- Page 1 ORIOLE SERIES CAMERA TRM-- Oriole 3G-SDI Board Camera (3G-SDI/EX-SDI/CVBS) AS-BCAM-S42-001-A Technical Reference Manual Edition: v1.00 Issued Date: 08 February 2025 February 2025 www.activesilicon.com Page 1 of 35...
-
Page 2: Table Of Contents
ORIOLE SERIES CAMERA Contents FEATURES ....................3 CAUTIONS ....................4 SPECIFICATION ................... 5 CONNECTORS ..................... 7 BLOCK DIAGRAM ..................10 CONTROL PROTOCOL ................11 VISCA COMMAND LIST ................15 VISCA INQUIRY COMMAND LIST ............. 19 OSD MENU ....................25 CAMERA DIMENSIONS ................34 APPROVALS .................... -
Page 3: Features
ORIOLE SERIES CAMERA Features 1/2.8“ Sony IMX462 CMOS sensor 2.16M Pixels (Total) / 2.12M Pixels (Active) Full HD Resolution 1920x1080p / 30fps (25fps) 1920x1080p / 60fps (50fps) 1280x720p / 30fps (25fps) 1280x720p / 60fps (50fps) DAY & NIGHT (optional function) The AS-BCAM-S42-001-A uses a DC Motor controller to drive a switchable IR-cut filter for day and night mode functionality. -
Page 4: Cautions
ORIOLE SERIES CAMERA Cautions Power Supply This camera must always be operated at 12V DC Handling of the unit Be careful not to spill water or other liquids on the unit. Operating and storage location Avoid viewing very bright objects (such as light fittings) for extended periods. Avoid operating or storing the unit in the following locations. -
Page 5: Specification
ORIOLE SERIES CAMERA Specification Model AS-BCAM-S42-001-A Image Sensor 1/3" Sony CMOS sensor Total Pixels 1,945(H) x 1,109(V) = 2.16M Pixels Effective pixels 1,937(H) x 1,097(V), 2.12M Pixels Scanning system Progressive Scan Digital: 1080p/60(50)fps,1080p/30(25)fps, Video modes 720p/60(50)fps, 720p/30(25)fps Analog: 700TVL Color(1/30s) : 0.5lux , BW(1/30s) : 0.1lux Minimum illumination Color DSS(1/8s) : 0.125lux , BW DSS(1/8s) : 0.025lux... - Page 6 ORIOLE SERIES CAMERA Model AS-BCAM-S42-001-A Intelligence Privacy / Motion / DIS Privacy Mask Off / On (24 masks) Motion Detection Off / On (3 positions) Digital Image Stabilizer Off / On Special Function Defect / Image Range / System / HD Format / EX-SDI / COMM Defect Det.
-
Page 7: Connectors
ORIOLE SERIES CAMERA Connectors J201 J302 J303 J301 J203 J205 Top/Front View Bottom/Rear View J201 (I/O Connector-1) Pin No. Name Description Pin No. Name Description IR lamp control O/P DC+12V In IR-ON Active: +3.3V Normal: 0V Day&Night Control I/P D&N IN... - Page 8 ORIOLE SERIES CAMERA J205 (HD-SDI Connector) J302 (Day & Night Motor Control Drive) Pin No. Name Description Pin No. Name Description Day: 4.5V SDI/EX-SDI Output CONT(+) Night: 0V (GND) Day: 0V (GND) CONT(-) Night: 4.5V RF Connector - MMCX 12505WS-02 (YEONHO)
- Page 9 ORIOLE SERIES CAMERA 1. D&N IN (J201-10) Port for input of external Day&Night signal “Ext-In” Mode (active high) • Day Mode: High (+3.3V) • Night Mode: Low (Ground) 2. AD KEY (J201-7) The external wired remote control connection for OSD operation.
-
Page 10: Block Diagram
ORIOLE SERIES CAMERA Block Diagram MEMORY HD-SDI EX-SDI OUTPUT CMOS CVBS OUTPUT (※ Test Only) RS-485 CONTROL +3.3V +1.8V +1.2V POWER +12V February 2025 www.activesilicon.com Page 10 of 35... -
Page 11: Control Protocol
ORIOLE SERIES CAMERA Control Protocol 1. Timing As Command processing can only be carried out one time in a Vertical cycle, it takes a maximum of 1V cycle time for an ACK/Completion to be returned. If the Command ACK/Completion communication time can be cut shorter than the 1V cycle time, then every 1V cycle can receive a Command. - Page 12 ORIOLE SERIES CAMERA 3. Pelco-D Protocol Command List Message Format (Hex) Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Zoom Tele Zoom Wide Stop Don’t care Menu (Set) 03 or 07 03 or 07 Down Left Right • ID: Camera ID (1 ~ 255) •...
