Industrial Electronic Devices
User Manual
Revision 1.000
English
KNX - Interface
(Order Code: HD67825-KNX-x-B2)
for Website information:
www.adfweb.com?Product=HD67825
for Price information:
www.adfweb.com?Price=HD67825-KNX-E-B2
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
User Manual KNX - Interface
Document code: MN67825_ENG
For others KNX products, see also the following links:
Converter KNX to
www.adfweb.com?Product=HD67801
www.adfweb.com?Product=HD67802
www.adfweb.com?Product=HD67803
www.adfweb.com?Product=HD67804
www.adfweb.com?Product=HD67807
www.adfweb.com?Product=HD67808
www.adfweb.com?Product=HD67809
www.adfweb.com?Product=HD67810
www.adfweb.com?Product=HD67811
www.adfweb.com?Product=HD67812
www.adfweb.com?Product=HD67813
www.adfweb.com?Product=HD67814
www.adfweb.com?Product=HD67815
www.adfweb.com?Product=HD67818
www.adfweb.com?Product=HD67820
www.adfweb.com?Product=HD67821
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
in India
in India
in India
in India
Revision 1.000
Pagina 1 di 21
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(EtherNet/IP)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(M-Bus Master/wM-Bus)
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(PROFINET Slave)
(SNMP)
(DMX)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Summary of Contents for ADF Web HD67825-KNX B2 Series
- Page 1 User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 1 di 21 Industrial Electronic Devices User Manual Revision 1.000 English KNX - Interface (Order Code: HD67825-KNX-x-B2) for Website information: www.adfweb.com?Product=HD67825 for Price information: www.adfweb.com?Price=HD67825-KNX-E-B2 For others KNX products, see also the following links: Benefits and Main Features: Converter KNX to Very easy to configure...
-
Page 2: Table Of Contents
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 2 di 21 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 3 di 21 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 4 di 21 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com srl tel. +39 - 0438.30.91.31 www.adfweb.com info@adfweb.com Figure 1: Connection scheme for HD67825-KNX-E-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 5 di 21 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection Scheme for HD67825-KNX-E-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 6 di 21 Industrial Electronic Devices CHARACTERISTICS: The HD67825 is a KNX - Interface. It has the following characteristics: Bi-directional information between KNX bus and Ethernet bus; Mountable on 35mm Rail DIN; Wide power supply input range: 8…24V AC or 12…35V DC;... -
Page 7: Power Supply
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 7 di 21 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC:... -
Page 8: Function Modes
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 8 di 21 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... -
Page 9: Leds
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 9 di 21 Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks slowly (~1Hz): Run Mode... -
Page 10: Knx
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 10 di 21 Industrial Electronic Devices KNX: KNX is the standard that allows the automated and decentralized management of the technologic plans of a big typology of structures: commercial buildings, factories, houses, public locals, schools and so on. -
Page 11: Ethernet
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 11 di 21 Industrial Electronic Devices ETHERNET: The Ethernet ports are used for programming the device and for the communication with the Ethernet Client. The Ethernet connection must be made using Connector3 of HD67825-KNX-E-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. -
Page 12: Use Of Compositor Sw67825
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 12 di 21 Industrial Electronic Devices USE OF COMPOSITOR SW67825: To configure the Converter, use the available software that runs with Windows called SW67825. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 13: New Configuration / Open Configuration
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 13 di 21 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “KNX - Interface”... -
Page 14: Software Options
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 14 di 21 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. In the section “Language”... -
Page 15: Set Communication
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 15 di 21 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of the interface. By Pressing the “Set Communication” button from the main window for SW67825 (Fig. 2) the window “Set Communication”... -
Page 16: Update Device
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 16 di 21 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. - Page 17 User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 17 di 21 Industrial Electronic Devices If you know the actual IP address of the device, you have to use this procedure: Turn on the Device with the Ethernet cable inserted; Insert the actual IP of the Converter;...
-
Page 18: Mechanical Dimensions
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 18 di 21 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 6: Mechanical dimensions scheme for HD67825-KNX-E-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 19: Ordering Informations
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 19 di 21 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67825 – KNX – x - B 2 Connectors Type 2: Fixed 5mm Screw Terminal Enclosure Type... -
Page 20: Disclaimer
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 20 di 21 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 21: Warranties And Technical Support
User Manual KNX - Interface Document code: MN67825_ENG Revision 1.000 Pagina 21 di 21 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
