- Page 1 ASSEMBLY INSTRUCTIONS FOR POWER DYNAMICS DECK 750 Read this manual carefully before attempting to assemble the Power Dynamics stage decks. Version 2 , 2025...
- Page 2 ASSEMBLY INSTRUCTIONS: Please check below instructions to insure correct assembling of your stage. All connections such as deck to deck clamp, leg to leg clamp must be fitted properly before using the stage. ASSEMBLY OF THE LEG Place the desired leg in the leg receiver of the stage deck on the underside.
- Page 3 SELF-LEVELING INSERT Align the stage decks using the self-leveling insert. Use 3 pieces on a 2 / 1m deck. 1 piece of leveling insert on the short side and 2 pieces on long side. CLAMP DECK TO DECK Use 3 clamps per deck on the short side and 2 on the long side. Fasten the clamp by turning the knob clockwise.
- Page 4 LEGS TO LEGS CLAMP 2 FEET Use 1 clamp for two legs, position them a maximum of 20 cm below the stage deck. Fasten the clamp by turning the knob clockwise. LEG TO LEGS CLAMP 4 FEET Use 1 clamp for 4 legs, position it a maximum of 20 cm below the deck. Fasten the clamp by turning the knob clockwise.
-
Page 5: Transport And Storage
Make sure to use only original Power Dynamics parts. When in doubt, consult your nearest dealer. The load on the floor where the stage deck has been set up must correspond to the nominal load. - Page 6 SERVICE-INSTRUCTIONS: A visual inspection by appropriately trained persons should be carried out before each use of the stage decks to detect any damage that could affect safety. Visual inspections should be carried out by appropriately trained persons. Devices that are not suitable for further use are to be disposed of in accordance with local regulations. Warning: The use of incorrect accessories can lead to personal injuries and severe damage and failure of components and structural elements.
- Page 7 Contact the manufacturer: POWER DYNAMICS TRONIOS BV Bedrijvenpark Twente Noord 18 7602 KR Almelo www.POWER-DYNAMICS.eu...
