  • Page 1 SURFACE GRINDERS INSTRUCTION MANUAL AND PART LISTS...

  • Page 2: Preface

    3. Please follow the instruction manual for operation and maintenance. Do not change any circuits, functions and parts of machine without approvals from SHARP. Please note that SHARP will not take any responsibilities for these faults. 4. Since SHARP subscribes to a process of continuous improvement for our products, designs and specifications are subject to change without notices.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PREFACE  TABLE OF CONTENTS  LIST OF FIGURES  CERTIFICATE OF ACCURACY  SAFETY INSTRUCTION  10-12 WARNING  13-14 CONSOLE PANEL  15-18 1. Loading, Unloading and Transportation  2. Unloading Instruction 2.1 Using Fork-Lift Trucks  2.2 Using Cranes or Elevating Platforms ...
  • Page 4 6.1 Please Check the Following Points before the Initial Usage  6.2 To Identify the Input Voltage of Machine is the Same as the Power Supply Source  26-27 7. Working Range, Operator’s Location & Max Load of Table  28-29 8.
  • Page 5 11.5 Grinding Condition 11.5.1 Down Feed Amount for Grinding  11.5.2 Cross Feed Amount for Grinding  11.5.3 Table Longitudinal Traverse  11.5.4 Peripheral Speed of Wheel for Table Traverse  11.5.5 Peripheral Speed of Wheel  11.5.6 Down Feed for Grinding  12.

  • Page 6: List Of Figures

    LIST OF FIGURES ITEM DESCRIPTION PAGE Figure 1.1: Machine Moving Figure 1.2: Machine Moving Figure 1.3: Machine Moving Figure 2: Foundation Plan Figure 3: Longitudinal Movement Operation Figure 4: Grinding Wheel Cross-Movement Figure 5: Hydraulic System Figure 6: Automatic Paper Strip Filter Figure 7: Table Flatness Figure 8:...

  • Page 7: Certificate Of Accuracy

    Certificate of Accuracy MACHINE MODEL: SERIAL NUMBER: MANUFACTURING DATE: TESTING DATE: CONFIRMED BY _______________ SIGNATURE of CHIEF _______________ _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 7...
  • Page 8 ERROR in mm Permissible Test to be applied Figure Table traverse Actual Under 1000mm 1000-2000mm Table flat in 0.02/1000 0.035/1000 longitudinal direction Table flat in 0.02/1000 0.02/1000 transverse direction Straightness of table movement in 0.02/1000 0.02/1000 longitudinal direction Straightness of table movement in 0.02/1000 0.02/1000...
  • Page 9 ERROR in mm Permissible Test to be applied Figure Table traverse Actual Under 1000mm 1000-2000mm True running of 0.005 spindle Perpendicularity of the table longitudinal movement to cross 0.02/300 traverse Vertical travel of wheelhead square 0.01/100 with table in transverse plane Spindle square with 0.02/300 table (Longitudinal)

  • Page 10: Safety Instruction

    SAFETY INSTRUCTION 1. Avoid using any improper work pieces. 2. The grinder can only be operated or maintained by eligible persons who have trained for handling grinding machines. 3. On-site safety training is required for both operators and troubleshooters. 4. The buyer shall remind their operators to follow the safety instructions at all times. Please read the instruction thoroughly before using the machine.
  • Page 11 16. It is obligated to wear gloves while loading sharp work pieces. Please use cranes for loading bigger-sized work pieces, especially the ones are over 25 kg. 17. DONT make any table adjustments while machine is still functioning. 18. Stabilize work pieces before grinding.
  • Page 12 38. SHARP warranty of each machine is based on an 8-hour standard operation per day. If the machine is operating more than 8 hours per day, please note that SHARP has the right to shorten the warranty period to 6-month.

  • Page 13: Warning

    W A R N I N G 1. Turn the wheel spindle CLOCKWISE. 2. The peripheral speed of the wheel should be 2300 m/min or up. 3. The spindle rotation speed should be 1800/1500 (60Hz/50Hz) min¯¹. 4. Max wheel dimension: (GS-25, 30) OD406mm x ID127mm x W25mm.
  • Page 14 DO NOT COMPRESSED AIR to clean the coolant channel and working table because the airborne grits and dusts will damage the slideways. ※ The chuck surface hasn’t been grinded before delivery. Please grind it after proper installation of the machine. ※...

