Sealey AK470DX Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
‰
equipment.
Familiarise yourself with the application and limitations of the oil drainer, as well as the potential hazards.
9
WARNING! Disconnect the drainer from the air supply before changing accessories, servicing or performing any maintenance.
‰
Maintain the drainer in good condition (contact your local Sealey stockist).
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Keep the drainer clean for best and safest performance.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9
WARNING! While extracting high temperature oils, keep hands, face and body protected using suitable personal protective
‰
equipment (PPE).
DO NOT Extract caustic or flammable products.
8
Keep children and unauthorised persons away from the working area.
9
WARNING! Ensure correct air pressure is maintained and not exceeded.
‰
Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use, and ensure that all connections are
9
secure.
DO NOT use the drainer for any purpose other than that for which it is designed.
8
DO NOT operate the drainer if any parts are damaged or missing as this may cause failure and/or personal injury.
8
DO NOT stand on the drainer.
8
DO NOT adjust or tamper with the safety valve.
8
DO NOT move the drainer by the hose, or yank the hose from the air supply.
8
DO NOT place attachments close to your face (especially eyes, ears, etc.) and DO NOT point hose at other persons or animals.
8
DO NOT allow untrained persons to operate the drainer.
8
DO NOT operate the drainer when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT leave the drainer operating unattended.
8
DO NOT direct air from the air hose at yourself or others.
8
When not in use disconnect from the air supply, vent reservoir and store in a safe, dry, childproof area.
9
Dispose of waste oil in accordance with local authority regulations.
9
WARNING! DO NOT pollute the environment by allowing uncontrolled discharge of waste oil.
‰
DANGER! DO NOT release drain pan clamp lever when there is pressure in the reservoir as pipe and drain pan will be propelled
▲
upward with force. This could result in damage and/or serious injury.
1.1. GENERAL SAFETY
Air compressor must maintain stable 7 bar+ pressure.
9
The air supply pipe requires a diameter of 10mm.
9
Ensure your air compressor produces dry air.
9
Waste oil should be properly disposed of/recycled according to relevant regulations.
9
For repair services, please contact your Sealey stockist. DO NOT attempt to repair it yourself.
9
DO NOT use the lifting rod as a handle.
8
Immediately shut off the air supply and inspect for leaks if detected during operation.
9
Handle extracted waste oil with care (40~80°C) to prevent burns. Wear gloves and goggles for eye and hand protection.
9
Always keep the engine off during operation.
9
Avoid extracting petrol, diesel, or liquids with methanol, ketones, or flammables.
9
After draining the used oil, make sure to quickly pour it from the measuring cup into the tank to keep the cup in good shape and make
9
it last longer.
Closing the measuring cup drain valve after emptying waste oil isn't required.
9
After operation, release equipment pressure, clean it, and handle carefully to prevent damage or injury.
9
© Jack Sealey Limited
MOBILE MULTI-FUNCTION OIL STATION
WITH 61PC TOOL SET
MODEL NO:
Wear protective Wear protective
gloves clothing
Original Language Version
AK470DX
AK470DX Issue 1 06/11/24
