- Page 1 MANUAL LiFePO BATTERY JARO-BT SERIE > JARO-BT9.12 > > JARO-BT12.12 JARO-BT150.12 > > JARO-BT20.12 JARO-BT60.24 > > JARO-BT60.12 JARO-BT100.24 > > JARO-BT90.12 JARO-BT30.36 > > JARO-BT120.12 JARO-BT100.36 03 / 2024 JAROCELLS.NL...
-
Page 2: Specifications
SPECIFICATIONS JARO-BT BATTERIES Parameter BT9.12 BT12.12 BT20.12 BT60.12 BT90.12 LiFePO LiFePO LiFePO LiFePO LiFePO Battery chemistry 12Ah 20Ah 60Ah 90Ah Capacity Ah 115Wh 154Wh 256Wh 768Wh 1.152Wh Capacity Wh 12,8V Voltage nominal <50mΩ <20mΩ Internal resistance 0 – +45°C Temperature during charging 14,5V±0,2V Voltage during charging Maximum charge current... - Page 3 SPECIFICATIONS JARO-BT BATTERIES Parameter BT120.12 BT150.12 BT60.24 BT100.24 BT30.36 BT100.36 LiFePO LiFePO LiFePO LiFePO LiFePO LiFePO Battery chemistry 120Ah 150Ah 60Ah 100Ah 30Ah 100Ah Capacity Ah 1.536Wh 1.920Wh 1.536Wh 2.560Wh 1.152Wh 3.840Wh Capacity Wh 12,8V 25,6V 38,4V Voltage nominal <20mΩ <40mΩ...
-
Page 4: Safety Guidlines
SAFETY GUIDLINES General safety Attention should be paid to all safety instructions in this manual. Keep the manual located close to the battery for future reference. Maintenance or repair work should only be carried out by qualified personnel. A damaged or abnormal functioning battery should not be used. - Page 5 > A JARO BT battery cannot be overcharged, is protected against over-discharging and will not be damaged when completely discharged. > JARO BT batteries connected in series may only be charged if the have the same charge (equally full) +/-10%. Otherwise, charge them separately with a charger suitable for one battery and then place them back in series.
-
Page 6: Available Information
General All information that is available within the battery about the degree of charge, power consumption, voltage, temperature, etcetera is made available via a wireless bluetooth connection to be read via our JAROCELLS App on an Android or Apple device. -
Page 7: Warranty Provision
What to do if the connection to the battery is lost? “Kill” the JAROCELLS App and restart the App. NOTE: By “Kill the App” we mean that the App must be complete be turned off and not just closed. You do this as follows:... - Page 8 We’ve got the power JAROCELLS B.V., Van Gijnstraat 5b, 2288 GA Rijswijk, The Netherlands. info@jarocells.nl / www.jarocells.nl NEXT GENERATION BATTERY PACKS...