  • Page 15: Console Panel

    Console Panel - CA8211FA (OLD) _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 15...
  • Page 16 Functions of Console Panel (CA8211FA) SA0: Emergency Stop SA3: Cross Feed Forward/Backward Button SA4: Rapid wheel Up/Down Button SA6: Switch for Coolant system SA31: Switch, Cross Feed Auto / Manual / Criss-Cross SA100: Switch for Electro Magnetic Chuck SA111: Button for surface grinding & plunge grinding-AD3 SA112: Wheel rise time, unit second-AD3 SA120:...
  • Page 17 Console Panel – CA8211ED (Standard) _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 17...
  • Page 18 Functions of Console Panel – CA8211ED (Standard) SA0: Emergency Stop SA3: Cross Feed Forward /Backward Button SA4: Rapid wheel Up/Down Button SA6: Switch for Coolant system SA31: Switch, Cross Feed Auto / Manual / Criss-Cross Switch for Electro Magnetic Chuck SA100: Button for surface grinding &...

  • Page 19: Loading, Unloading And Transportation

    1. Loading, Unloading and Transportation 1.1 The machine should be loaded / unloaded by fork-lift trucks, cranes, or elevating platforms. DONT put rolling bar under the bottom of machine. 1.2 All clamps, clamp bolts, and anti-sliding wooden blocks for transition CANNOT be removed until the machine is completely installed.

  • Page 20: Unloading Instruction

    2. UNLOADING INSTRUCTIONS 2.1 Using Fork-lift Trucks Release the packing box from the fixative devices. Unload the packing box by fork lift. Uncrate the machine Position the machine at the foundation. Set up the machine. Note: The capacity of fork-lift trucks depends on the gross weight of machines. _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 20...

  • Page 21: Using Cranes Or Elevating Platforms

    2.2 Using Cranes or Elevating Platforms Release the packing box from the fixative devices. Unload the packing box by crane or elevating device. Uncrate the machine. Position the machine at the foundation. Set up the machine. Note: The capacity of cranes or elevating platforms depends on the gross weight of machines. _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 21...

  • Page 22: Safe Installation

    3. Safe Installation 3.1 Location: It is important to install the grinding machine at the proper site to obtain high accuracy. An ideal location is as followings: 3.1.1 The best location for the machine is where has the least temperature variations. 3.1.2 Avoid installing the machine in a place where the nearby machines may splash cutting chips.

  • Page 23: Foundation Plan

    4. Foundation Plan Figure 2 Foundation Plan _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 23...

  • Page 24: Lubrication, Hydraulic Oil And Maintenance

    5. Lubrication, Hydraulic Oil and Maintenance 5.1 Recommended Brands 5.1.1 Lubrication Oil MOBIL： Vactra No.2 SHELL： Tonna S-68 (V-68) BP： Maccurat D-68 ARAL： Deganit BW-68(B68) CASTROL： Magna BD-68 ESSO： Fibis K-68 5.1.2 Oil for hydraulic system MOBIL： Vacuolinel oil 1409 SHELL：...

  • Page 25: Capacity Of Hydraulic Motor, Oil Tank Capacity And Lubricant

    5.3 Capacity of Hydraulic Motor, Oil Tank Capacity and Lubricant MODEL HYDRAULIC MOTOR OIL TANK CAPACITY LUBRICANT CAPACITY PSGS-2045H 1 HP 60 L PSGS 1 HP 60 L PSGS 2 HP 90 L PSGC 5 HP 120 L 20 L PSGO 5 HP / 7.5 HP 150 L...

  • Page 26: Before The Initial Usage

    6. Before the Initial Usage 6.1 Please check the following points before the initial usage: All power lines connected with the power terminal properly and correctly. Motors & pumpers are turning on the right direction. C. Machine is properly grounded. D.
  • Page 27 should move forward to the operator. If not, please switch any two wires of U3, V3, and 6.2.8 Pressing "SA4" down, the grinding head should move upward. Pressing "SA4" and"SB40" buttons simultaneously will make the grinding head to move downward. If not, please switch any two wires of U4, V4, and W4.

  • Page 28: Working Range, Operator's Location & Max Load Of Table

    7. Working Range, Operator’s Location & Max Load of Table POSITION DIMENSION (mm) OVERALL LENGHT GC50100: 5200 GC60120: 6000 GC50120: 6000 GC60150: 6700 GC50150: 6700 GC60220: 8200 OVERALL WIDTH GC50 :3500 GC60 :3700 _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 28...
  • Page 29 OVERALL HEIGHT 3000 Max Load of Table (Magnetic chuck included) GC50100 : 1600 kg GC60120 : 1880 kg GC50120 : 1880 kg GC60150 : 1880 kg GC50150 : 1880 kg GC60220 : 2000 kg NOTE: The intensity of lighting shall be 300 (lux) at least on the contacted surface between the wheel and the work-piece in the working area.

