Summary of Contents for heat-timer 904316-00
- Page 1 INSTALLATION AND OPERATION MANUAL TRANSDUCERS PRESSURE AND VACUUM TRANSDUCERS HEAT-TIMER CORP. 059045-00 REV. E...
-
Page 2: Table Of Contents
WIRING TO DIGI-ELITE WIRING TO PLATINUM CONTROLS WIRING TO SQ-ELITE WIRING TO THE RINET/INTERNET NETWORK WIRING THE SENSOR INTERFACE TO THE MSI HUB WIRING THE TRANSDUCER TO THE SENSOR INTERFACE TRANSDUCER TYPES AND SPECIFICATIONS NOTES WARRANTY HEAT-TIMER CORP. 059045-00 REV. E... -
Page 3: Overview
Heat-Timer pressure and vacuum, transducers are designed to connect to a variety of controls, including many Heat-Timer controls. The transducers use a 4-20mA signal and require a voltage source for the signal. All Heat-Timer controls provide the necessary voltage source. -
Page 4: Installation Instructions
General tool kit (screwdrivers, wire strippers, power drill, etc.) • 18 AWG multi-conductor, shielded or twisted-pair cable (Heat-Timer p/n 703001-01 or equivalent #18/2 cable) – used for the 24Vac Sensor Interface to MSI Hub connection, and the transducer to Sensor... -
Page 5: Mounting The 4-20Ma Sensor Interface
Position the Sensor Interface Enclosure (3) in the desired location, and then secure it in place using the at least two screws (4) through the mounting holes in the back of the Enclosure. NOTICE Do not replace the Sensor Interface cover until all wiring is completed. HEAT-TIMER CORP. 059045-00 REV. E... -
Page 6: Connecting The Wiring
Use only the transducer’s red (power) and black (signal) wires and cut the rest of the wires. WIRING TO DIGI-ELITE The Heat-Timer SPC, TSC, and MC Digi-Elite controls are capable of reading a variety of sensors. The Sensor Type selected from the control’s Startup menu determines the terminals the control will use to read the system sensor. -
Page 7: Wiring To Sq-Elite
The Sensor Interface receives power from the MSI Hub transformer and communicates with the network via the MSI Hub. Therefore, the MSI Hub must be properly installed prior to installation of the Sensor Interface. Refer to the Multi-Sensor Interface Hub Installation and Operation Manual (Heat-Timer p/n 059410-00) for information. -
Page 8: Wiring The Transducer To The Sensor Interface
Continue with “Wiring the Transducer to the Sensor Interface”. WIRING THE TRANSDUCER TO THE SENSOR INTERFACE 1. Run the 18 AWG multi-conductor, shielded or twisted-pair cable (Heat-Timer p/n 703001-01 or equivalent #18/2 cable) from the transducer through a knockout on the Sensor Interface Enclosure. -
Page 9: Transducer Types And Specifications
TRANSDUCER TYPES AND SPECIFICATIONS NAME PART # DESCRIPTION TYPE 0-15 PSI Pressure Transducer 904316-00 For Multi-MOD SQ-Elite-8S, Digi Span Pressure 0-30 PSI Pressure Transducer 904310-00 For Multi-MOD, MPCQ Platinum, SQ-Elite-8S, Digi Span Pressure 0-100 PSI Pressure Transducer 904312-00 For Multi-MOD, SQ-Elite-8S, Digi Span... -
Page 10: Notes
NOTES HEAT-TIMER CORP. 059045-00 REV. E... -
Page 11: Warranty
Heat-Timer Corporation will invalidate the warranty. Batteries are not included in this warranty. This warranty applies only to the original user and is not assignable or transferable. Heat-Timer Corporation shall not be responsible for any maladjustments of any control installed by Heat-Timer Corporation. It is the user’s responsibility to adjust the settings of the control to provide the proper amount of heat or cooling required in the premises and for proper operation of the heating or cooling system. - Page 12 20 NEW DUTCH LANE, FAIRFIELD, NJ 07004 PHONE: 973-575-4004 FAX: 973-575-4052 HEAT-TIMER.COM HEAT-TIMER CORP. 059045-00 REV. E...
