Summary of Contents for Bosch WAX32M12
- Page 1 Translated from German to English - www.onlinedoctranslator.com Washing machine WAX32M12 [de] Instructions for use and assembly...
-
Page 2: Table Of Contents
Further information can be found in the digital instructions for use. Table of Contents 1 Security ........4 7 Display ........22 1.1 General information ....4 8 buttons ......... 24 1.2 Intended use ........4 9 Programs ......... 26 1.3 Restriction of the group of users ........ - Page 3 15 Basic settings ....34 16 Cleaning and care ....35 16.1 Cleaning the drum ....35 16.2 Cleaning the detergent drawer ........35 16.3 Cleaning the drain pump ..36 16.4 Cleaning the inlet opening in the rubber sleeve ... 38 17 Eliminating malfunctions ....
-
Page 4: Security
de safety 1 security Please note the following safety instructions. 1.1 General information ¡ Read this guide carefully. ¡ Keep the instructions and product information for later use or subsequent owner. ¡ Do not connect the device if it has been damaged in transit. 1.2 Intended use Use the device only: ¡... -
Page 5: Safe Installation
safety de 1.4 Secure installation When installing the device, follow the safety instructions. WARNING - Risk of Electric Shock! Improper installations are dangerous. ▶ Only connect and operate the device in accordance with the information on the nameplate. ▶ Only connect the device to an alternating current power supply via a properly installed, earthed socket. - Page 6 de safety WARNING - Risk of Fire! Using an extended power cord and unapproved adapter is dangerous. ▶ Do not use extension cables or multiple socket strips. ▶ If the power cord is too short, contact customer service. ▶ Use only adapters approved by the manufacturer. WARNING - Risk of Injury! The heavy weight of the device can lead to injuries when being lifted.
-
Page 7: Safe Use
safety de CAUTION - Risk of Injury! The device may vibrate or move during operation. ▶ Place the device on a clean, level and firm surface. ▶ Align the device with the device feet and a spirit level. There is a risk of tripping if the hoses and mains connection cables are improperly laid. - Page 8 de safety ▶ Never expose the device to extreme heat and moisture. ▶ Do not use steam cleaners, high pressure cleaners, hoses or showers to clean the device. WARNING - Risk of damage to health! Children can lock themselves in the device and endanger their lives.
-
Page 9: Safe Cleaning And Maintenance
safety de The device can tip over if you sit or lean on the open door. ▶ Do not sit or lean on the appliance door. ▶ Do not place any objects on the appliance door. Reaching into the rotating drum can injure your hands. ▶... - Page 10 de safety Penetrating moisture can cause an electric shock. ▶ Do not use steam cleaners, high pressure cleaners, hoses or showers to clean the device. WARNING - Risk of Injury! The use of non-original spare parts and accessories is dangerous. ▶...
-
Page 11: Avoid Property Damage
Avoid property damage de ▶ Make sure that the valve housing of Avoid property damage the water inlet hose is installed so that it does not come into contact with the environment and is not exposed to any external force. P lease heed these instructions in order to Make sure that the inside ▶... -
Page 12: Environmental Protection And Saving
de Environmental protection and saving Unsuitable cleaning agents can Use economical program settings. damage the surfaces of the device. a If you have entered the program Do not use harsh or abrasive ▶ Adjust the settings for a program, cleaning agents. the display shows the expected Do not use cleaning agents that ▶... -
Page 13: Energy Saving Mode
Set up and connect de Close the appliance door. The device has an automatic quantity control. 4.2 Scope of delivery a The automatic amount fits that The water consumption and the duration of the After unpacking, check all parts for program are optimally adapted to the type of transport damage and that the textile and the amount of load. -
Page 14: Remove The Transport Locks
de Set up and connect conditions WARNING Installation site Risk of injury! Kitchenette The device only The device can tip over when under through operated on a base. walking working ▶ set up the plate, Before putting the device into operation, it is essential to secure the feet of the device on a which are firmly base with the retaining tabs →... -
Page 15: Remove The Transport Struts
Set up and connect de Loosen and remove all screws of Insert the 4 cover caps. the 4 transport locks with an SW13 wrench. Press down the 4 cover caps. Pull the power cord out of the holder. 4.5 Remove the transport struts Remove the 4 sleeves. -
Page 16: Connecting The Device
de Set up and connect Remove the transport struts. 4.6 Connect the device Water inlet hose connect WARNING Risk of electric shock! The device contains live parts. Touching live parts is dangerous. Do not immerse the electric ▶ Aquastop valve in water. Loosen and remove the screws of Notice: Make sure that you connect the horizontal transport strut with a... -
Page 17: Aligning The Device
Set up and connect de CAUTION! 4.7 Align the device When pumping out, the water drainage To reduce noise and vibrations and to hose is under pressure and can become prevent the device from wandering, detached from the installed connection orientate the device correctly. -
Page 18: Connecting The Device Electrically
de Set up and connect Tighten the lock nuts hand-tight against the housing with an SW17 wrench. Hold the device base firmly and do not adjust the height. 4.8 Connect the device electrically Insert the plug of the power cord of the device into a socket near the device. -
Page 19: Getting To Know Each Other
To get to know de 5 Getting to know each other 5.1 Device Here you will find an overview of the components of your device. 5 6 7 Depending on the device type, details in the picture may differ, e.g. B. Color and shape. -
Page 20: Detergent Drawer
de To get to know 5.2 Detergent drawer Chamber II: ¡ Detergent for the main Laundry ¡ Softener ¡ Bleach ¡ Stain remover Chamber : ¡ softener ¡ Liquid starch ¡ Impregnating agent Chamber I: ¡ Detergent for pre-wash 1 2 3 ¡... -
Page 21: Before Using For The First Time
Before first use de a The display shows the remaining Before the first Program duration. a The display shows after program end: -0-. B. p repare the device for Start the first wash or press to 8th. switch off the appliance. application before. -
Page 22: Display
Display Display I. The display shows the current setting values, selection options or information texts. display designation More information 0:40 Estimated program duration or remaining Program duration / time of the program. Remaining time of the pro gram → "Keys ", page 24 Ready in - time 10.0 kg Loading temp... - Page 23 Display de display designation More information ¡ lights up: The child lock is active Parental controls fourth. ¡ flashes: the childproof lock is activated and the device was operated. → "Deactivating childproof lock ", page 34 The stain type is activated. blood The stain type is activated.
