INSTALLATION MANUAL

MODEL #201019

50A LOAD MANAGEMENT

MODULE

All fleX Controller™ Models

ACTIVATE YOUR WARRANTY

SERIAL NO.

by registering your product:

championpowerequipment.com

or visit championpowerequipment.com

SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be

read and understood before operating the product. Failure to do so could result in serious injury. This

manual should remain with the product.

Specifications, descriptions and illustrations in this manual are as accurate as known at the time of

publication, but are subject to change without notice.

5109-M-OP

REV 20250417

Champion Power Equipment, Inc.

Table of Contents

Need help?

Do you have a question about the 201019 and is the answer not in the manual?

Questions and answers

Summary of Contents for Champion 201019

Page 1 Failure to do so could result in serious injury. This manual should remain with the product. Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice. 5109-M-OP REV 20250417 Champion Power Equipment, Inc.
Page 2: Table Of Contents
201019 - 50A LOAD MANAGEMENT MODULE TAbLE Of CONTENTS TAbLE Of CONTENTS Introduction ..............
Page 3: Introduction
201019 - 50A LOAD MANAGEMENT MODULE INTRODUCTION INTRODUCTION SAfETY DEfINITIONS Congratulations on your purchase of a Champion The purpose of safety symbols is to attract your Power Equipment (CPE) product. CPE designs, attention to possible dangers. The safety symbols, builds, and supports all of our products to strict and their explanations, deserve your careful specifications and guidelines.
Page 4: Important Safety Instructions
201019 - 50A LOAD MANAGEMENT MODULE IMPORTANT SAfETY INSTRUCTIONS IMPORTANT SAfETY The manufacturer cannot anticipate every possible circumstance that might involve a hazard. INSTRUCTIONS The warnings in this manual, tags and decals affixed to the unit are, therefore, not all-inclusive. If using ...
Page 5 201019 - 50A LOAD MANAGEMENT MODULE IMPORTANT SAfETY INSTRUCTIONS  WARNING Be certain that the power from the utility is turned off and all backup sources are locked out before starting this procedure. Failure to do so could result in serious injury or death.
Page 6: Safety And Dataplate Labels
Some of the following symbols may be used on this product. Please study them and learn their meaning. This artwork belongs to Champion Power Equipment. The contents are conﬁdential and privileged and shall not be disclosed to or used by or for outside parties without the explicit consent of Champion Power Equipment.
Page 7: Controls And Features
201019 - 50A LOAD MANAGEMENT MODULE CONTROLS AND fEATURES CONTROLS AND fEATURES Read this installation manual before installing your fleX™ Load Management Module (LMM). Familiarize yourself with the location and function of the controls and features. Save this manual for future reference.
Page 8: Electrical Installation Diagram
201019 - 50A LOAD MANAGEMENT MODULE CONTROLS AND fEATURES Electrical Installation Diagram UTILITY GENERATOR METER CIRCUIT BREAKER* AIR CONDITIONER HOME PANEL LOAD MANAGEMENT MODULE *Lead wire to Home Panel must be connected to a circuit breaker rated for connected load, breaker not to...
Page 9: Installation
201019 - 50A LOAD MANAGEMENT MODULE INSTALLATION INSTALLATION Unpacking Carefully unpack the LMM. Inspect closely for any damage that might have occurred during shipment. Check that all packing material is completely removed from the LMM prior to installation. Handle LMM carefully when installing.
Page 10 201019 - 50A LOAD MANAGEMENT MODULE INSTALLATION 3. Connect the L1 and L2 Line to the top of the 5. Connect the ground to the ground terminal. contactor relay (LINE connections). 6. Max. Torque Line, Load Terminals and Ground 4. Connect the T1 and T2 lines to the bottom of Terminal to 25 in.
Page 11: Connecting The Lmm To The Ats
201019 - 50A LOAD MANAGEMENT MODULE INSTALLATION Setting DIP Switches Replace the cover. The DIP Switches set parameters of the controller. There are 4 DIP switches on the LMM. These are the designated “ON” or “OFF” position settings for the DIP switches;...
Page 12 201019 - 50A LOAD MANAGEMENT MODULE INSTALLATION ATS DIP Switches 1-4 on the fleX ATS control are activated, LMM2 and LMM5 will have the same lockout of the LMM during generator operation. priority, and LMM3 and LMM6 will have the same priority.
Page 13: Settings On The Flex Controller™ Module
201019 - 50A LOAD MANAGEMENT MODULE LOAD TEACHING SYSTEM Settings on the fleX Controller™ 4. After the ATS has learned all loads the LMM units will be returned to normal operation. Module 5. Installation configuration is now held in On the ATS fleX Controller, set the two circular pots...
Page 14: Specifications
201019 - 50A LOAD MANAGEMENT MODULE SPECIfICATIONS SPECIfICATIONS Unit Model ...................... 201019 Service rating .............Energy Management Equipment Enclosure type................Type 3R Outdoor* Maximum Amps ................50A resistive Nominal Volts ..................120/240 ETL Listed - Conforms to ........CAN/CSA Standard C22.2 No. 205 ..............UL916 Energy Management Equipment Load Management Circuits ................
Page 15: Warranty
Champion Power Equipment disclaims any obligation to cover any loss of time, use of this product, freight, two years (parts and labor) from the original date of...
