Indirect, gas/oil-fired, industrial air handler
Hide thumbs Also See for Combat IDF Series:
Table of Contents

Advertisement

Quick Links

Download this manual
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. DO NOT try to light any appliance.
3. DO NOT use electrical switches.
4. DO NOT use any telephone in
your building.
5. Extinguish any open flame.
6. Leave the building.
7. Immediately call your local fuel
supplier after leaving the building.
Follow the fuel supplier's
instructions.
8. If you cannot reach your fuel
supplier, call the Fire Department.
WARNING
Fire Hazard
Keep all flammable objects, liquids and
vapors the minimum required clear-
ances to combustibles away from
equipment.
Some objects will catch fire or explode
when placed close to equipment.
Failure to follow these instructions can
result in death, injury or property
damage.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can result in death, injury or property
damage. Read the installation, operation and service
manual thoroughly before installing or servicing
this equipment.
Installation must be done by a registered installer/
contractor qualified in the installation and service of
gas/oil-fired heating equipment or your fuel supplier.
NOT FOR RESIDENTIAL USE
© 2012 Roberts-Gordon LLC
Combat
Indirect, Gas/Oil-Fired,
Industrial Air Handler
Installation, Operation &
Please take the time to read and understand
these instructions prior to any installation.
Installer must give a copy of this manual to the owner.
Keep this manual in a safe place in order to provide
your serviceman with necessary information.
Roberts-Gordon LLC
1250 William Street
P.O. Box 44
Buffalo, New York 14240-0044
Telephone: +1.716.852.4400
Fax: +1.716.852.0854
Toll Free: 800.828.7450
www.robertsgordon.com
www.rg-inc.com
IDF-Series
®
Service Manual
IDF 35
IDF 45
IDF 50
IDF 65
IDF 75
IDF 85
IDF 100
IDF 125
IDF 150
Installer
Owner
P/N 131100NA Rev A 11/12
IDF 175
IDF 200
IDF 225
IDF 250
IDF 275
IDF 300
IDF 350
IDF 400
IDF 450
