Lumena OBSERVA User Manual

Pir solar flood light (remote control)

Advertisement

Quick Links

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE
If a fitting is found to be damaged, cease use immediately.
Contains batteries – avoid extreme heat/ fire and recycle sensibly – check with your local authority or retailer for further advice.
The unit may get warm whilst on for a period of time.
Always take care when installing your solar light, especially when mounting it in high places.
Secure all cabling, leaving slightly slack.
All connections should be made as watertight as possible to avoid electrical shortage.
Do not modify this fitting or it may void any warranty and result in an unsafe product. Always consult the manufacturer.
Ensure all mounting instructions are followed.
Ensure the fitting is mounted out of range of head height to avoid injury.
The unit will not charge correctly if the panel is behind glass or in artificial light.
SPECIFICATIONS
Wattage: 10W (100W equivalent) // 30W (300W equivalent)
LEDs: SMD 2835 LEDs 1W = 88pcs / 30W = 180pcs (120*60˚ Beam Angle)
Colour Temperature: CCT Switch (3000K / 6000K)
Lumen Output: 1500lm // 4800lm
LED Life Expectancy: 50,000 hours (approx.)
Sensor: PIR (motion sensor) 8m*120˚ detection + Light Sensor (photoreceptor)
Light Sensor LUX Level: ON <20 Lux
Function: Constant On / PIR Mode (Variable – see remote control settings)
IP Rating: IP65 (IP67 Connector Plug)
Cable Length: 5m (approx.) plug & play
Solar Panel: Monocrystalline 10W = 4.5W 6V, 30W = 10.5W 10V
Battery Type: 10W = Lithium Ion 18650 3.7V 3.6Ah 13.32Wh // 30W = LiFePO4 32700 6.4V 6Ah 38.4Wh (replaceable)
Battery Charge Time: 4-6 hours (approx.)
Max Illumination Time at Full Charge: 12-14 hours (varies by function, location, weather & seasonal light conditions)
Illumination Coverage: 10W = ≤80m² // 30W = ≤150m²
Materials: ABS, Polycarbonate, Tempered Glass, Steel (bracket), Stainless Steel (bolts)
Mounting: Surface mount (adjustable brackets) – compatible with ground spike
Recommended Install Height: 2-4m
Recommended Install Distance: 10W = 6-8m // 30W = 10-14m
Remote Control: Infrared (10-12m range) – requires 1 x CR2025 battery (included)
Working Temperature: -10˚C to 40˚C
Features: Built-in IC intelligence with over-charge and over-discharge protection
Included: Flood Light, Solar Panel, 4x M8*60mm Fixings Pack, Remote Control
Dimensions: 10W F: 153*147*32mm S/P: 202*221*24mm // 30W F: 200*175*49mm S/P: 375&256&22mm
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface dirt. To maintain
efficiency, specifically clean the solar panel, floodlight lens and PIR sensor on a regular basis. Also, keep the solar panel free of debris and snow
to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could damage the fitting. Please refer to
our website for more information on the best way to clean different materials.
RETURNS & RECYCLING:
If purchased from a 3
party, please contact your supplier. If purchased direct, contact us by phone or email:
rd
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us for more
information. Please recycle packaging whenever possible.
WARNINGS
OFF >40 Lux (approx.)
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
Full product range & more information: www.lumenalights.com
OBSERVA PIR Solar Flood Light (Remote Control)
Tel: +44 1327 871161
USER MANUAL
OBS10PIR-CCT / OBS30PIR-CCT
GUARANTEE
see website for
Email: sales@lumenalights.com
✔✔✔
3 YEAR
more details
2025-02-19-v1
