- Page 1 Watchman 410 Installation Guide Created February 2025 (855) 694-2837 cell-gate.com...
-
Page 2: Table Of Contents
Contents Items Included............Standard Power Wiring..........Solar Power Wiring..........InHand Router............Wiring Blue Board............ Wiegand............Gate Status from Gate Operator....Dry Contact Relay, Normally Open....Dry Contact Relay, Normally Closed..... Wet Contact Relay, Normally Open....Wet Contact Relay, Normally Closed..... Mounting to a Pedestal.......... -
Page 3: Items Included
Items Included • Watchman 410 Unit • Blue Board • InHand Router • 12 Volt DC Power Supply • Keys • Flangenuts 1/4” (x4) • Carriage Bolts 1/4” x 1” (x4) • Customer Information Packet We do not recommend running wires over 60 feet. -
Page 4: Standard Power Wiring
Standard Power Wiring Most devices will be powered using the (PWR-200) 12V DC 5 Amp Transformer. Ensure you wire the positive to the + and negative to the - 12 gauge wire will not fit in the red screw terminal for the power supply. -
Page 5: Solar Power Wiring
When wiring up the SunSaver (PWR-710), follow the order below for connecting each component. 1. Blue Board 2. Battery (x1, not included) 3. Solar Panel (x1) 3. 3. 2. 2. If connecting more than one battery, please contact CellGate Technical Support. (855) 694-2837 cell-gate.com... -
Page 6: Inhand Router
InHand router For Use in W410 Version: AA1TP-ATT / AA1TP-VZN Product ID: M780 Power: Indicates the device is on Status: Indicates device state/troubles Cellular: Indicates device communication Signal: Indicates strength of signal cell-gate.com (855) 694-2837... - Page 7 Not for use with this device Do not remove the SIM card tray unless specifically advised by tech support. The SIM card tray contains both AT&T and Verizon SIM cards. They can only be swapped online by tech support. Cellular 1 & 2: Power Block: 12V DC is WAN / LAN1: Plugs Directly connected to antenna...
-
Page 8: Blue Board
Blue Board Below is the blue board inside the device. It provides power to the router and other accessories, such as cameras. It’s also the central control interface between the faceplate and the router. • Wire main power from transformer to the power connector on the blue board. •... -
Page 9: Wiegand
You will likely need to program the output of the gate operator. Warning: You must wire into a DRY CONTACT the Gate Operator. Applying power to the input on the blue board will damage it. Gate statuses can be inverted. If needed, please call CellGate to invert. (855) 694-2837 cell-gate.com... -
Page 10: Dry Contact Relay, Normally Open
Dry Contact Relay, Normally Open Dry Contact Relay, Normally Closed cell-gate.com (855) 694-2837... -
Page 11: Wet Contact Relay, Normally Open
You must use a diode to maintain warranty. Contact CellGate for diode instructions. Wet Contact Relay, Normally Open Wet Contact Relay, Normally Closed (855) 694-2837 cell-gate.com... -
Page 12: Mounting To A Pedestal
Mounting to Pedestal Gasket is already attached to the back of the device. Corner holes are 5mm in diameter. Attach a 14-gauge grounding wire from one of the carriage bolts to a grounding rod. cell-gate.com (855) 694-2837... - Page 13 (855) 694-2837 cell-gate.com...
