Hioki SW2001 Instruction Manual page 154

9 Specifications
9.1 General Specifications
Item
Operating environment
Operating temperature and
humidity range
Storage temperature and
humidity range
Conforming standards
Power supply
Displays
Interface
Dimensions
Weight
Product warranty period
Included accessories
Indoor use, pollution degree 2, altitude: up to 2000 m (6562 ft.)
0°C to 40°C (32°F to 104°F), 80% RH or less (non-condensing)
-10°C to 50°C (14°F to 122°F), 80% RH or less (non-condensing)
Safety
EN 61010
EMC
EN 61326 Class A
Commercial power supply
Rated supply voltage: 100 to 240 V AC
(Assuming voltage fluctuation of ±10%.)
Rated supply frequency: 50 Hz/60 Hz
Anticipated transient overvoltage: 2500 V
Maximum rated power 120 VA
Normal power consumption (reference value): 17W (during low-
voltage system measurement)
Power LED, remote LED, high voltage output LED, error LED
USB, LAN, EXT. I/O
Approx. 439.2W × 265.9H × 770D mm (17.3W × 10.5H × 30.3D in.)
(excluding protrusions)
SW2001-04: Approx. 20.5 kg (45.2 lbs)
SW2001-08: Approx. 22.5 kg (49.6 lbs)
SW2001-16: Approx. 27.0 kg (59.5 lbs)
SW2001-24: Approx. 31.5 kg (69.4 lbs)
(None including the ST9200 or ST9201 options available only at the
time of purchase order issuance for the instrument)
If including ST9200: Add 1.2 kg (2.6 lbs)
If including ST9201: Add 0.139 kg (0.3 lbs)
3 years
See: "Included accessories"
154
HIOKI SW2001A971-01
Description
