- Page 1 Operating Manual Translation Operating Manual SONOREX TECHNIK Air circulation dryer UT Valid for: Air circulation dryers UT 16, UT 40, UT 75 23776-002 en/2025-02...
- Page 2 © 2025 1 2 GmbH & Co. KG, Heinrichstr. 3–4, 12207 Berlin, Germany Phone: +49 30 76880-0, Fax: +49 30 7734699, info@bandelin.com Certified to ISO 9001 and ISO 13485 2 / 22 23776-002 en/2025-02...
-
Page 3: Table Of Contents
Table of contents About this operating manual ....................... 5 Safety ..............................6 Using the device ...........................6 Keep out of reach of children ......................6 Risk of electric shock ..........................6 Danger due to noise emissions ......................6 Danger due to high temperatures ....................7 Interference with wireless communication ................7 Safety stickers on the device ......................7 Not overloading accessories ......................7... - Page 4 Disposal ..............................18 Information about the device ......................19 Technical specifications ........................19 Ambient conditions .......................... 20 CE conformity ............................. 20 4 / 22 23776-002 en/2025-02...
-
Page 5: About This Operating Manual
• Should this operating manual leave any questions unanswered, please contact your specialist dealer or BANDELIN. Notes on service can be found in chapter 6.4 Repairs. In the event that the translation cannot be understood, the German original version of BANDELIN must be followed. -
Page 6: Safety
Safety Safety Using the device The device is intended to rid items that are to be dried of solid, non-combustible materials from residual aqueous liquid. The parts to be dried must be introduced into the air circulation dryer in a basket provided for this purpose. The device is intended for use in the commercial sector. -
Page 7: Danger Due To High Temperatures
Safety Danger due to high temperatures The device and the items to be dried may become hot during operation. Touching them may cause burns. The temperature can be set to up to 140 °C. Very high temperatures can occur during prolonged operation. •... -
Page 8: Construction And Function
Construction and function Construction and function Structure 1 Handles 2 Stainless-steel tank 3 Stainless-steel housing 4 Control panel 5 Feet for a secure footing 6 Outlet for hose socket 8 / 22 23776-002 en/2025-02... -
Page 9: Control Panel
Construction and function 7 Floor drain for discharging dripping water 8 Inlet air openings 9 Suction opening Control panel 1 Yellow pilot lamp Lit up means: heating is switched on 2 White pilot lamp Lit up means: heating is switched on Lit up means: heating control active 3 Turning knob for adjusting the heating temperature 4 Green pilot lamp... -
Page 10: Function
Construction and function Function The air circulation dryer is used to dry cleaned and rinsed wet or moist workpieces. The air, which is heated by means of heating elements, is directed via air ducts specifically onto the objects to be dried in order to achieve rapid drying. A small portion of the recirculating air flow is always exchanged via the device, which is open at the top. -
Page 11: Preparation For Operation
Preparation for operation Preparation for operation Installation site requirements The installation site of the device must meet the following conditions: • The installation surface must be horizontal, firm and dry. • Its load-bearing capacity must be sufficient for the device. For the weight, see chapter 8.1 Technical specifications. -
Page 12: Operation
Operation Operation Putting into service Requirements • Check whether the outlet has been connected to the drain without any kinking. • Check whether there are any foreign objects in the device that could get sucked in. • Check whether there are any parts in the device that are not sufficiently temperature- resistant. -
Page 13: Introducing Items To Be Dried
Operation Introducing items to be dried To achieve a good result, observe the following instructions when introducing items to be dried: • Use suitable accessories, such as a basket or shelf. Do not place items directly on the bottom. • Spread out the items as you insert them. Do not stack them. Sensitive items must not touch other items. -
Page 14: Troubleshooting
Operation Troubleshooting Malfunction Possible causes Troubleshooting The air circulation - One or more heating elements - Contact the manufacturer; see chapter 6.4 Repairs. dryer does not heat have failed or does not become - The thermostat on the device - Switch on the thermostat properly warm is set too low - The time switch is defective... -
Page 15: Maintenance
Maintenance Maintenance Servicing The device does not need to be serviced. Functional tests can be performed for regular checks; see chapter 6.3 Tests. Cleaning and looking after the device Cleaning the housing • Wipe the housing with a damp cloth. Wipe it dry with a soft cloth. •... -
Page 16: Tests
Maintenance Tests If one of the tests does not lead to the desired result, contact the servicing team. See section 6.4 Repairs. Check the control lamps Check the function of the pilot lamps. • Briefly turn the device on. » The green pilot lamp will remain on as long as operation is switched on. •... -
Page 17: Repairs
Fill out the form and attach it so as to be clearly visible on the outside of the packaging. Acceptance will be refused without a completed form. Send the unit to the following address: BANDELIN electronic GmbH & Co. KG Heinrichstr. 3–4 12207 Berlin... -
Page 18: Disposal
Disposal Disposal WARNING Health hazard due to contaminated device - Decontaminate the device before disposal if it has come into contact with hazardous substances. - Also decontaminate accessories before disposal. Dispose of the device properly as electrical waste if it can no longer be used. Do not dispose of the device in the household waste. -
Page 19: Information About The Device
Information about the device Information about the device Technical specifications Mains supply: 400 V 3N~ (± 10%) 50/60 Hz, cable length 2 m Tank: Stainless steel 1.4404, 2 mm, welded Serial number: See type plate on the back of the device Degree of protection: IP 21 Device... -
Page 20: Ambient Conditions
Information about the device Ambient conditions Ambient conditions Overvoltage category: Degree of contamination: Permissible ambient temperature: 20 to 40 °C Permissible relative humidity to 31 °C: Permissible relative humidity to 40 °C: Permissible air pressure: 800 to 1050 mbar No dewing. For indoor operation only. - Page 21 21 / 22 23776-002 en/2025-02...
- Page 22 1 2 GmbH & Co. KG Heinrichstrasse 3 – 4 12207 Berlin Germany Phone: +49 30 76880-0 Fax: +49 30 7734699 info@bandelin.com www.bandelin.com...
