Summary of Contents for Accsoon CoMo SE

Page 1 2.4GHz User Manual...
Page 2: Table Of Contents
CONTENTS Packaging List Product Description Product Features Instruction Accsoon CoMo SE First Use Volume Control Indicator Status and Voice Prompt Specifications Warranty After Sales Safety Information Contact Us FCC Interference Statement...
Page 3 包装内容产品特征产品简述使用说明认识产品使用声音调整耳机状态与提示音参数表格常见问题质保说明售后说明安全信息联系我们...
Page 4: Packaging List
1. Packaging List Accsoon CoMo SE (1 host headset, 4 remote headsets) package includes: Host headset × 1 Remote headset × 4 Battery × 5 Battery charger × 1 Battery storage box × 1 Headset ear Microphone cushion × 5 windscreen ×...
Page 5 Accsoon CoMo SE (1 host headset, 2 remote headsets) package includes: Host Headset × 1 Remote headset × 2 Battery × 3 Battery charger × 1 Battery storage box × 1 Headset ear Microphone cushion × 3 windscreen × 3...
Page 6 Accsoon CoMo SE (single headset) package includes: Headset × 1 Battery × 1 User manual × 1 Headset ear Microphone cushion × 1 windscreen × 1...
Page 7: Product Description
SE provides a 400-meter (1312 ft) line-of-sight connection range and at least 30 hours of noise-free communication, all without the need for a base station. The Accsoon CoMo SE is the perfect team communication solution, offering added convenience and superior connectivity.
Page 8 External Battery slot antenna Pairing button Firmware update port Microphone boom Indicator Microphone ENC switch Power switch...
Page 9: First Use
First Use STEP 1 As the picture shown, open the battery slot and put in the battery. STEP 2 Push the host and remote headsets’ power switch to “ON”, the headset will be powered on and play “Power Slow green flicker On”...
Page 10: Volume Control
· As the picture shown, when the microphone boom is placed at【±45°】, the indicator will remain on with red light and the microphone will be muted. · To turn on the microphone, push the microphone boom forward to 45° the indicator will remain on with a green light. · You will hear a “Toot” voice prompt, when the microphone is turned on/off. Note：Maximum swivel angle of the boom shaft【±115°】 Volume Control 1.
Page 11: Indicator Status And Voice Prompt
Indicator Status and Voice Prompt Manual Instruction Indicator Voice Prompt Disconnected： Push the power switch to Slow green flicker Power on “ON” Connected： Green light stays on Push the power switch to Indicator off “OFF” Lift up the mic boom： Mute on: Mic mute on Red light stays on...
Page 12: Specifications
5. Specifications Label Description Communication 1312ft / 400m (with no barriers and interference) Range Battery Capacity 2320 mAh (single battery) Operating Time 30 hours Frequency 2.4GHz Signal-to-noise >65dB Ratio Microphone Type Electret Communication 16KHz/16bit Sampling Rate Weight 237g (Single headset with battery) Dimension 241.8 x 231.5 x 74.8 mm (single headset) Operating...
Page 13: Faq
6. FAQ 1. Connection Drops 1. If the host headset is powered off, or the distance between the host and the remote headset is too far, the remote headset will be disconnected from the host, and the indicators on the remote headsets will turn into slow green flickers and play “Disconnected” voice prompt. When the host and remote headsets are not in connection for longer than 30 minutes, the headsets will automatically power off. 2. When the remote headsets are disconnected from the host headset, you can reconnect the headsets by powering on the host headset or put the host and remote headset back into the communication distance, the remote headsets will automatically reconnect to the host headset. Remote headset’s indicator will stay on with green light and will play “Connected” voice prompt. 2. Pairing and Host Headset Memory Clearing 2.1 Pairing PAIR Fast green flicker 1. Switch the power button on both the host and remote headsets to “ON”. 2. Press and hold the pairing button on the host headset for 3 second s to enter pairing mode. The indicator will show quick green flickers, with no prompt voice. 3. Press and hold the pairing button on remote headsets for 3 seconds to enter pairing mode. The remote headsets will play “Pairing” voice prompt, and the indicator will show quick green flickers.
Page 14 Note: Please ensure you exit pairing mode before using Accsoon CoMo SE for communication. 2.2 Memeorize Pairing Information Host headset × 1 remote headset × 4 1. One host headset can connect and memorize 4 remote headsets at the maximum. If your host headset's memory isn't fully used, you can follow guideline 2.1 to pair and add new remote headset(s). 2. A single remote headset can only store pairing information of one host headset at a time. To pair it with a new host headset, please follow the instructions in guideline 2.1. Note: If you have multiple Accsoon CoMo SE host and/or remote headsets, follow guideline 2.1 to arrange the pairing memory of each host/remote group. Multiple separate groups of Accsoon CoMo SE can work in the same place without interference. 2.3 Pairing Overtime The pairing mode will last for 120 seconds. The headsets will automatically exit pairing mode, if host/remote headsets are unable to pair up within the time limit, follow guideline 2.1 to restart pairing.
Page 15: Warranty
7. Warranty Warranty Period 1. Within 15 days after receiving the product, Accsoon provides replacement or complimentary maintenance for product quality-related issues. 2. Under proper use and maintenance, from the date of receipt, Accsoon provides a one-year warranty on the product (headsets and the charger) and a three-month warranty for batteries.
Page 16: Safety Information
(www.accsoon.com). 2. You can get detailed solutions from authorized dealers or Accsoon. 3. Accsoon reserves the right to review the damaged product. 9. Safety Information 1. When operating this equipment, read and follow all the instructions in this manual.