-
Page 24: Buttons
de Keys 8th Keys D. T he selection of the program settings depends on the set program. gram. You can see the options for each program in the overview for. selection More information button Start / reload ¡ start Start, cancel or pause the program. ¡... - Page 25 Keys de selection More information button prewash ¡ activate Activate or deactivate prewash, e.g. B. for washing heavily soiled laundry. ¡ deactivate Water plus ¡ activate Enable or disable washing with more water and an additional rinse. ¡ deactivate Recommended for particularly sensitive skin or in areas with very soft water.
-
Page 26: Programs
Programs 9 Programs Notice: The care labels on the laundry give you additional information on selecting a program. Care symbols on the care labels Max. program description Bela- manure (kg) 10.0 cotton Wash hard-wearing textiles made of cotton, linen and mixed fibers. Also suitable as a shortened program for normally soiled laundry if you activate SpeedPerfect. - Page 27 Programs de Max. program description Bela- manure (kg) ¡ max. 1600 rpm Fine silk Wash delicate, washable textiles made of silk, viscose and synthetic materials. Use a detergent made for delicates or silk. Notice: Wash particularly delicate textiles or textiles with hooks, eyes or hangers in the laundry net.
- Page 28 de Programs Max. program description Bela- manure (kg) Shirts / blouses Wash non-iron shirts and blouses made of cotton, linen, synthetic and mixed fabrics. Tip: To avoid creases in the laundry, activate Easy Iron. The laundry is only spun briefly and can be removed while dripping.
- Page 29 Programs de Max. program description Bela- manure (kg) Do not use fabric softener. Do not use wool, mild detergents or liquid detergents. Notice: If you have not used a program at 60 ° C or higher for a long time, the drum cleaning indicator flashes as a reminder.
-
Page 30: Accessories
- Close zippers, Velcro fasteners, scanning the QR code in the table of hooks and eyes contents or at www.bosch-home.com. - Tie fabric belts, apron strings or use a laundry bag 11.1 Prepare laundry... -
Page 31: Detergents And Care Products Tel
Hints Press. ▶ ¡ Extended notes on usage The switch-on process takes a few can be found at www.bosch- seconds. home.com or by scanning the QR code on the front page of these Notice: The drum lighting goes out operating instructions. -
Page 32: Inserting Laundry
de Basic operation Insert the dosing aid. 13.4 Loading laundry Notice: To avoid creasing, observe the maximum load of the → "Programs ", page 26 . Requirement: The laundry is prepared. → "Laundry ", page 30 Open the door. Make sure the drum is empty. Insert the detergent drawer. -
Page 33: Adding Detergent And Care Products
Basic operation de a The drum turns and it Fold down the dispensing aid and A load detection follows, which can click into place. take up to 2 minutes and then the water runs in. a The display shows either pro duration or the Ready in time is displayed. -
Page 34: Continuing The Program With Rinse Hold
Notice: You can find more information in the digital instructions for use by scanning the QR code in the table of contents or at www.bosch-home.com. Leave the appliance door and detergent drawer open so that Residual water can dry off. -
Page 35: Cleaning And Care
Notice: You can find more information in the digital instructions for use by scanning the QR code in the table of contents or at www.bosch-home.com. 16.1 Clean the drum Pull out the insert from the bottom CAUTION Risk of injury! -
Page 36: Cleaning The Drain Pump
de Cleaning and care Insert the insert and click into Open and remove the place. maintenance hatch. Clean the opening for the Slide a sufficiently large container detergent drawer. under the opening. Slide in the detergent drawer. Take the drainage hose out of the holder. - Page 37 Cleaning and care de Clean the drain pump CAUTION - Risk of scalding! The detergent solution becomes hot Requirement: The drain pump is empty. → Page 36 when washing at high temperatures. Since there may still be residual ▶ Do not touch the hot detergent water in the drain pump, carefully solution.
