INSTRUCTIONS
BALL VALVE series EBVC
BRAZE VALVE
Product Range
EBVC
1
3
Copyright ©SANHUA 2025
Subject to change without notice
Temperature allowed range (TS):
-40°C to +150°C
0%
2
4
2. Welding: If the valve
body is not wrapped
with wet cloth, welding
is prohibited.
1
Design Pressure (PS):
140 bar ( 2030 psi)
C→A POSITION
C→B POSITION
1. Welding: If the valve body
is not in 0% position (C→A),
welding is prohibited.
II-EBVC001CN-R2501
