ENQT Network Tester 2 User Manual

Hide thumbs Also See for Network Tester 2:

Advertisement

Quick Links

Download this manual
Network Tester 2
USER MANUAL
Do you have questions about our products?
+49 40 35 73 20 65 
vertrieb@enqt.de

Advertisement

loading
Need help?

Need help?

Do you have a question about the Network Tester 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ENQT Network Tester 2

Summary of Contents for ENQT Network Tester 2

  • Page 1 Network Tester 2 USER MANUAL Do you have questions about our products? +49 40 35 73 20 65  vertrieb@enqt.de...
  • Page 2 Variants ......................5 Hardware variants ..................6 Service agreements ..................6 Handling......................7 Note declaration.................... 7 Prepare usage of the Network Tester 2 ............7 Operation.....................10 Maintenance mode ..................12 Factory settings.................... 12 Connection of the extension modules ............13 Homescreen .......................
  • Page 3 Data Network Tester 2 450 ................. 60 Data Network Tester 2 5G ................63 Data Network Tester 2 PRO................. 66 Data Network Tester 2 Metering Edition (ME)..........69 Data Network Tester 2 IoT................72 10 Declaration of Conformity................. 76 11 Licence information................... 76 12 Disposal instructions ..................
  • Page 4 1 Introduction The Network Tester 2 from ENQT GmbH is a tool designed for analyzing and evaluating wireless networks. It reliably measures and records key network parameters such as signal strength, network availability, and connection quality. Its advanced hardware and custom software ensure accurate, reliable, and repeatable measurements.
  • Page 5 Connect the charger to the USB-C port on the bottom of the Network Tester 2 to recharge the built-in battery. Use the reset button on the Network Tester 2 to reset the entire device to the factory settings. For more information, go to section Handling.
  • Page 6 450 MHz band. Network Tester 2 5G The Network Tester 2 5G is the tool you need to check both public and private 4G (LTE) and 5G networks. It supports 5G nSA (non-standalone) as well as 5G SA (standalone) and private 5G networks.
  • Page 7 To avoid damage, users must handle the battery as described. Use the charging accessory shipped with the Network Tester 2 to recharge its battery. The charging cable and charger have been tested for use with the Network Tester 2. HANDLING...
  • Page 8 You'll hear a slight click when the cable is securely in place. The green status LED on the bottom of the Network Tester 2 will indicate the status of the charging process: Slow flashing: Charging in progress Permanent light indicates that the charging process has been completed.
  • Page 9 Do not use any tools to screw the antennas on to the Network Tester 2. Fasten the antennas by hand to avoid damage. Do not operate the Network Tester 2 without antennas connected as this can cause damage.
  • Page 10 The Network Tester 2 is equipped with a touch-sensitive display (touchscreen) for user inputs. Inputs can be made with a finger or a stylus (touch pen) suitable for capacitive touchscreens. A suitable stylus is included with the Network Tester 2. Using the stylus is particularly useful when gloves hinder finger input.
  • Page 11 4.3.3 Use of custom SIM cards The Network Tester 2 allows you to use your own SIM cards. It has a SIM card slot on the right side for this purpose, which can hold up to two SIM cards in 4FF ("nano SIM") format.
  • Page 12 ) or the reset button on the Network Tester 2 to do so. The reset button is on the underside of the Network Tester 2, to the left of the charging connector. The button can be accessed through a small hole, which is covered by a sticker (label).
  • Page 13 Reset the Network Tester 2 by pressing and holding the On/Off button while also pressing the Reset button with the device switched off. You'll see that the On/Off button flashes during the reset process. Keep the on/off button pressed until the flashing stops.
  • Page 14 4.6.2 Disconnect Before removing an extension module, complete all measurements and switch off the Network Tester 2. Use a slot screwdriver to pull out the red safety slide. Insert the screwdriver into the notch and slide out the red safety slider. Do not use the screwdriver as a lever, as this will damage the safety slider, the extension module or the Network Tester 2.