Page 17: Federal Communication Commission Interference Statement
10. Federal Communication Commission Interference Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 19 一、包装内容迅声 2.4G（一拖四）包装内含 : 主控耳机 × 1 从属耳机 × 4 电池 × 5 充电器 × 1 电池收纳盒 × 1 耳机海绵套 × 5 麦克风海绵套 × 5 单耳机收纳袋 × 5 收纳包 × 1 用户手册、合格证 × 1...
Page 20 迅声 2.4G（一拖二）包装内含 : 主控耳机 × 1 从属耳机 × 2 电池 × 3 充电器 × 1 电池收纳盒 × 1 耳机海绵套 × 3 麦克风海绵套 × 3 单耳机收纳袋 × 3 收纳包 × 1 用户手册、合格证 × 1...
Page 21 迅声 2.4G（单只）补充耳机内含：耳机 × 1 电池 × 1 用户手册、合格证 × 1 耳机海绵套 × 1 麦克风海绵套 × 1...
Page 22 二、产品简述感谢您购买致迅迅声 2 . 4 G ，全双⼯⽆线降噪通话系统。迅声 2.4 G 是致迅推出的新一代无线通话系统，运行于 2.4 G H z 频段，摆脱了传统全双工耳机对中心基站的依赖，实现了主控耳机与最多四...
Page 23 天线电池仓配对按钮固件升级口柔性麦杆指示灯麦克风降噪开关电源开关...
Page 24 使用 STEP 1 如图所示，打开电池仓，装配电池。 STEP 2 拨动主从耳机电源开关至 ON，耳机开机发出提示音“开机”，此时主从耳机指示灯均绿灯慢闪绿灯慢闪。 STEP 3 打开主从耳机配对连接。 · 主从耳机连接，出厂时当前主控耳机与从属耳机为已配对状态。 · 从机发出“连接成功”提示音，表示主从耳机已连接。 STEP 4 静音 / 通话 · 如图所示，麦杆处于 ±45°以内时，麦克风为关闭状态，此时指示灯红色常亮。 ·...
Page 25 注转轴的最大转动角度为 ±115° 声音调整 1. 按下耳机侧面的“+”“-”按键即可实现对耳机音量的调节。 2. 耳机上的“+”“-”按键仅对通话音量生效，不会影响麦克风的收音效果。如需调整麦克风收音，可直接调整麦克风与声源的距离。 3. 通话音量等级共有五档，出厂默认为第三档，耳机对音量调整具有记忆功能。 4. 开机状态下，系统默认开启通话降噪功能，可手动按下降噪切换键关闭 / 打开通话降噪功能。降噪（ENC）...
Page 26 耳机状态与提示音操作指示灯状态提示音未连接：绿灯慢闪电源开关拨动至 ON 开机已连接：绿灯常亮电源开关拨动至 OFF 指示灯熄灭抬上麦杆：静音静音状态红灯常亮嘟嘟打下麦杆：正常通话状态绿灯常亮调整通话音量至最大 / 嘟嘟小值常亮连接完成连接成功（颜色跟随麦杆状态）断连绿灯慢闪断连（仅从机）配对绿灯快闪配对中常亮配对成功配对成功（颜色跟随麦杆状态）单击“降噪”键，循环降噪开启：降噪开切换降噪关闭：降噪关电量低于 10% 红灯慢闪...
Page 27 五、参数表格功能 / 性能描述传输距离无障碍无干扰环境下≥ 400 米电池容量 2320mAh（单节电池）工作时间约 30 小时工作频率 2.4GHz 信噪比 >65dB 麦克风类型驻极体通话采样率 16KHz/16bit 自重 237 克（含电池）尺寸 241.8 x 231.5 x 74.8 mm（单只耳机）工作温度 -15~45° C...
Page 28 六、常见问题 1. 断连与恢复连接 1. 若主控耳机电源关闭，或从属耳机超出主控耳机传输范围，则会发生断连状况，此时从属耳机指示灯由绿灯常亮转绿灯慢闪，耳机发出断连提示：“断连”，如断连时间超过 30 分钟，主从耳机将会自动关机。 2. 若当前主从耳机已经断连，可依据当前断连状态，采取主从耳机开机，或将主从耳机恢复到正确通讯距离以重新恢复通信。此时主从耳机将自动连接，从属耳机指示灯恢复为绿灯常亮，耳机发出连接提示音：“连接成功”。 2. 配对与清码 2.1 配对配对（PAIR）绿灯闪烁 1. 拨动主控耳机电源开关至“ON”， 4. 从属耳机发出“配对成功”提示音，使所需配对的主从耳机开机。表明从属耳机和当前主控耳机配对成功，从属耳机指示灯绿灯慢闪。 2. 长按主控耳机的“配对”按键 3 秒，...
Page 29 2.2 配对记忆主机从机 × 4 1. 主控耳机至多与四台从属耳 2. 从属耳机只能记忆一台主机配对。若当前主控耳机处于控耳机的信息。若需重新配未...
Page 30 3. 未在质保范围内的（配套耳罩、咪头罩、一次性耳罩、收纳袋以及收纳包 / 箱）。 4. 未经授权的维修、拆解。 5. 因火灾、水灾、雷击等不可抗力造成的损坏。八、售后说明 1. 如产品需要售后，可联系当地致迅授权经销商，如无当地授权经销商可以通过致迅公司邮箱（support@accsoon.com）或网站（www. accsoon.cn）与客服取得联系并获得相应支持。 2. 致迅经销商或致迅客服会告知您如何运送相关产品及如何处理您的保修问题，致迅公司保留复查损坏产品的权利。九、安全信息 1. 操作本设备时，请阅读并遵循本手册中的所有说明。 2. 只能使用 Accsoon 指定或推荐的附件 / 电池 / 充电器。...
Page 31 十、联系我们官方网站官方客服微信微信公众号 Bilibili...
Page 32 2024 www.accsoon.cn 2024...
