Summary of Contents for Power Science GDH-020A
- Page 1 Diesel Heater: GDH-020A Installation Instruction & User’s Manual...
- Page 2 Power Science Diesel Heater 1. Overview Power Science Diesel Heater (Model: GDH-020A) is a 2kW heater with stainless steel diesel tank and Bluetooth controlled switch specially designed for caravan, motorhome and other vehicles. All the components are selected, and every machine has been fully tested before coming to the market.
- Page 3 Power Science Diesel Heater 2. GDH-020A Outline Dimensional Drawing 310 (ø 60) 305 (ø 75) 4×16 min. 17 ø 24 ø 25 3. Product Parameters • Model: GDH-020A • Weight: 2.7kg • Dimension: 310*115*122mm • Heat Value: 2kW • Hot air Volume: 90m •...
- Page 4 Power Science Diesel Heater （3） The outdoor air filter should be kept as far away from the exhaust outlet as possible to prevent exhaust gases from being sucked back into the combustion chamber. （4） If the entire diesel heater system is installed indoors, make sure that all exhaust gases can be completely discharged to the outside.
-
Page 5: Tools Required For Installation
Power Science Diesel Heater 6. Tools Required for Installation To install the heater in a caravan, motorhome, or campervan, you’ll also need the following tools and supplies: • Drill and drill bits • Hole saw (105mm and 65mm Diameter) • Screwdriver •... - Page 6 Power Science Diesel Heater 7. Equipment & Components List Item Name Q’ty Specification Picture Equipment Include: Combustion Chamber, Spark Plug, Motor, Main Unit Fan, Electronic Control Unit, Temperature Sensor, - 5L Stainless Steel Fuel Tank. - Fuel Level Guage. Diesel Tank 1 set - Stainless Steel pickup pipe on the top.
- Page 7 Power Science Diesel Heater Cold & Hot Air - Inner Diameter: φ 60mm Ducting - Length: 1.8m after stretch - Outer Diameter: φ 60mm - Length: 50mm Vent 2 set - Height: 10mm - With 6 screws - Working Diameter: φ 44 ~ 64mm...
- Page 8 Power Science Diesel Heater Bag #4: Others - Outer Diameter: φ 100mm Metal Ring - 170*140*2(Thickness)mm Mount Plate To mount the main unit to the floor. Stud Bolt To connect the mount plate with the main unit. - Working Diameter: φ 10mm...
- Page 9 Power Science Diesel Heater 8. Installation Instructions （1） Select a right installation location and make an installation hole a. Choose an installation location inside the vehicle. Avoid obstacles such as pipes, water tanks, and chassis beams outside the vehicle; b. From the inside of the vehicle, drill a pilot hole to the outside in the area where the heater will be installed.
-
Page 10: Install The Heater
Power Science Diesel Heater Tips： ➢ Applying some lubricant when inserting the black rubber hose into the unit' s fuel inlet or the nylon fuel pipe into the black rubber hose will facilitate these works. ➢ Position the Clamps for the air intake pipe and exhaust pipe in the middle of the two pipes to avoid interference with the installation hole. - Page 11 Power Science Diesel Heater Tips： ➢ The cold air inlet opening should be positioned as far away as possible from the warm air outlet. ➢ If installing a cold air inlet pipe, the cover at the rear of the heater needs to be removed.
-
Page 12: Fuel Filter Installation
Power Science Diesel Heater ➢ Fuel Pump Installation Angle The outlet of the fuel pump shall tilt upwards. The tilt angle can be selected from the range of 15°～90°, but the range of 15°～35° will be preferred. (as shown in the following Figure.) When conditions permit, the fuel pipe between the fuel pump and the heater shall go up gradually. -
Page 13: Display Information
Power Science Diesel Heater At this point, the heater installation work has been completed, and you can now proceed to start using it. 9. User Manual （1） Display Information 1. ON/OFF Button 2. Fuel button 3. Setting Button 4. LCD Display 5. - Page 14 Power Science Diesel Heater • Press the “Power” button of the remote controller, then the switch will go back to the home page. • The specific button definitions are as follows: ➢ P-1: Button for increments ➢ P-2: Button for decrements ➢...
- Page 15 Power Science Diesel Heater 2. Or replace it with a new one. 1. Make sure the Fan is not blocked. Fan Fault 2. Or replace it with a new one. 1. Make sure the ignition plug is connected correctly. Ignition Unit Fault 2.
- Page 16 Scan to Download Android App Scan to Download IOS App Or visit Or Search AirHeaterBLE https://www.booyood.com/app /airHeaterbyble.apk In APP STORE Power Science Australia Group Pty Ltd Address: 74 Killara Road, Campbellfield VIC 3061 URL: www.powersciencegroup.com.au Email: info@powersciencegroup.com.au...
