Operating Instructions and Parts Manual
Scan the QR code or visit www.waynepumps.com for the full manual in English and Español. If you are having trouble scanning the
QR code, type the following URL into your internet browser to access the manual, www.waynepumps.com/wayne-operating-manuals/
POWER SUPPLY REQUIREMENT
MOTOR
HORSEPOWER
CIRCUIT REQUIREMENT
LIQUID TEMPERATURE RANGE
© 2025, WAYNE
SPECIFICATIONS
120 V, 60 Hz
Single Phase, Fan Cooled, Continuous Duty
1 HP
15 A (minimum)
40° F- 120° F
Model
HP
PLS100
1
Portable Lawn Sprinkler and Multi-Use Pump
Please read and save these instructions. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury and/or property
damage! Retain instructions for future reference.
MOTOR HOUSING
MOTOR SHAFT
IMPELLER
VOLUTE
PUMP SUCTION
PUMP DISCHARGE
PERFORMANCE
Discharge Head
40 ft.
60 ft.
Gal/hr
660
550
Intended for Indoor Use Only
www.waynepumps.com
CONSTRUCTION
Coated Steel
Stainless Steel
Thermoplastic
Stainless Steel
1 in. NPT
1 in. NPT
80 ft.
100 ft.
390
210
650001W-001 D 03/25
PLS100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wayne PLS100
Summary of Contents for Wayne PLS100
- Page 1 PLS100 Scan the QR code or visit www.waynepumps.com for the full manual in English and Español. If you are having trouble scanning the QR code, type the following URL into your internet browser to access the manual, www.waynepumps.com/wayne-operating-manuals/ CONSTRUCTION MOTOR HOUSING...
-
Page 2: Safety Signal Words
INSTALLATION MANUAL This pump is not designed to handle salt SAFETY SIGNAL WORDS water, brine, laundry discharge or any other application which may This manual contains information that is very important to know and contain caustic chemicals and/or foreign materials. Pump damages understand. -
Page 3: Installation
INSTALLATION MANUAL INSTALLATION OPERATION PUMPING FROM LAKES, PONDS OR SMALL STREAMS Never run the pump dry. Running pump without water will cause seal failure. NOTE: This pump is not intended for a permanent application. Remove priming port on pump, fill the pump and suction hose with Locate pump as close as possible to the water source, keeping the water. -
Page 4: Maintenance
INSTALLATION MANUAL MAINTENANCE Maintain adequate ventilation for the pump motor. The motor bearings are permanently lubricated at the factory. Additional lubrication is not required. DRAINING FOR WINTER Always protect pump and piping against freezing temperatures. If there is any danger of freezing, drain the system. Disconnect suction and discharge lines from pump. - Page 5 INSTALLATION MANUAL REPAIR KITS REF. NO. DESCRIPTION PART NUMBER IMPELLER, SHAFT SEAL, GASKET KIT 64049-WYN1...
- Page 6 HOW LONG DOES THE COVERAGE LAST? This Limited Warranty starts on the date of your purchase and lasts for one year for PLS100; however, if you cannot establish proof of purchase from an authorized dealer in the form of a sales receipt or other documents that establish proof purchase from an authorized dealer (“Proof of Purchase”), then this Limited Warranty will start on the date the Product was manufactured and lasts one year for PLS100 (the “Warranty Period”).
