Tools required
1. Your table may have one of two different pre-drilled hole patterns. Please refer to the image below that matches
your table.
2. Attach Leg Bracket to table with screws "B". (If table was received with Leg Brackets attached skip to Step 3)
3. Slide Leg Base under lip of Leg Bracket until seated & pre-drilled screw holes are visible through Leg Base holes.
4. Fasten Leg Base to table with (2) screws "B".
5. Insert Adjustable Leg into Leg Base at desired height and attach with (1) screw "A".
6. Repeat for remaining legs.
HOLE PATTERN "A"
Adjustable Leg
B
5 Screws
Leg Bracket
Leg Base
Marco Group, Inc.
5400 Doniphan Dr.
Neosho, MO 64850
www.madebymarco.net
Assembly Instructions
Activity Table Legs
Phillips Screwdriver
Customer Service Hours:
Monday-Friday 8:30am to 4:30pm CST
Toll-Free 888-627-2601
CustomerService@marcogroupinc.com
5/16"-18 x 1/2" Screw
A x 4
HOLE PATTERN "B"
Adjustable Leg
B
A
6 Screws
Leg Bracket
Leg Base
B
(Except holidays)
Hardware (Included)
417-455-9663 - Phone
417-455-0057 - Fax
#85259
Rev. 11-27-23
#12 x 3/4" Screw
B x 32
A
B