  • Page 15 5 Homescreen 5.1 Statusbar The Network Tester 2 displays different symbols at the top of the screen to indicate the status of various functions. One of them, the battery level indicator, is permanently displayed. Battery indicator WLAN Access Point current...
  • Page 16 New and improved functions can be added to the Network Tester 2 throughout its service life by means of updates. In addition, functions requiring a license that were not purchased with the device originally can also be licensed at any later date.
  • Page 17 5.4 Extended functionalities Depending on the Network Tester 2 variant, the service agreement selected and the options booked the following additional functions may be available: Wifi Scan Bluetooth-Scan...
  • Page 18 Tester 2 and change certain settings. 5.6.1 Device information The device information contains all the hardware and software information and version numbers that the ENQT support may ask you for in case of problems with the Network Tester 2. 5.6.2 Device settings...
  • Page 19 (SSID) and password you need to establish a connection. Once connected to the Network Tester 2 via WiFi, enter the address displayed on the Network Tester 2 screen under "URL" exactly as shown in the address bar of a browser.
  • Page 20 5.6.3 Softwareupdates Software updates give you the option to upgrade the Network Tester 2 to the latest version. These updates are available to customers with a service contract for the Network Tester 2 free of charge. Updates are only installed by ENQT at the express request of the customer and never without prior agreement.
  • Page 21 6 Device functions 6.1 Meter Test Use the "Meter Test" function of the Network Tester 2 to efficiently determine the network coverage and usable networks at the very location where you plan to install or operate a meter, an antenna or a mobile phone.
  • Page 22 The measurement starts as soon as you confirm the input of the measurement identifier by tapping . During a Meter Test, the Network Tester 2 performs a single active connection test for each network operator and network technology selected in the...
  • Page 23 Meter Test is completed. This allows you to transfer the results e.g. to a smartphone app directly after the measurement. The QR code will appear on the Network Tester 2 display after completing a Meter Test and tapping again to end the display of the QR code and return to the homescreen.
  • Page 24 Activate speed measurements) and the Network Tester 2 will measure and display the download speed in bits per second (b/s). It will be shown next to the signal level and signal quality in the Meter Test. Both readings will be displayed right next to each other.
  • Page 25 Each Meter Test result is saved individually and can be found again in the "Export" or "History" function afterwards. Enabled once, the Interval function remains active for subsequent Meter Test measurements and is even retained when the Network Tester 2 is switched off and on DEVICE FUNCTIONS...
  • Page 26 again. You can deactivate the Interval function again in the options menu by tapping when entering the identifier. 6.1.3.2 Band Scan Normally, the optimum cell is automatically selected during a Meter Test measurement, regardless of the frequency band in which it operates. If the Band Scan option is active, measurements are taken separately in each frequency band.
  • Page 27 Once enabled, the Band Scan option will remain active for subsequent Meter Test measurements and is retained even when the Network Tester 2 is switched off and on again. You can deactivate the Band Scan option again in the options menu by tapping when entering the identifier for a Meter Test.
  • Page 28 6.2.1 Starting a measurement Before starting, you have to select which network operator and which technology to measure. First, select the network operator. Then, tap the button at the bottom of the screen to select the network technology (e.g. "LTE"). The shown list is filled with all operators and technologies that were selected beforehand in the operator selection (see section...
  • Page 29 6.2.2.1 Bar visualization The current measured value is displayed in different ways: A color scale from red, orange, yellow to green and the height of the bar indicate the value visually. The measured value is also displayed as a number with the corresponding unit.
  • Page 30 Meter Test and are available for test in the Signal measurement function. You can also restrict the frequency bands to be used. This allows you to to emulate devices that do not support all available frequency bands with your Network Tester 2. DEVICE FUNCTIONS...
