HERO S11197 User Manual

User Manual
Hero Medical Shower Stool
S11197
SKU
Standard
Overall Width 60cm
Overall Depth 47cm
Seat Width 40cm
Width Between Arms 46cm
Seat Height 46-59cm
Armrest Height 22cm
Weight 3.4kg
Safe Work Load (SWL) 205kg
Independent Living Specialists
S13167
S11968
Padded
Padded
Extra Wide
60cm 66cm
47cm 46cm
35cm 50cm
46cm 53cm
46-59cm 46-59cm
22cm 21cm
4kg 4.2kg
205kg 205kg
1
Safety & Precautions
User Safety: It is recommended that the below safety checks are completed
prior to each use:
• All locking pins must be fully protruding.
• Adjusted to appropriate height for user.
• Legs are in a secure position with anti-slip rubber tips attached.
• Weight on chair does not exceed safe work load.
Weight Capacity: the maximum safety weight limit for the product is 205kg.
If the maximum safety weight limit is exceeded, this can increase the risk of
damage to the product and/or risk of serious injury to the user and others.
Instructions for Use
Product Assembly
1. Remove contents from packaging.
2. Attach all four legs by sliding leg component into main frame receiver
until the locking pin is secured and protruding at the appropriate height
for the user.
3. Ensure legs are stable and secure.
Adjusting the Height
1. Push locking pin in and slide internal leg up or down to the appropriate
height. Ensure all locking pins are fully protruding prior to use
2. Please note that one leg has additional holes, to assist with stabilising
product on uneven floors.
Independent Living Specialists
Hero Medical Shower Stool Manual
2