- Page 13 ORIOLE SERIES CAMERA 5. Visca Protocol ► Command packet (Variable packet length) X: 1 ~ 7 (Camera address) QQ: 01 (Command), 09 (Inquiry) ► Ack message packet (Variable packet length) Y: 9 ~ F (Camera address + 8) Q: 4 (Receive Ack), 5 (Completion message), 6 (Error message) R: Socket Number (1 ~ 3) ※...
- Page 14 ORIOLE SERIES CAMERA ► Example of communication Camera ID: 1 Socket number: 1 ※ Command ※ Inquiry command ► Network change message Sent from the peripheral device to the controller when a device is removed from or added to the network. The address must be re-set when this message is received: Y0 38 FF –...
-
Page 15: Visca Command List
ORIOLE SERIES CAMERA VISCA Command List Command Set Command Command Packet Comments AddressSet Broadcast 88 30 01 FF Address setting Broadcast 88 01 00 01 FF IF_Clear I/F Clear 8x 01 00 01 FF CommandCancel 8x 2p FF p : Socket No. (1 ~ 3) - Page 16 ORIOLE SERIES CAMERA Command Set Command Command Packet Comments Auto (On) 8x 01 04 5A 02 FF CAM_SlowShutter Auto Slow Shutter ON/OFF Manual (Off) 8x 01 04 5A 03 FF p :Max Slow shutter level (0:x2, 1:x4, 2:x8) CAM_MaxDSSLev Direct 8x 01 04 5A 1p FF ※...
- Page 17 ORIOLE SERIES CAMERA Command Set Command Command Packet Comments 8x 01 04 66 02 FF CAM_PictureFlip Picture Reverse On/Off (Rotate 180º) 8x 01 04 66 03 FF Night 8x 01 04 01 02 FF ICR Mode ON/OFF 8x 01 04 01 03 FF...
- Page 18 ORIOLE SERIES CAMERA Command Set Command Command Packet Comments 8x 01 04 16 01 FF Down 8x 01 04 16 02 FF Left 8x 01 04 16 04 FF CAM_OSD_Menu Right 8x 01 04 16 08 FF Menu / Set...
-
Page 19: Visca Inquiry Command List
ORIOLE SERIES CAMERA VISCA Inquiry Command List Inquiry Command Command Packet Inquiry Packet Comments y0 50 02 FF D-Zoom On CAM_DZoomModeInq 8x 09 04 06 FF y0 50 03 FF D-Zoom Off CAM_DZoomPosInq 8x 09 04 46 FF y0 50 00 00 0p 0q FF pq : D-Zoom Position... - Page 20 ORIOLE SERIES CAMERA Inquiry Command Command Packet Inquiry Packet Comments CAM_HLCModeInq 8x 09 04 32 00 FF y0 50 0p FF p : HLC Mode - 0(Off), 1(On), 2(Night) CAM_HLCLevelInq 8x 09 04 32 10 FF y0 50 00 00 0p 0q FF pq : HLC Level (0 ~ 14h)
- Page 21 ORIOLE SERIES CAMERA Inquiry Command Command Packet Inquiry Packet Comments CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p: Last Recall Memory No. t : 0 ~ 7 (Address) CAM_MemSaveInq 8x 09 04 23 0t FF y0 50 0p 0q 0r 0s FF...
- Page 22 ORIOLE SERIES CAMERA Exposure control values D-Zoom control values Shutter Speed (Hex) D-Zoom position Step 60Hz/30Hz 50Hz/25Hz Magnification Zoom Position (Hex) /NTSC /PAL 1/30000 1/30000 1/10000 1/10000 1/7000 1/7000 1/5000 1/5000 1/2500 1/2500 1/1600 1/1600 1/1000 1/1000 1/700 1/700 1/250...
- Page 23 ORIOLE SERIES CAMERA OSD character values V position 00 ~ 0Eh 15 Rows H position 00 ~ 27h 40 Columns Character code: Code Character Code Character Code Character Code Character Space Ç È " É Ê Ë Î & Ï...
