Playcraft Willow Bend Assembly Instructions Manual

Shufleboard cradle

Advertisement

Quick Links

SKU NUMBER: Willow Bend
SHUFLEBOARD CRADLE
WARNING: Do not attempt to assemble the pool table if any parts are missing or damaged. Improper
assembly may lead to damage or serious injury! We strongly recommend using Yelp or Google to locate
local billiard stores with professionals experienced in assembling pool tables instead of relying on the
provided "professional" general furniture assembly service(For example of Angi) . Slate leveling and
attaching the felt require expertise beyond typical furniture installation.Regular installations typically require
the assistance of two or more adults.
Please read the following instructions carefully prior to assembly.Check the parts list to make sure you have
all the parts needed for proper assembly.
1
