EZ-Path 44 Series Installation Instructions

Optional Ground Attachment
1
Cut hole in the wall. Refer to table A for
opening requirements.
4
Install one small plate onto left side of
the first EZ-Path
®
Note: For more information on firestop installation, refer to ASTM E3157.
I N S T A L L A T I O N
2
Align intumescent tape/gasket (provided) with
bottom edge of flat, solid surface of each wall
bracket. Peel back paper to expose pressure
sensitive adhesive and adhere gasketing to
each bracket prior to installation
device.
Specified Technologies Inc.
Somerville, NJ 08876 USA
T: (800) 992-1180
F: (908) 526-9623
www.stifirestop.com
Series 44+ EZ Path
x1 x4
x4
Hardware Kit PN5052 x1:
x8
TABLE A: OPENING DIMENIONS
Number of
Devices
2
3
4
5
I N S T R U C T I O N S
Vertical Multi-Gang Wall Bracket
®
(Part Number: EZP544WV)
x4 x4
x4
Hardware Kit PN5054 x4:
x8 x8
Parts Included (Not to Scale)
3
Assemble wall plates using included
nuts and bolts.
Height
9-3/8"
14"
18-5/8"
23-1/4"
Page 1 of 2
Warranty: www.stifirestop.com/legal/warranty
Made in USA • Printed in USA
ZIS1310 02121
x1
x4
x4
Width
4-3/4"
4-3/4"
4-3/4"
4-3/4"