  • Page 30: Concise Grinding Operation

    8. Concise Grinding Operation 8.1 Grinding Operation 8.1.1 Turn "SA0" clockwise and press "SB1" button to turn on the machine. 8.1.2 Press "SA100" switch to turn on the magnetizing chuck. 8.1.3 Adjust table dogs T1& T2 in order to get the ideal setting distance. 8.1.4 Press "SB21"...

  • Page 31: Functions Of Grinding Wheel Cross-Movement

    Figure 3 Longitudinal Movement Operation 8.3 Functions of Grinding Wheel Cross-Movement 8.3.1 Manual Cross-Movement 8.3.1.1 Manual function is always available whether the table is moving or not. 8.3.1.2 Turn the handle wheel to the left - the grinding wheel will move toward to the operator.
  • Page 32 8.3.2.5 When a trip dog touches the limit switch "LS1" or "LS2", the rapid cross moving function will stop immediately. 8.3.3 Intermittent Cross-Movement 8.3.3.1 The function is only available when the table is moving. 8.3.3.2 Turn "SA31" knob to the right. 8.3.3.3 Turn "SA3"...

  • Page 33: Functions Of Grinding Wheel Movement

    Figure 4 Grinding Wheel Cross-Movement 8.4 Functions of Grinding Wheel Movement 8.4.0 Manual Upward/Downward Movement 8.4.0.1 The function is always available whether the table is moving or the cross movement is working. 8.4.0.2 Turn the handle wheel to the left - the grinding wheel will move upward. 8.4.0.3 Turn the handle wheel to the right - the grinding wheel will move downward.

  • Page 34: Hydraulic System

    8.4.1.2 Turn "SA4" knob to the right - the grinding wheel will move upward. 8.4.1.3 Turn "SA4" knob to the left and "SB40" button simultaneously - the grinding wheel will move downward. AD3 Upward/Downward Movement – Electrical Panel No. CA8211FA Optional 8.4.2 8.4.2.1 Turn "SA0"...
  • Page 35 8.5.3 Steps to check oxidation and aged hydraulic oil: Step 1: Drop a tiny amount of oil on the filter paper Step 2: If the color of the oil appears bright yellow on the filter paper, which means the oil is still clean for usage. On the contrary, if the color result is dirty, it indicates the oil have to change immediately.

  • Page 36: Figure 5: Hydraulic System

    Figure 5: Hydraulic System 1. Oil Filter (MF-12) 9. Hydraulic Hoses (**) 2. Hydraulic Pump (DVM-1V) 10. Main Spool chamber (PST-04) 3. Electric Motor (5H x 6P) 10a. Flow Control Valve (PST-04) 4. Pressure Gauge (0~70kg/cm²) 10b. Directional Control Valve (PST-04) 5.

  • Page 37: Cooling System

    Cooling system Advantages of wet grinding are as below: 8.6.1 Reduce the possibility of deformed work pieces because of overheating. 8.6.2 Reduce the risk of scorched surface on the work pieces. 8.6.3 Grinding grit on the wheel can easily come off. 8.6.4 Save grinding time.

  • Page 38: Figure 6: Automatic Paper Strip Filter

    Milacron Cimtech 200 Fuchs Ratak Synthan 47 Mobil Kuhlschmierst off 166 or 193 Oemeta Unimet RD Shell Metaline Fluid GR ⚫ The main cause of peeling-paint is due to the nitrite and glycol contained in the water-based fluid. ⚫ Please use the recommended synthesis cutting oils. 8.6.11 Automatic Paper Stripe Filter Figure 6: Automatic Paper Stripe Filter...

  • Page 39: Machine Level Adjustments

    9. Machine Level Adjustments Machine leveling is a very important task not only for the precision of the machine but also for the accuracy of work-piece. Therefore, using the spirit level is strongly recommended. The finished accuracy should be within 0.02 mm/m, 200mm in length for the machine level adjustment.

  • Page 40: Straightness Of Table Motion

    9.2 Straightness of Table Motion 9.2.1 Repeat step 9.1.1 to 9.1.4. 9.2.2 Move spirit levels to the right and left positions by table motion to compare with the reference points. Straightness tolerance of table movement in both directions is 0.02/1000mm under 1000mm or 0.02/1000mm under 1000mm-2000mm or less.

  • Page 41: Figure 10: Straightness Of Table Motion

    9.2.4 Read out the indicator when the column gets to its front and back positions. Please refer to Figure 10 below. The parallelity tolerance should be below 0.01/300mm. Figure 10 9.2.5 Repeat 9.2.3 9.2.6 Read out the indicator when the table gets to its right, middle and left positions.