  • Page 31 You can restrict the frequency bands the Network Tester 2 may use for a particular provider and network technology. Tap on the name of the wanted network technology highlighted in blue.
  • Page 32 Tapping at the bottom of the screen resets the selection to this default values, removing all customizations. The default provider list depends on which country a Network Tester 2 was produced for. 6.3.1.3 Return to home screen You can return to the home screen at any time by tapping...
  • Page 33 In case you are unable to select 5G as network technology for the provider Deutsche Telekom, switch to the “Telekom 5G/4G” profile using the Profile Manager (see Profile Manager). This profile is only available on Network Tester 2 devices where it is relevant. 6.3.3 Adding an operator You can add additional operators by tapping at the bottom of the screen.
  • Page 34 The MCC (Mobile Country Code) is a three-digit number that identifies a country or region. Together with the Mobile Network Code (MNC), it is used to uniquely identify a cellular network. The number field only accepts a three-digit number. Confirm the entry by tapping .
  • Page 35 The manual input option allows you to measure non-public networks, such as networks in test mode. 6.4 History - Cloudupload You can display data from previous measurements stored on the Network Tester 2 by using the History function. DEVICE FUNCTIONS...
  • Page 36 All previous measurements are displayed in the history view, regardless of whether they have already been uploaded to the measurement data portal. If measurements are stored on the Network Tester 2 that have not yet been uploaded into the ENQT measurement portal, the symbol indicates the number of measurements that have not yet been transferred.
  • Page 37 6.5 Profile Manager The Network Tester 2 uses profiles to define settings for SIM card, network parameters and the modem selection. Depending on the hardware variant, the Network Tester 2 may come with different pre-defined profiles. The Profile Manager function allows you to switch between them.
  • Page 38 . The Network Tester 2 then returns to the home screen and re-initialises the modem. After a short time, the Network Tester 2 is ready to use again and displays all functions as usual. You can exit the screen via without changing the profile.
  • Page 39 After confirming the name entry, you have to specify the modem and the SIM slot to use. The Network Tester 2 displays all modems available in the upper drop-down menu. Tap the modem you want to use to select it.
  • Page 40 Next, define an APN (Access Point Name) to be used. This is specific to the operator and the network to be used, and is provided by the operator. Please ensure that the input is completely accurate, otherwise the connection will fail. Confirm your input with to get to the next step.
  • Page 41 Extension module such as the Network Tester 2 Metering Edition. Before using the function, make sure that the wM-Bus extension module is plugged into the top of the Network Tester 2 properly and is locked in place. Follow the instructions in section Connection of the extension modules.
  • Page 42 6.6.1 Data display The data display in the center of the user interface shows a list of all wM-Bus transmitters from which packets have been received since the function was started. In the list, all received wM-Bus packets are grouped by their transmitter ID.
  • Page 43 In the detailed packet view, the time of reception, message size and signal strength are displayed. (Content) Usually, the content of the packets is encrypted. The Network Tester 2 can decrypt wM-Bus messages if the encryption key is known. By tapping the -symbol, you can open a window that allows you to enter the 32-character key in hexadecimal format).
  • Page 44 6.6.4.1 Receiver mode The Network Tester 2 supports the reception of wM-Bus messages in either of S and T+C modes. Use the buttons to switch between the two modes. Tap the desired option and press to confirm.
  • Page 45 LMN Extension, such as the Network Tester 2 Metering Edition. Before using the LMN function, the LMN Extension module needs to be plugged into one of the USB-C ports on the top of the Network Tester 2 and locked in place. Please refer to section...
