Summary of Contents for ACOEM PAT
- Page 1 P U L L E Y A L I G N M E N T TO O L USER MANUAL ACOEM...
-
Page 3: Declaration Of Conformity
INTRODUCTION ACOEM PAT uses two laser transmitters for projecting of laser lines on the opposite laser unit. By adjusting the pulleys so that the laser line coincides with the reference line on the opposite laser unit, the pulleys are aligned. - Page 4 Type designation(s)/Model no(s) 1-0671 ACOEM PAT Manufacturer’s name, address, telephone & fax no ACOEM AB, Box 7, SE-431 21 Mölndal, Sweden Tel: +46 31 706 28 00, E-mail: info.se@acoem.com Standard/Test report/Technical construction file/Normative document The following standards and/or technical specifications, which...
-
Page 5: Laser Precautions
Failure to observe the safety pre-cautions and operating instructions can cause bodily injury, fire, and damage to the equipment. Do not disassemble, modify, or use the equipment in other ways than explained in the operating instructions. ACOEM AB will not accept any liability for such use. WARNING! - Page 6 MOUNTING SELECTING V-GUIDES Four sizes of V-guides are supplied to fit pulley grooves of most widths and types. Select the appropriate V-guide according to the V-guide selector. Mount two V-guides on each PAT unit. Pulley groove width...
- Page 8 MOUNTING THE PAT UNITS Place the V-guides of the first unit in the groove of the first pulley and press the unit firmly until the magnet secures it to the pulley. NOTE! The magnet, which holds the unit to the pulley, is very strong.
- Page 9 Ensure that the V-guides has settled correctly in the groove by pushing the units a few millimeters along the groove. Place the second unit in the opposite groove of the second pulley. Position both units facing each other, and in the corresponding grooves.
- Page 10 ALIGNMENT 1. VERTICAL ANGLE ALIGNMENT (TWIST) If the laser lines are not parallel to the center line on the targets (see picture below), there is a vertical angular misalignment. Correct the twist by adding or removing shims on the movable side until the the laser lines are parallel to the center lines.
- Page 11 2. HORIZONTAL OFFSET ALIGNMENT If the laser line on the movable side is parallel to the center line but not in the center, there is a horizontal offset misalignment. Correct the offset misalignment by moving the movable machine in the axial direction until the laser line (on the movable side) coincides with the center line.
- Page 12 3. HORIZONTAL ANGLE ALIGNMENT If the laser line on the stationary side is parallel to the center line but not in the center, there is a horizontal angle misalignment. Correct the angle misalignment by rotationg the movable machine horizontally until the laser line (on the stationary side) coincides with the center line.
- Page 13 Finally, check that the laser line coincides with the center line on both the movable and stationary side. Repeat step 1 to 3 for fine adjustment, if necessary.
-
Page 14: Technical Specification
TECHNICAL SPECIFICATION Housing material: Anodized aluminum frame an ABS plastic. Operating Temp: 0 to 40 °C Storage Temp: -20 to 65 °C Relative humidity: 10 - 90% Weight: 324 g/unit with batteries Dimensions: 61 mm x 77 mm x 61 mm Laser: 650 nm class II diode laser Laser power: <... - Page 16 Publication No. P-0172 © 2024 ACOEM AB, Mölndal, Sweden All rights reserved. No part of this manual may be copied or reproduced in any form or by any means without prior permission from ACOEM AB acoem.se acoem.com...
