- Page 1 MGC-10 Multi-Channel Dash Camera DUAL DASH CAMERA INS TALL GUIDE (847) 296-279 sales@motorgc.com www.motorgc.com...
- Page 2 Important Notice 1. Before installation, please park the vehicle on the horizontal ground and shut down the engine (do not park the vehicle on a ramp or an inclined road). 2. Please read the section of packing list carefully and check carefully at the time of unpacking. 3.
- Page 3 Schematic Diagram of System Connection-Power Supply through OBD Schematic Diagram of System Connection-Power Supply through Standard Power Cable Preparation for Installation Relevant personnel must have a comprehensive understanding of the product's functions, (847) 296-4279 sales@motorgc.com www.motorgc.com applications, and overall components. They should possess knowledge of electrical circuits and vehicle structures, as well as common installation techniques for in-vehicle devices.
- Page 4 Schematic Diagram of System Connection-Power Supply through OBD Schematic Diagram of System Connection-Power Supply through Standard Power Cable Schematic Diagram of System Connection-Power Supply through Standard Power Cable Schematic Diagram of System Connection-Power Supply through Power Box Max FF Lite Pro+ FF Lite Pro+ chematic Diagram of Syst matic Diagram of System C...
- Page 5 Schematic Diagram of System Connection-Power Supply through Standard Power Cable Schematic Diagram of System Connection-Power Supply through Standard Power Cable Preparation for Installation Relevant personnel must have a comprehensive understanding of the product's functions, FF Lite Pro+ FF Lite Pro+ applications, and overall components.
- Page 6 Preparation for Installation Material and Tool List MGC-10 Camera x1 (847) 296-4279 sales@motorgc.com www.motorgc.com...
- Page 7 (847) 296-4279 sales@motorgc.com www.motorgc.com...
- Page 8 Installation of SIM Card and Memory Card Take out the Dashcam (power-o7), and use the Allen key in the kit to open the card slot panel on the right of the Dashcam by turning counterclockwise. Install SIM card and Micro SD card as shown in the figure below (pay attention to the insertion direction of the cards).
- Page 9 *Note: (1) Because the operating temperature range of the device is -40°C to +70°C, the Micro SD card and SIM card shall be able to function well in some harsh environments for a long time. Specifically, the metal contact on consumer-grade Micro SD cards and SIM cards is easy to oxidize under prolonged hot, humid, or salt-mist conditions.
- Page 10 Selection of Dashcam Installation Area (1) The Dashcam must be installed in the middle of the front windshield. It is generally installed in the rearview mirror area above the centerline of the front windshield. (2) When conditions permit, the height of the DSC lens shall not exceed the height of the driver's eyes, and the installation position shall be as low as possible provided that the driver's view is not obstructed.
- Page 11 Installation of Dashcam Bracket Park the vehicle on the horizontal ground, clean the interior and exterior of the glass in the target installation area with alcohol cotton to ensure that no dirt on the glass in this area will a7ect the angle of view of the lens for road condition monitoring, and ensure the glass is dry.
- Page 12 Installation of Dashcam Connect the Dashcam to the bracket with the front side facing inward (with the teeth on the right side of the bracket engaged with those on the right inner side of the Dashcam), and tighten the bracket stud clockwise with a PH2 cross screwdriver (before tightening, first adjust the Dashcam to be vertical).
- Page 13 Angle Adjustment and Fixation of Dashcam Adjust the Dashcam back and forth so that it is vertical. Fasten the bracket stud to ensure that the angle of the Dashcam will not be changed easily, and fix the Dashcam. When fixing, ensure that the cockpit camera screen meets the following conditions: 1) The center of the cockpit shall be in the middle of the screen.
- Page 14 Use a screwdriver to fasten the bracket studs clockwise so that the Dashcam will not shake easily. *Note: Make sure that the connection between the bracket and the Dashcam is fastened (the device is rigidly connected with the vehicle), so that the Dashcam will not shake easily. Otherwise, the GPS positioning will be inaccurate.
- Page 15 If the mode of power supply connection through the loose wire is adopted, according to the definition of power loose wire, connect POWER/ACC/GND with the power cable of the vehicle, respectively. *Note: The power line shall be connected using "special stripping-free connection terminal" where possible (no stripping is required, so as to avoid the risk of electric leakage), and the connection shall be wrapped with insulated rubber tape to avoid electric leakage/short circuit.
- Page 16 Left steering/right steering/reversing signal After locating the fuse board below the steering wheel or the front passenger dashboard, measure the cable corresponding to left steering/right steering/reversing signal according to the tips on the cover back of the fuse board or using a multimeter.
- Page 17 *Note: If the measured signal is a pulse signal, the source of left steering/right steering shall be set as pulse on the setting screen of the Dashcam; if the measured signal is a continuous high or low level signal, the source of left steering/right steering shall be set as level on the setting screen of the Dashcam.
- Page 18 Fixing position 1 of the power supply box: Remove the side ba7le of the driving seat, tear o7 the 3M tape on the power supply box, and fix it to the left or right ba7le, as shown below: Fixing position 2 of the power supply box: Fix the power supply box on the right ba7le of the driving seat with exposed cabling.