  • Page 46 LMN bus. the current bus supply voltage the voltages of the A and B signal lines the total number of LMN messages received by Network Tester 2 since LMN function was started the number of corrupt LMN messages received In addition, a recommendation for action is displayed below this data.
  • Page 47 If your LMN extension module is 12V-capable, a switch will be displayed. When activated, the LMN bus voltage is provided by the Network Tester 2. This means the bus is supplied without the use of a gateway or power supply unit. This is particularly useful for test setups.
  • Page 48 LMN packets sent from and to the meter in detail. The packets detected by Network Tester 2 are displayed in a list with the reception time, communication direction and message size. Tap on a packet to call up further details.
  • Page 49 The meter number, source address and destination address are all clearly displayed. You will find further information on message transmission in the HDLC Control block. The content of the message is displayed in the data block as a byte sequence (hexadecimal format). 6.8 Wifi Scanning The “Wifi Scan”...
  • Page 50 End the “Wifi Scan” function by tapping . This will return the Network Tester 2 to the homescreen. If this function is not already available on your Network Tester 2, you can acquire it by purchasing the fitting license option. 6.9 Bluetooth Scanning The “Bluetooth scan”...
  • Page 51 Close the detailed view using Press to end the Bluetooth scan function and return to the homescreen. If this function is not already available on your Network Tester 2, you can acquire it by purchasing the fitting license option. DEVICE FUNCTIONS...
  • Page 52 7 Care instructions Follow these care instructions to ensure a long service life of your Network Tester 2: General cleaning Use a soft, lint-free cloth to clean the housing and screen. If necessary, dampen the cloth with water or a mild soap solution. Ensure that no liquid enters the connector or the inside of the Network Tester 2.
  • Page 53 Avoid direct sunlight, high temperatures and high humidity. These may damage the Network Tester 2. Store the Network Tester 2 in the transport case when not in use to protect it from mechanical damages. ENQT's silicone protective cover is the perfect option to keep your Network Tester 2 safe during use.
  • Page 54 Network Tester 2. Handling You must always handle the Network Tester 2 with care. The Network Tester 2 is made of sensitive materials such as plastic and glass and contains sensitive electronic components. Do not pierce, break or expose the Network Tester 2 or the battery to open flames or liquids.
  • Page 55 Network Tester 2 and its accessories are not used or stored in a dusty, smoky, damp or dirty environment. The Network Tester 2 must not be operated in the vicinity of strong magnetic fields. Using the Network Tester 2 in the vicinity of a thunderstorm can cause irreparable damage.
  • Page 56 Keep the Network Tester 2 at least 15 cm away from areas of your body where a pacemaker is located. Use the Network Tester 2 on the opposite side of the body to avoid interference with pacemakers or other implanted or neighbouring medical devices.
  • Page 57 9 Technical description 9.1 Data Network Tester 2 LTE Size 170 x 96 x 35 mm Weight 432 g 3,5" TFT-Colour display (45 mm × 75 mm, 480 × Display 800 Pixel) Charging port USB-C with Power Delivery (PD) Internal battery Li-Ion, 3.500 mAh for up to 8 hours of usage...
  • Page 58 9.1.1 Assignment of the antenna connections 9.1.2 Service agreements NT 2 LTE NT 2 LTE plus NT 2 LTE max ✔ ✔ ✔ Meter test ✔ ✔ ✔ Signal measuring ✔ ✔ ✔ Multilingual ✔ ✔ ✔ Simple video instructions ✔...
  • Page 59 ✔ ✔ ✔ Measurement export ✔ ✔ ✔ Colour coding ✔ ✔ ✔ Band selection ✔ ✔ ✔ Basic training course EasyIntegration (QR- optional optional Export) Extended measurement ✔ ✔   details ✔ ✔ Ongoing updates   Remote maintenance & ✔...
  • Page 60 Wifi-Scan bookable bookable bookable Bluetooth-Scan bookable bookable bookable 9.2 Data Network Tester 2 450 Size 170 x 96 x 35 mm Weight 432 g 3,5" TFT-Colour display(45 mm × 75 mm, 480 × Display 800 Pixel) Charging port USB-C with Power Delivery (PD) Internal battery Li-Ion, 3.500 mAh for up to 8 hours usage...
  • Page 61 9.2.1 Assignment of the antenna connections 9.2.2 Service agreements NT 2 450 NT 2 450 plus NT 2 450 max ✔ ✔ ✔ Meter test ✔ ✔ ✔ Signal measuring ✔ ✔ ✔ Multilingual ✔ ✔ ✔ Simple video instructions ✔...
  • Page 62 ✔ ✔ ✔ Measurement export ✔ ✔ ✔ Colour coding ✔ ✔ ✔ Band selection ✔ ✔ ✔ Basic training course EasyIntegration (QR- optional optional Export) Extended measurement ✔ ✔ details ✔ ✔ Ongoing updates Remote maintenance & ✔ ✔ configuration ✔...
