    English Installation Instruction UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged. Do not use damaged or defective parts.
  • Page 3 Supplied Par ts List (1)Wall Plate-a (1)VESA 200 Plate-b (4)M4x12 Bolt-c (4)M4x30 Bolt-d (4)M6x12 Bolt-e (4)M6x35 Bolt-f (8)M4 Washer-g (6)M6 Washer-h (4)M4/M6 Space-i (2)M6x10 Bolt-j (4)Lag Bolt Washer-k (4)Lag Bolt-l (4)Concrete Anchor-m CAUTION! This TV mount must be securely attached to the vertical wall.
  • Page 4 Mounting the Wall Plate to the Wall Step 1 Brick Mount 50mm 40mm Wood Mount 50mm 3.8mm...
  • Page 5 Mounting the VESA 200 Plate to a TV Step 2 d,f g,h This way up! This way up! For Flat Back TV For Curved Back TV Attaching TV to Wall Plate Step 3 Levelling Mount Step 4 You can re-level the mount after the mount has been installed on the wall.
  • Page 6 Ukoliko imate dodatna pitanja o proizvodu, ljubazno vas molimo da kontaktirate direktno proizvođača kako biste dobili sve detaljne informacije. Za najnovije informacije o ceni, dostupnim akcijama i tehničkim karakteristikama proizvoda koji se pominje u ovom dokumentu, molimo posetite našu stranicu klikom na sledeći link: https://tehnoteka.rs/p/zidni-nosac-za-tv-s-box-lcd-2900b-akcija-cena/...
