Summary of Contents for CASAINC BR30001AACH1W
- Page 1 Smart Toilet Manual Model:BR30001AACH1W Phone:888-257-3857 Website:www.casainc.com Customer Service:service@casainc.com...
- Page 3 Thank you for your trust Sincerely thanks for buying our product,please understand important matters regarding the instructions for use from this manual before you use the product. Please follow the instructions of the manual. Please safekeep the manual after reading for review later. Our products will be improved continually,we will not notice if there's some change.
-
Page 4: Table Of Contents
Content 1.Overview ........................1 1.1 Appearance ....................1 1.2 Remote control ..................2 2. Packinglist ......................3 3. Explanation of symbols ..................4 4.Safety instructions ..................... 4 4.1 Normal use .....................4 4.2 Safety instructions .................. 4 4.3 The use of battery .................. 6 5.Side button description .................. -
Page 5: Overview
1.Overview 1.1 Appearance Side Button Description Stop/Flush/Drying Regarding the appearance &function, Note: please refer to the physical goods. service@casainc.com... -
Page 6: Pairing The Remote
Drying pairing succeeds power plug. button. Do not keep it close to your bodyfor whom has cardiac pacemaker and other auxiliary Tips: medicalequipment inthe body,Becuase the remote has strong magnet inside. service@casainc.com... -
Page 7: Packinglist
2.Packing list Complete machine Backup battery Remote Wax ring Angle valve filter &decorative cover Positioning plate for ceramic body Quick lock valve Remote battery Manual service@casainc.com... -
Page 8: Explanation Of Symbols
● If the ground wire is not connected,it maycause electric shock or leakage. ● Make surethe power cord is notdamaged. ● The power cord can't be stucked or squeezed. ● Keeps the power cord away from hot surfaces and sharp edges. ● The power socket must be within the specified range(AC120V±10%). service@casainc.com... - Page 9 ● Don't block the air outlet.Don't put your hands or other things into the air outlet. ● Don't cover the air outlet when using it. ● Don't shoot urine into theair outlet. ● Do not put ignited cigarettes and other burning materials into this product. service@casainc.com...
-
Page 10: The Use Of Battery
● The remaining water may freeze when the product is transported over long distances or stored for along timein cold winter or alpineregion.To prevent the damage caused by freezing,please take antifreeze measures. service@casainc.com... -
Page 11: Side Button Description
●When the wash function is onging,rotating down the button【 】 will movethe nozzleforward ● There are 4 levels for adjustment,close,low,mid,high level.If it is out of levels,the machine will respond with two beeps telling the operation is invalid. (The correct operation only has one beep) service@casainc.com... -
Page 12: Remote Control Description
●When power is off,long pressing for over 2 seconds will turn it on. ●When power is on,long pressing forover 2 seconds will turnit off. When poweris off,shutdown modeexits automatically at the timethe human body sits on theseat. Levelindicator -High light Close Flushing 飞 Short press the button【飞】tostart flushing. service@casainc.com... -
Page 13: Water Temperature Adjustment
Auto setting ◎ 口 ● If the settingis open,it willautomatically openthe coverand seat when the userapproaches,and will automatically close the seatandcover after the user leaves. ● f the settingis closed,it wont automatically openor close the seat. service@casainc.com... -
Page 14: Night Light
● foot sensor for flushing ● foot sensor foropening coverorseat ● foot sensor for closing seat Foot sensor Keypoints of footsensor for flipping cover and seat: ● The foot needs to beplaced within 2cm from the sensor,and then the foot-sensing action is effective. service@casainc.com... -
Page 15: Other Functions
● It can flush by short pressing the side butoon. ■Power-off flush When the product is not plugged in,or in the case of power failure,press the flush button on side panel to flush. ● If theabove operation is invalid,please replace the battery or contact your local dealer. service@casainc.com... - Page 16 ● The seat closes by foot sensor. Automatically open the cover · ● Leave after sitting on seat over 10 seconds ● Automatically flush before drying or afterleaving the seat for about 3seconds ● Automatically close the cover afterabout seconds. service@casainc.com...
