HumanCentric WORKFLOW Assembly Manual

Desk
Hide thumbs

Advertisement

Table of Contents

T H E WO R K F LOW DE SK
A S S E M BLY M AN UAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WORKFLOW and is the answer not in the manual?

Questions and answers

Summary of Contents for HumanCentric WORKFLOW

  • Page 1 T H E WO R K F LOW DE SK A S S E M BLY M AN UAL...
  • Page 2 Thanks for making the Workflow Desk a part of your workspace. We can’t wait to see what you create next. We’d love to hear about HUMANCENTRIC.COM...
  • Page 3 CON T E N TS What’s in the Box Technical Details Safety and Warnings Assembly Process Desk Operation Troubleshooting Error Codes...

  • Page 4: What's In The Box

    Outer Rail (x1) Outer Rail (x1) Rail Plug (x1) Rail Plug (x1) WHAT’S IN THE BOX Note: The desktop and frame will arrive in separate boxes and may arrive in separate shipments. Desktop (x1) WHAT ’ S IN THE BOX? WHAT’S IN THE BOX THE BOX WHAT’S IN THE BOX...

  • Page 5: O Ptional Too Ls

    TOOLS R EQU IR E D TO OLS 5mm Hex Key T20 Torx Key Phillips Head Screwdriver (included) (Included) (Not Included) O PTIONAL TOO LS Cordless Drill Phillips Head Drill Bit Torque Screwdriver (Optional) (Optional) (40 Ncm Setting, Optional)
  • Page 6 Read this manual completely before use. This is a height adjustable desk and inappropriate use can result in property damage or bodily harm. HumanCentric does not accept warranty or liability claims for damages caused by improper use or handling of this desk. This manual should be provided to all new users.

  • Page 7: As Se M Bly Pr Ocess

    AS SE M BLY PR OCESS Place the desktop upside down on a pad, blanket, or cardboard box to protect it from scratches. The side with pilot holes should be on top. Place the inner and outer rails on the desktop and slide the inner rail into the outer rail.
  • Page 8 Align the frame holes with the Cantilever Screws Rail Screws pilot holes in the desk. (both sides) Partially screw in all the #10 x 3⁄4” frame screws before tightening fully. This will allow for minor adjustments to make sure all the frame holes remain aligned.
  • Page 9 Place the clamp locks in the orientation below with the arrow on the lock pointing at the arrow on the clamp. Then use your foot to push the lock into the clamp until you hear a click. These take considerable force to push in, so use your full body weight and wear shoes.
  • Page 10 1 0. Screw the four levelers into the bottom of the feet. 1 1. Connect the motor cables and power cable to the control box. 1 2 . Align the control box holes with the pilot holes in the desk. Secure the control box using the two #10 x 2”...
  • Page 11 Hide the excess cable lengths inside the rail. 14 . Plug the Anti-collision sensor into the A1 or A2 port of the control box. Flip the desk upright. It is recommended to use two people to avoid injury and damage to the desk. Then place the controller into the front right pocket.
  • Page 12 1 6 . Secure the controller in the pocket. Use the included torx key to screw the two controller screws into the bottom of the controller. Do not torque the screws over 40 Ncm. If you do not have a torque screwdriver, please tighten gently until you can feel a slight resistance.
  • Page 13 18 . Level your desk by rotating the leveling feet you installed earlier. Initialize your desk by following 1 9. the below procedure. IMPORTANT: The controller has a safety lock feature to prevent undesired movement from accidental contact. To unlock, touch the “S” button until the current height is shown on the display.
  • Page 14 TO D ISASSEMBL E Note: It is not recommended to disassemble and reassemble your desk repeatedly, but, if necessary, you can disassemble the locks and clamps by following the procedures below. Lock Removal: Remove the M6x16mm screws from each side of the leg.
  • Page 15 DE SK O PE RATIONS NORMAL OPERATION: To move the desk up or down, first you must unlock the controller by holding “S” until the current height is shown on the display. Then you can press and hold the UP or DOWN button until the desk reaches the desired height.

  • Page 16: Troubleshooting

    T R OUBLE SHO OTI NG Common Solutions If the desk is not functioning correctly, the following are the most common solutions that should be tried first. Initialize the desk 1. Hold the DOWN button on desk controller to ensure the desk is retracted to its lower limit. 2.
  • Page 17 E R R OR CO DES ERROR CODE NAME DESCRIPTION POTENTIAL CAUSE TROUBLESHOOTING Position Lost The desk has an unknown • Position error • Initialize desk position and needs to be • New desk leg was added initialized General Overload Up Desk was overloaded going •...
