Shooter Lane Ramp Correction:
There have been a small number of games that
were shipped with an incorrect bend in the Shooter
Lane Ramp. This incorrect bend puts the wrong
trajectory on the ball, resulting in the ball not
properly travelling to the gate or around the Top
Lane.
Directions.
1. Print this document. When printing, check the
box to print the page at actual size.
2. After printing, measure the 1 inch box on page 4
to confirm the page was printed at 1=1 scale.
Advertisement
Related Manuals for Chicago Gaming ATTACK from MARS
Summary of Contents for Chicago Gaming ATTACK from MARS
- Page 1 Shooter Lane Ramp Correction: There have been a small number of games that were shipped with an incorrect bend in the Shooter Lane Ramp. This incorrect bend puts the wrong trajectory on the ball, resulting in the ball not properly travelling to the gate or around the Top Lane.
- Page 2 3. Remove the two screws that hold the Shooter Lane Ramp to the playfield. You can remove the Shooter Lane Ramp without removing the wire ramp above it. 4. Place the Shooter Lane Ramp on the edge of a table, as shown below. Align the Shooter Lane Ramp so the bend in the bracket is sitting right on the corner of the table.
- Page 3 Kicker Bracket Alignment Correction: If the Kicker Bracket Assembly is not aligned correctly, it can hit the ball off center and cause it to rattle in the shooter lane. Check that the plunger is aligned to the center of the ball.
