- Page 1 SQA70 ， User s Manual DO NOT LOOK AT SUN THROUGH TELESCOPE. IT WILL CAUSE IRREVERSIBLE DAMAGE TO YOUR EYES. w w w . s h a r p s t a r - o p t i c s . c o m...
- Page 2 E n g l i s h I n s t r u c t i o n s f o r u s e T h e S Q A 7 0 i s a n O T A w i t h a n a p e r t u r e o f 7 0 m m , a f o c a l l e n g t h o f 3 3 6 m m , a n d a n a t i v e f o c a l r a t i o o f 4 .
- Page 3 M 4 2 , M 4 8 , a n d M 5 4 a n d c a n b e u s e d t o m o u n t v a r i o u s a c c e s s o - r i e s . SQA70 Specifications Aperture：7 0 m m Focal length：3 3 6 m m...
- Page 4 Product Size Diagram Dew shield locking screw Tube ring Finder base Rotator thumb screw 360° rotator M48×0.75 Coarse adjustment handwheel 290mm Vixen dovetail plate Coarse adjustment handwheel Fine adjustment handwheel The Locking Screw Position Diagram ②Bottom Load Adjustment Screw ③Bottom Locking Screw ①...
- Page 5 Steps of Installing EAF ② Remove the coarse adjustment ① Remove the thumb screw knob with a 2mm wrench ③ Put the motor bracket on and screw the standard M4 screws into the hole shown, but please do not lock them now. ④...
- Page 6 ⑥ Lock the EAF mounting screws ⑦ Finally, lock the M4 fixing screws ⑤ Insert the EAF(optional) into the flexible coupling and lock the coupling end locking screw Items in SQA70 Packaging SQA70 OTA An Oxford cloth bag An M42 adapter An M54 adapter SQA70 ，...
- Page 7 Official site Facebook YouTube Twitter...