  • Page 42: Maintenance

    10. Maintenance INTERVAL MAINTAINING POINTS REMARKS Working Table Surface To keep the surface clean and with oil is a necessity after working hours. Each Time Re-adjust the wheel balance and re-clean up Grinding Wheel the inner hole of wheel flange and the spindle.

  • Page 43: Wheel Mounting

    11. Wheel Mounting & Dismounting, Balancing, Wheel Inspection and Grinding Condition Figure 11: Wheel Mounting 11.1 Wheel Mounting 1. Check and inspect the wheel. The inspection progress is listed at Section D below. 2. Insert the wheel (Part ) into the body of flange (Part ). 3.

  • Page 44: Wheel Dismounting

    11.2 Wheel Dismounting 1. Open the wheel cover and loose the spindle fixed bolt (Part ) by turning clockwise. 2. Dismount the wheel from the spindle by using the wheel extractor (Part ). 3. Loose screws (Part ) to separate the flange body (Part ) from the flange lock nut (Part ).

  • Page 45: Figure 12A: Wheel Balancing

    11.3.4 Steps for wheel balancing (Figure 13) 11.3.4.1 Adjust levels of wheel balance with spirit. Please refer to Figures 12A & 12B. _________________________________________________________________________________________________ INSTRUCTION MANUAL Page 45...

  • Page 46: Figure 13: Correcting The Level Of Wheel Balance With Spirit

    11.3.4.2 In order to find out the center of gravity, please lay the wheel to oscillate. Mark its downward position S as shown in Figure 13. 11.3.4.3 Move the first balance weight G opposite to point S. 11.3.4.4 Equally distribute two correction weights K to a certain distance. (Figure 13) 11.3.4.5 Turn the wheel 90 degrees and to check whether it is in balance.

  • Page 47: Wheel Inspection

    11.4 Wheel Inspection Before using the wheel, please make sure there are no cracks on the surface of the wheel. After the visual inspection, please use the following “ring” inspection to re-confirm the good condition of the wheel before usage. 11.4.1 Ring Inspection Step 1 - For smaller and lighter wheel, the inspector can insert his finger or a small wooden...

  • Page 48: Recommended Brands For Wheels

    11.4.2 Recommended Wheels Surface Grinding The shape of horizontal wheel The shape of vertical wheel Hardness under 206-355 356-510 Cylinder / Segmental Ring wheel wheel Carbon Under WA 46K WA 46J WA 36J WA 30J WA 24K Steel Steel HRC25 (SS, S-C, S-CK, Over WA 46J...

  • Page 49: Grinding Condition

    * The calculated speed can not exceed the maximum safe operating speed indicated on the wheel. * The standard wheel dimension is 14" (O.D.) x 5" (I.D.) x 2" (T). The maximum wheel outer diameter is 16”. 11.5 Grinding Conditions 11.5.1 Down Feed Amount for Grinding Down Feed Amount...

  • Page 50: Peripheral Speed Of Wheel

    11.5.5 Peripheral Speed of Wheel: 20~30m / sec Wheel Fast Slow Conditions Grinding Resistance Small Large Heat Produced Much Less Surface Finish Fine Rough Wheel worn-out Small Great Safety Better Material Peripheral speed Steel 20~30 m/sec Cast Iron 20~18 m/sec Tungsten Carbide 8~18 m/sec...

  • Page 51: Directional Control Arm Adjustment

    12. Directional Control Arm Adjustment If the table of the machine moves to the very end of one direction and is not able to be reversed by hydraulic system, it indicates a situation the direction control arm L2 which has been separated from the original point and needs to be re-adjusted again.
  • Page 52 Step 1: Release the fixed screwdriver L5 after making a mark at the point where the directional control arm L2 stopped. Step 2: Follow Figure 15D to loose Arm L2. Step 3: Turn the direction of the directional control arm L2 opposite to the table direction. (e.g.

  • Page 53: Cross Traverse Setting System

    13. Cross Traverse Setting System 13.1 Manual Cross Traverse Setting System LS1, LS2: Limit Switch for Max Cross Feed Stroke Safety Control LS3, LS4: Limit Switch for the Adjustment of Cross Feed 13.2 Function and Operation of Electric Touch Cross Traverse Setting System A: The advantage of this user-friendly electronic ‘one-touch’...

  • Page 54: Electromagnetic Chuck

    14. Electromagnetic Chuck An electromagnetic chuck is an indispensable attachment for surface grinding machine. It requires a perfect flat mounting surface to be clamped onto the machine table; otherwise, table will be subjected to disformation due to the huge magnetic attracting force of chuck. The following practice must be followed to grind the mounting surface of magnetic chuck before it is clamped onto the machine table.
