- Page 1 cWORK Worklight Series & cRUN Running Light Series Installation Manual Energy Efficient LED Engine Worklight and Running Lights...
- Page 2 The cWORK & cRUN Series Energy Efficient LED Light Engine Worklights and Running Lights CAREFULLY READ THE INSTALLATION INSTRUCTIONS BEFORE USING THIS FIXTURE. The document provides the standard installation instructions for a qualified, trained systems integrator or electrical contractor. Please read all warnings, notices, and instructions in this guide before installing or using this product.
-
Page 3: Power Requirements
BEFORE YOU GET STARTED, PLEASE READ THESE INSTALLATION INSTRUCTIONS COMPLETELY. WARNINGS WARNING: You must have access to a main circuit breaker or other power disconnect device before installing any wiring. Be sure that power is disconnected by removing fuses or turning the main circuit breaker off before installation. Installing the device with power on may expose you to dangerous voltages and damage the device. -
Page 4: What's Included In The Box
BEFORE YOU GET STARTED, PLEASE READ THESE INSTALLATION INSTRUCTIONS COMPLETELY. INSTALLATION INSTRUCTIONS FOR THE cWORK AND cRUN WHAT’S INCLUDED IN THE BOX cWORK White Unit cRUN Blue Unit CONNECTING POWER The cWORK/cRUN is supplied with a 1 - meter TRUE1 Connector. This cable can be connected to any single-phase 120 VAC power source. The cWORK/cRUN TRUE1 input/output connection is at the rear of the unit. - Page 5 BEFORE YOU GET STARTED, PLEASE READ THESE INSTALLATION INSTRUCTIONS COMPLETELY. CONNECTING Note: Note: After inserting properly The proper twist-lock Note: as in illustration A, twist is achieved when the SAFETY WARNING: When connecting, the cable connector silvery tab is in the Incorrect insertion may match the notch on the clockwise to lock.
-
Page 6: Adjusting Tilt
INSTALLATION INSTRUCTIONS FOR THE cWORK AND cRUN: (CONTINUED) MOUNTING The cWORK/cRUN is simple to install and position where work lighting is needed. The unit should be installed with a C-Clamp and Safety Cable. (Supplied by others). When mounting the cWORK/cRUN, you must follow and abide by all national and local codes for safe installation and use. - Page 7 CHANGING THE REFLECTOR ON THE cWORK AND cRUN: STEP 1 Place the cWORK/cRUN on a flat surface. Using a number 1 Phillips screwdriver, remove the 4 screws circled in red. Keep those screws, they will need to be reinstalled when the reflector has been changed. Reference Figure 1. STEP 2 Remove side panel and set it aside.
-
Page 8: Special Cleaning And Care Instructions
CLEANING AND CARE INSTRUCTIONS FOR THE cWORK AND cRUN WARNING! All cleaning should be performed with power completely shut off at the break box or unplugged from the AC outlet. Never remove protective covers from luminaire when powered. Wear appropriate protective eye wear and gloves when cleaning the fixture.