- Page 24 ORIOLE SERIES CAMERA Register Settings Register Register Function Setting Value 2400 bps 4800 bps 9600 bps BaudRate 19200 bps 38400 bps 57600 bps 115200 bps Max. DZoom Ratio Digital ZOOM Max 00 ~ F8 = 256 / (256 - Value)
-
Page 25: Osd Menu
ORIOLE SERIES CAMERA OSD Menu ◆ Main Menu MENU ↲ D&N MODEL ↲ EXPOSURE ↲ WHITE BAL ↲ IMAGE ↲ INTELLIGENCE ↲ SPECIAL FUNC DISPLAY [EXIT] [SAVE] [DFLT] Functions can be setup using “Menu Key Command” of Visca protocol. The menu consists of the “Main Menu”... - Page 26 ORIOLE SERIES CAMERA EXPOSURE MENU EXPOSURE ↲ MODEL D&N LENS MODE NORMAL ↲ BRIGHTNESS EXPOSURE ↲ SHUT SPEED AUTO WHITE BAL ↲ IMAGE ↲ INTELLIGENCE ↲ FLICKERLESS OFF SPECIAL FUNC WDR/BLC DISPLAY DAY&NIGHT AUTO [BACK] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ◈...
- Page 27 ORIOLE SERIES CAMERA ◈ FLICKERLESS: Select Flickerless mode ► OFF / ON (remove screen flicker) ◈ AGC: Select Auto Gain Control ► OFF / ON ◈ WDR/BLC: Select WDR (Wide Dynamic Range) or BLC (Back Light compensation) ► WDR↲ ▷ LEVEL: Adjust WDR level.
-
Page 28: White Balance
ORIOLE SERIES CAMERA WHITE BALANCE MENU WHITE BAL ↲ MODEL D&N MODE AUTO ↲ EXPOSURE RED GAIN ↲ BLUE GAIN --- WHITE BAL ↲ CHROMA IMAGE ↲ INTELLIGENCE ↲ SPECIAL FUNC DISPLAY [BACK] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ◈ AWB: Select WHITE BALANCE mode ►... - Page 29 ORIOLE SERIES CAMERA IMAGE MENU IMAGE ↲ ↲ MODEL D&N ↲ EXPOSURE MIDDLE ↲ MIRROR WHITE BAL ↲ SHARPNESS IMAGE ↲ INTELLIGENCE ↲ SPECIAL FUNC DEFOG DISPLAY FREEZE GAMMA 0.55 E.ZOOM [BACK] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ◈ HLC: Select High Light Compensation.
- Page 30 ORIOLE SERIES CAMERA ◈ DEFOG: Carry out defog function ► OFF / ON↲ ▷ MODE: AUTO / MANUAL ▷ LEVEL: LOW / MIDDLE / HIGH ※ Can’t use DEFOG and ACE at the same time (When ACE On, DEFOG is Off, and when DEFOG is On, ACE is Off) ◈...
- Page 31 ORIOLE SERIES CAMERA INTELLIGENCE MENU INTELLIGENCE ↲ MODEL D&N PRIVACY ↲ EXPOSURE MOTION ↲ WHITE BAL ↲ IMAGE ↲ INTELLIGENCE ↲ SPECIAL FUNC DISPLAY [BACK] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ◈ PRIVACY: Hide an area you want to hide on the screen ►...
- Page 32 ORIOLE SERIES CAMERA SPECIAL FUNC MENU SPECIAL FUNC ↲ ↲ MODEL D&N DEFECT ↲ EXPOSURE IMAGE RANGE FULL ↲ WHITE BAL SYSTEM NTSC INTELLIGENCE ↲ HD FORMAT 1080p/30fps IMAGE ↲ SPECIAL FUNC ↲ EX-SDI ↲ COMM DISPLAY [BACK] [SAVE] [DFLT]...
- Page 33 ORIOLE SERIES CAMERA DISPLAY MENU DISPLAY ↲ ↲ MODEL D&N DISP SEL ON↲ ↲ EXPOSURE SET TITLE ↲ ↲ WHITE BAL INIT SEL ON↲ ↲ IMAGE SET INIT MSG ↲ INTELLIGENCE LANGUAGE ENGLISH ↲ SPECIAL FUNC DISPLAY [BACK] [SAVE] [DFLT]...
-
Page 34: Camera Dimensions
This product is compliant with the RoHS3 requirements (Directive 2015/863/EU). RoHS3 REACH Please contact Active Silicon for the latest formal REACH declaration (EC 1907/2006). This product is designed to be compliant with the following requirements when housed in a suitable enclosure: ►... -
Page 35: Ordering Information
ORIOLE SERIES CAMERA ORDERING INFORMATION PART NUMBER DESCRIPTION AS-BCAM-S42-001-A Oriole 3G-SDI Board Camera (also EX-SDI, CVBS output), with switchable IR-cut filter and 3.6mm focal length M12 standard lens fitted; other lenses on request. AS-BCAM-S42-EVAL-A Evaluation kit Headquarters: North America: Active Silicon Ltd Active Silicon, Inc.
