EverSirius EX200 User Manual


OVERVIEW
EverSirius powerful soft LED panel EX200 is designed for big studios. The beam
angle is flood 120°, but it can reach the brightness of 5500lux @1m at 5600K. The
wide CCT 2800K~6500K gives more color choice. AC in and outputs to make more
lights in parallel, for easier wiring. The fan-less design gives a silent shooting
environment. Moreover, both CCT and brightness can be quick preset. The 11 lighting
effects makes it competitive and available for more application.

SPECIFICATIONS
Model
Power
CRI
TLCI
CCT
Light source
Dimmer
Beam angle
Working voltage
Dimension
Weight
Working Temperature

WHAT ARE INCLUDED
1. LED Panel EX200 ×1
2. DMX cable ×1
3. Power cable ×1
4. Barn doors ×1 set
5. Safety cable ×1
EX200
200W
> 96
> 96
Bi-Color 2800K~6500K
2400 pcs SMD LED
0~100% step-less dimming
120°
AC 100-240V / DC 25.6-33.6V
1056 x 335 x 133 mm
10.5 kg
-20℃~+45℃

INSTRUCTIONS
A brief introduction to facilitate your operation.
① ② ③
① Power switch.
② AC power cable socket.
③ AC outputs. Making multiple lights in parallel.
④ DC power socket
⑤ USB port.
⑥ DMX connecting sockets (in/out).
⑦ LCD Display. When power is on, it shows the real-time data.
⑧ Touch button for CCT. Press ⑬multi-function knob to switch between CCT
and brightness, and rotate it for Standard or Fast adjustment (refer to below ⑬).
⑨ Touch button for CCT quick setting 3200K / 4500K / 5600K / 6500K.
⑩ Touch button for DMX function. Rotate ⑬multi-function knob for DMX
address setting.
⑪ Touch button for brightness quick setting 25% / 50% / 75% / 100%.
⑫ Touch button for special effects. Press ⑬multi-function knob to switch
parameter settings, and rotate it for adjustment.
⑬ Multi-function knob. In CCT mode, long press the knob to switch between
Standard (S) and Fast (F) adjustment for brightness (1%/10%) & CCT (100K/500K)
⑭ V-mount battery plates. For the use of batteries.
⑩
⑧
⑫
⑨
⑪
④ ⑤ ⑥
⑦
⑬
⑭
