antenna, Main NKDECK14 EAA63185001 Antenna, Aux Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 75 Explode view NBOTM03 NBOTM02 NBOTM01 NBOTM02 NADT01 NPWCD01 Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
  • Page 76 1SZZBA4041J Screw, M2.0 X L3.0 X D3.3 X H0.3 NSCR05 1SZZBA4116A Screw, M2.0 X L2.2 X D3.6 X H0.3 CUTTING PU Hybrid SYSTEM POCKET NO PRINT NBAG01 MAF63367302 11T540_ 11T740 Pouch Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
