- Page 1 OWNER’S MANUAL AIR CURTAIN MODEL: FM-1209B-2 ITEM: EB290 MODEL: FM-1212B-2 ITEM: EB291...
- Page 2 READ AND SAVE THESE INSTRUCTIONS CAUTION: - Read and follow all instructions before operating Air Curtain. - Do not use appliance if any part are damaged or missing. WARNING: - To reduce the risk of fire or electrical shock, do not expose to water or rain. - To reduce the risk of fire or electrical shock, do not use this appliance with any solid state speed control device.
-
Page 3: Installation Method
Installment ( unit: mm ) MODEL FM-1209B-2 Item:EB290 FM-1212B-2 1200 Item:EB291 WARNING: To reduce the risk of fire, electric shock, or injury to persons, observes the following. a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. - Page 4 b. Install bottom board on the wall: - Fix position of installation - Attach the bottom board mounting to wall or the suitable building structure with expansion bolt. See the diagram on the right.. - Ensure bottom board is mounted securely. See following diagram.
-
Page 5: Wiring Diagram
Wiring diagram: Cautions and Maintenance: 1) Install at location firmly enough for safety, check installation quality periodically. 2) Do NOT install Air Curtain at location with water-splash, or with permanent exposure to high temperature and places close to explosive and corrosive gases. 3) In case of damage or breakdown, should consult qualified technician.