  • Page 63 Wifi-Scan bookable bookable bookable Bluetooth-Scan bookable bookable bookable 9.3 Data Network Tester 2 5G Size 170 x 96 x 35 mm Weight 432 g 3,5" TFT-Colour display(45 mm × 75 mm, 480 × Display 800 Pixel) Charging port USB-C with Power Delivery (PD) Internal battery Li-Ion, 3.500 mAh for up to 8 hours usage...
  • Page 64 9.3.1 Assignment of the antenna connections 9.3.2 Service agreements NT 2 5G NT 2 5G plus NT 2 5G max ✔ ✔ ✔ Meter test ✔ ✔ ✔ Signal measuring ✔ ✔ ✔ Multilingual ✔ ✔ ✔ Simple video instructions ✔...
  • Page 65 ✔ ✔ ✔ Measurement export ✔ ✔ ✔ Colour coding ✔ ✔ ✔ Band selection ✔ ✔ ✔ Basic training course EasyIntegration (QR- optional optional Export) Extended measurement ✔ ✔ details ✔ ✔ Ongoing updates Remote maintenance & ✔ ✔ configuration ✔...
  • Page 66 Wifi-Scan bookable bookable bookable Bluetooth-Scan bookable bookable bookable 9.4 Data Network Tester 2 PRO Size 170 x 96 x 35 mm Weight 432 g 3,5" TFT-Colour display (45 mm × 75 mm, 480 × Display 800 Pixel) Charging port USB-C with Power Delivery (PD) Internal battery Li-Ion, 3.500 mAh for up to 8 hours of usage...
  • Page 67 n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/ 40/41/48/66/70/71/75/76/77/78/79 2.4 GHz WLAN Optional upgrade 5 GHz WLAN Optional upgrade Bluetooth / BLE Optional upgrade 9.4.1 Assignment of the antenna connections 9.4.2 Service agreements NT 2 PRO NT 2 PRO plus NT 2 PRO max ✔ ✔ ✔ Meter test ✔...
  • Page 68 ✔ ✔ ✔ Interval measuring ✔ ✔ ✔ RSSI/RSRQ/RSRP Switch ✔ ✔ ✔ International networks ✔ ✔ ✔ Signal curve ✔ ✔ ✔ Measurement export ✔ ✔ ✔ Colour coding ✔ ✔ ✔ Band selection ✔ ✔ ✔ Wifi-Scan ✔ ✔...
  • Page 69 Measurement data portal- ✔ ✔ CloudSync ✔ Profileditor bookable bookable 9.5 Data Network Tester 2 Metering Edition (ME) Size 170 x 96 x 35 mm Weight 432 g 3,5" TFT-Colour display(45 mm × 75 mm, 480 × Display 800 Pixel)
  • Page 70 5 GHz WLAN Optional upgrade Bluetooth / BLE Optional upgrade 9.5.1 Assignment of the antenna connections 9.5.2 Service agreements NT 2 ME NT 2 ME plus NT 2 ME max ✔ ✔ ✔ Meter test ✔ ✔ ✔ Signal measuring ✔...
  • Page 71 ✔ ✔ ✔ International networks ✔ ✔ ✔ Signal curve ✔ ✔ ✔ Measurement export ✔ ✔ ✔ Colour coding ✔ ✔ ✔ Band selection ✔ ✔ ✔ LMN-Cryptoreset ✔ ✔ ✔ LMN-Manipulation reset ✔ ✔ ✔ LMN-Bus Check ✔ ✔...
  • Page 72 Wifi-Scan bookable bookable bookable Bluetooth-Scan bookable bookable bookable 9.6 Data Network Tester 2 IoT Size 170 x 96 x 35 mm Weight 432 g 3,5" TFT-Colour display(45 mm × 75 mm, 480 × Display 800 Pixel) Charging port USB-C mit Power Delivery (PD)
  • Page 73 Conformity CE, ROHS, WEEE Antenna connections 1× SMA (broadband antenna included) Technologies NB-IoT 1/NB-IoT 2, LTE Cat. M1, 2G/GSM NB1/NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/ B20/B25/B28/B66/B71/B72/B85 M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/ Frequency bands B25/B26/B27/B28/B66/B72/B85 850/900/1800/1900MHz 2.4 GHz WLAN Optional upgrade 5 GHz WLAN Optional upgrade Bluetooth / BLE Optional upgrade 9.6.1 Assignment of the antenna connections 9.6.2 Service agreements...
  • Page 74 ✔ ✔ ✔ Signal measuring ✔ ✔ ✔ Multilingual ✔ ✔ ✔ Simple video instructions ✔ ✔ ✔ Operator configuration ✔ ✔ ✔ Interval measuring ✔ ✔ ✔ RSSI/RSRQ/RSRP Switch ✔ ✔ ✔ International networks ✔ ✔ ✔ Signal curve ✔...
  • Page 75 ✔ ✔ Premium Support Speed test & runtime ✔ measurement ✔ Measurement data portal ✔ Bandscan Measurement data portal- ✔ ✔ CloudSync ✔ Profileditor bookable bookable Wifi-Scan bookable bookable bookable Bluetooth-Scan bookable bookable bookable TECHNICAL DESCRIPTION...
  • Page 76 Network Tester 2 5G Network Tester 2 PRO Network Tester 2 IoT Network Tester 2 Metering Edition We, the ENQT GmbH hereby confirm that the design and construction of the aforementioned devices comply with the following guidelines: 2011/65/EU 2014/53/EU EN 55032:2016-02...
  • Page 77 12 Disposal instructions Improper disassembly can lead to injuries. The Network Tester 2 contains a lithium polymer battery. Batteries pose hazards if not dismantled and disposed of correctly. This can result in a fire hazard in the event of a short circuit.
  • Page 78 13 Manufacturer details The Network Tester 2 is developed and manufactured by: ENQT GmbH Spaldingstr. 210 20097 Hamburg Germany Contact Phone: +49 40 35 73 20 65 E-mail: info@enqt.de Represented by Christopher E. Niemöller Commercial register HRB 151086 Registry court: Amtsgericht Hamburg...
