ELECTRICSUN ElectricSun1200ta User Manual

EN
1. CALCULATION FORMULA FOR ElectricSun RADIANT PANELS (W/m² for a room with h ≈ 2,5m)
Number of outer sides
1 side
2 sides
3 sides
4 sides
2. INSTRUCTIONS FOR THE Tuya AND Smart Life MOBILE APPS
From the APP you can set a daily program, the time to start (you can set several hours per day), you can set the
temperature, High or Low power, you can set the timer for a certain number of operating hours, from 1 to 24 hours.
The settings are made in the APP, from the bottom bar, Smart, Automation, Tap-to-Run.
1. Download the app. Both Apple and Android users can scan the QR code below to download either App.
2. You will be required to create an account, using your email address. Make sure to turn on BLUETOOTH and
LOCATION on your phone.
3. Once done, click on "Add Device", and "Add Manually".
4. After that, click "Small Home Appliances" on the left menu, scroll down and select "Oil Heater WI-FI". Check that
the WiFi symbol light is flashing on the heater, after which you will be required to enter your WiFi network name
and password.
5. Please make sure to connect to 2,4 GHz Wi-Fi Network.
6. After that, the app will connect to your heater and you will be able to control it using the app
ElectricSun
FAR INFRARED RADIANT PANEL
for Indoor and Outdoor Use
USER MANUAL
■ Read all the instructions carefully before setting up and operating
this unit.
■ This manual is designed to provide you with important
information needed to setup, operate, maintain your radiant
heaters.
■ Failure to follow these instructions may damage and/or impair its
operation and void the guarantee.
With good insulation
50 Watts/m²
60 Watts/m²
70 Watts/m²
80 Watts/m²
Medium insulation
70 Watts/m²
80 Watts/m²
90 Watts/m²
100 Watts/m²
Without insulation
90 Watts/m²
100 Watts/m²
110 Watts/m²
120 Watts/m²
1
