SUPERNOVA VK-0003 Setup Instructions

© 2025
Order #XXXXX
SEG Graphic Installation
Insert narrow side of
STEP 1: Attach Corners
silicone welt into the
1 3
channel at corner 1, with
fabric to the outside.
Repeat for opposite
corner 2, then corner 3,
Always insert graphic
then corner 4.
into each alternate corner,
then into the sides of
the frame. Otherwise
the graphic will not fit
into the frame correctly.
4 2
STEP 2: Attach Middle
1
Once corners are
attached, press the
middle of edge 1 into
the channel. Then press
middle of edge 2 into
3 4
the channel on opposite
side.
Repeat with edge 3 & 4.
2
Once the middle of sides
are attached, fully press
STEP 3: Attach Sides
the silicone welt into the
2
1
channel, between center
and corner at location 1.
5 7
Repeat the process
between center and
corner at location 2.
6 8
3 4
PRESS
in.
DON'T slide or push
along edge
Do the same for welt
To remove the graphic
from the frame, locate on opposite side, at
the fabric pull tab.
locations 3 & 4. Then
Gently pull on the tab
repeat for locations 5 & 6
to remove the graphic.
and 7 & 8.
VK-0003 Backlit Table Top
Item Qty. Description
1 2 Base Plate
2,2A 1,1 33.5"w CEI110 Horizontal Extrusion w/ Miter One End
3,3A 1,1 33.5"w CEI110 Horizontal Extrusion w/ Miter One End
4,4A 1,1 40"h CEI110 Vertical Extrusion w/ Miter Both Ends
5 1 36.353"h Z45 Vertical Extrusion
Steps:
1) Attach base plates [1] to extrusions [2] and [3], using bolts.
2) Assemble extrusions [2,2A,3,3A,4,4A] together as shown.
See reverse side for CEI-110 Frame Assembly details.
3) Attach extrusion [5] to center of frame.
See Z45 Attachment detail.
4) Connect lighting power cords and attach transformer.
5) Install SEG graphic to front and back of assembled frame.
2A
4
2
1
3A
*
5
to power
*
3
1
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com
Completed Assembly
*
Z45 Attachment
Z45
F r o
n t o
f F
r a m
e
4A
Attach Z45 vertical to back
groove of CEI-110 horizontal.
Light to Light Attachment
Male
Lights
+
+
-
-
Light to Transformer Attachment
+
- Female
Power
Transformer
96W / 4 Amp / 24V
Maximum of 7 lights per chain,
7 lights per Transformer
CEI-110