-
Page 17: More Humanized Design
When the human body is seated and function of cleaning or drying is not open, short pressthe button【O】to stop deodorization function. ■LED display/Light The temperature display corresponds to the temperaturelevelon the remote. When you're setting the different function's temperature,the corresponding function light willight.In the meanwhile,it displays the cureent temperature in the middle screen. service@casainc.com... -
Page 18: Installation
Please makesure opening and dloseing the door wil notffect the installation and useof the toilet when you are checking theinstallation space is bigenough or not.Thedistance of the inlet pipe from the ground should be more than 150mm. Before instalation,pleaseconfirm location ofsewageoutletandwaxsealasbelow picture ■ Structure for installation service@casainc.com... -
Page 19: Installation Steps
※ Both the battery and connection line have positive and negative poles.Do not insert by force,otherwise the product willbe damaged.lf any doubt,please inquire your local seller. Note: please refer to page 21 for the backup battery replacement guide. ③ Installation for angle valve service@casainc.com... - Page 20 As shown in Figure 3. ※After themarksare overlapped,do not move the ceramic body or shake it left orright,otherwise the sealing Figure 1 produced by the wax ring may be damaged,resulting in water leakage. service@casainc.com...
- Page 21 Aand B,then drill holes for bolts according to bolt positioning point,and remove the positioing plate.As shown in Figure 1. 2.Put a flange to the floor with bolts,then fix the wax ring to the sewage outlet, anddothe sealing well.As shown in Figure 2. service@casainc.com...
- Page 22 Figure 4. 5.Put the total top back to ceramicbody by pressing it down.(Note:there are corresponding buckles for connecting the total top to ceramic body) As shown in Figure 5. Figure 5 service@casainc.com...
- Page 23 120V,60Hz,16A with ground fault circuit breaker or ground leakage protector circuit. ● Plug in toilet to power socket and make sure the indicator light is on.If itdims, please press the intemmedate reset switch. ● When poweris on,test whether functions are normal. service@casainc.com...
-
Page 24: Remote Installation
· Choose a suitable place to instalthe remote bracket where you can easily touch the remote when you are siting on the inteligent toilet. ● Confirm that there are no obstades around the product. ■ Installation steps service@casainc.com... -
Page 25: Checklist After Installation
※ The battery boxis moisture-proof,please ensure that the buckle isfastened to achieve a good sealing effect. service@casainc.com... -
Page 26: Cleaning And Maintenance
After deaning the water supply angle valvenet,the Replace the filter smaller waterflow isstil small Check if the seals is damaged or not Replace the seals Device leakage Replace the suitableparts The water supply angle valveis not matching with device service@casainc.com... - Page 27 Ifit is frozen and failed to spray water,you can coverthe water supply pipe or connection part with cloth which hasbeensoaked in hotwater to make it thawed.(Please donotpour the water supply pipe with hotwater or blow it with hot wind.) service@casainc.com...
-
Page 28: Product Specification
Leakage Protection switch,wind/seat/water temperature Protection Nano intelligent deodorization Deodorization Note Rated power:when the ambient temperature is73.4°F,inlet water static pressureis 0.2 MPa±0.02 MPa,inlet water temperature is59°F±33.8°F,and seat temperature(high), water temperature(high),water pressure(high),the maxium stable power we can read in the mode of lady wash. service@casainc.com... -
Page 29: Troubleshooting Guide
Reference manuahow to adjust not enough temperature is in low gear or not water temperature Washer aways Please find a professional Solenoid valve failure dripping water repair man Please find a professional Washer can Seat bodyinduction failure. repair man not use service@casainc.com... - Page 30 1 minute Check the night light whether is Open the night lightaccording Night light not work close or not tothe manual Close the angle valve and Leakage disconnectthe power supply then contact yourinstaller service@casainc.com...
- Page 32 Model:BR30001AACH1W Phone:888-257-3857 Website:www.casainc.com Customer Service:service@casainc.com...
