Rinnai PCD01W Installation Instruction

REU-AM – PCD01W Pipe Cover
Installation Instruction
GENERAL INFORMATION
This Pipe cover (PCD01W) is compatible with Rinnai Water Heater models as listed on the right.
•
For your safety, always wear safety glasses and gloves.
•
To use this product correctly and safely, please read and follow these assembly and installation
instructions.
•
Carefully unpack and identify each component before attempting to assemble. Refer to Parts List.
•
The pipe cover is designed to conform with the hot water heater and is approximately the same width
and depth of the appliance. An installed pipe cover conceals 460mm of pipework below the appliance.
PIPE COVER PCD01 PARTS LIST
Part No. Description
1
Top Frame
2
Bottom Frame
3
Left Panel
4
Right Panel
5
Front Panel
6
L Bracket
7
Plastic Retaining Clip
8
Screw M4x12
9
Screw M4x8
10
Plastic Washer M4
11
Screw M5x8
12
Wall Anchor
13
Screw diam. 4.8x32
* For Australia & New Zealand only. To meet AS/NZS 5601 access requirements, the four M4x12 screws
the M4 plastic washers 10 are not to be fitted.
IMPORTANT
i INITIAL ASSEMBLY
1. Assemble the top frame
clips 7 . Once in place secure these parts with screws
2. Secure the two bottom frames
and plastic washers 10
Quantity
1
2
1
1
1
2
2
*
4
6
*
10
2
2
2
1 to the left 3 and right 4 panels with the plastic retaining
2 to the left 3 and right
.
1 2
6 7 8
10 11 12
9 and plastic washers 10 .
4 panels with screws 9
(For factory use)
U298-1198X01 (00)
MODELS
Infinity 12 REU-AM1220WD
Infinity 16 REU-AM1620WD
Infinity 20 REU-AM2024WD
Infinity 26 REU-AM2626WD
3 4
9
13
8
3
i
1
2
2
5
and four of
4
10 9
7
10
9