-
Page 38: Cleaning The Inlet Opening In The Rubber Sleeve
de Cleaning and care Make sure that both impellers can Insert and close the maintenance be turned. flap. Insert the pump cover. 16.4 Clean the inlet opening in Make sure that the components the rubber sleeve. of the pump cover are correctly installed. -
Page 39: Eliminating Malfunctions
Troubleshooting de 7 Eliminate malfunctions K You can rectify minor faults in your device yourself. Take advantage of the Troubleshooting information before contacting customer service. In this way you avoid unnecessary costs. WARNING Risk of electric shock! Improper repairs are dangerous. Only trained specialists are allowed to carry out repairs on the device. - Page 40 de Troubleshooting Cause and troubleshooting disturbance "E: 30 / -80" Remove impermissible extensions from the water ▶ drainage hose. Connect device Pump cover is not screwed in completely. Make sure that the pump cover is screwed into the ▶ device as far as it will go. The handle of the pump cover must be vertical.
- Page 41 Troubleshooting de Cause and troubleshooting disturbance shines. Temperature is too high. Wait until the temperature has dropped. ▶ → "Abort program ", page 33 ▶ The water level is too high. Select a suitable program for expressing. ▶ → "Programs ", page 26 Laundry is jammed in the door.
-
Page 42: The Drain Pump Is Blocked
de Troubleshooting Cause and troubleshooting disturbance Program starts Door is not closed. not. Close the door. To start the program, press Start / reload Child lock is activated. → "Deactivating childproof lock ", page 34 ▶ - Done in + is activated. Check if - Done in + is activated. - Page 43 Troubleshooting de Cause and troubleshooting disturbance Detergent does not work is activated. Continue the program by pressing fling or pumped out. ▶ Pumping out choose and Start / reload to press. → "Continuing the program at Rinse Hold ", page 34 The water drainage hose is connected too high.
- Page 44 de Troubleshooting Cause and troubleshooting disturbance The unbalance control system compensates for the unbalance Program duration change changes during the by distributing the laundry several times. washing process. No mistake - no action required. ▶ Notice: When loading, place large and small items of laundry together in the drum.
- Page 45 Troubleshooting de Cause and troubleshooting disturbance High spin speed Select suitable programs for the type of textile. ▶ number is not reached. The unbalance control system compensates for unbalance by reducing the spin speed. Redistribute the laundry in the drum. ▶...
- Page 46 de Troubleshooting Cause and troubleshooting disturbance Slurping, rhythmic The detergent solution pump is active, the detergent solution is nice sucking noise. pumped out. Not a fault - normal operating noise. ▶ Wrinkling. Spin speed is too high. Set a lower spin speed for the next wash cycle. ▶...
-
Page 47: Cleaning The Drum
Troubleshooting de Cause and troubleshooting disturbance Spin result is The unbalance control system compensates for unbalance not satisfied- by reducing the spin speed. lend. The laundry is Redistribute the laundry in the drum. ▶ too wet / too damp. Notice: Place large and small items of laundry together in the drum. -
Page 48: Emergency Release
18.1 Dismantling the device operation again Notice: You can find more information For more information see ▶ → on usage at www.bosch- "Installation and connection ", home.com or durc h the scanning page 13 and → the QR code a of these on the front page "Before using for the first time ",... -
Page 49: Disposing Of Old Devices
Customer service de 18.4 Dispose of the old device 9 Customer service Valuable raw materials can be W. I f you have any questions about the reused through environmentally application, you cannot rectify a fault friendly disposal. on the device yourself or the device needs to be repaired, please contact WARNING our customer service. -
Page 50: Aqua Stop Guarantee
de Customer service You can make a note of the data so that you can quickly find your device data and customer service telephone number. 19.2 AQUA-STOP guarantee In addition to warranty claims against the seller from the sales contract and in addition to our manufacturer's guarantee, we provide replacement under the following conditions. -
Page 51: Consumption Values
Consumption values de 0 consumption values T he following information is provided in accordance with the EU Ecodesign Regulation give. The values given for programs other thanEco 40-60 are only guide values and were determined on the basis of the applicable standard EN60456. Per- program Bela-... - Page 52 de Technical specifications (E no.) On the nameplate. Maximum load 10.0 kg Alternatively, you can find the model amount of manure identifier in the first line of the EU Mains voltage 220-240 V, energy label. 50-60 Hz 10 A Minimal in- installation-proof assurance 2300 W...
- Page 56 Contact data of all countries are listed in the attached service directory. Robert Bosch Hausgeräte GmbH Carl-Wery-Strasse 34 81739 Munich GERMANY www.bosch-home.com * 9001658167 * 9001658167 (010915)
