  • Page 1 IVN-8563 User Manual 2025-01-31...

  • Page 2: Table Of Contents

    IVN-8563 Multidrop Network Configuration ........

  • Page 3: Ivn-8563 User Manual

    IVN-8563 IVN-8563 User Manual User Manual The IVN-8563 User Manual provides detailed descriptions of the product functionality and the step-by-step processes for use. Looking For Something Else? For information not found in the User Manual for your product, such as specifications and API reference, browse Related Information .

  • Page 4: Ivn-8563 Overview

    • The IVN-8563 supports multidrop networks and custom PLCA settings for network communication. • The IVN-8563 supports firmware updates performed by the end-user. • When paired with a device such as the PXIe-8623, the IVN-8563 supports NI-XNET monitor path and endpoint path. ni.com...
  • Page 5 IVN-8563 Overview Note The IVN-8563 does not require driver support and is not directly supported by NI-XNET. Related information: • PXIe-8623 Features • PXIe-8623 Data Path Overview © National Instruments...

  • Page 6: Ivn-8563 Driver Support

    IVN-8563 Driver Support Driver Support The IVN-8563 does not require driver support and is not directly supported by NI-XNET. For NI-XNET monitor path and endpoint path support, pair the IVN-8563 with a device such as the PXIe-8623 Automotive Ethernet Interface Module.

  • Page 7: Components Of A Ivn-8563 System

    Components of a IVN-8563 IVN-8563 System System IVN-8563 is designed for use in a system that may require hardware, drivers, and software to optimize IVN-8563 for your application. Use the minimum required IVN-8563 system components as a starting point for building your system.
  • Page 8 The included USB type-A to USB type-C cable connects a suitable power source, such as a PC or an industrial controller, to the USB type-C power connector on the IVN-8563. A USB cable with a USB mini-B (miniUSB) connector is required for advanced device configuration.
  • Page 9 Components of a IVN-8563 System 1). The IVN-8563 kit includes a compatible plug. Attach the plug to a twisted-pair cable. © National Instruments...

  • Page 10: Ivn-8563 Theory Of Operation

    Industrial Ethernet MACPHY Controller. Weidmuller OMNIMATE SL-SMT 3.50/02/90LF terminal block headers are used to connect to these ports. Compatible plugs are included with the IVN-8563. The 10BASE-T1S port can be configured as coordinator or follower. The USB mini-B (miniUSB) connector allows you to access and modify the device configuration.

  • Page 11: Ivn-8563 Block Diagram

    IVN-8563 IVN-8563 Block Diagram Block Diagram The IVN-8563 provides a single channel to transform data between 10/100BASE-TX Ethernet and 10BASE-T1S automotive Ethernet. Use the IVN-8563 block diagram to visualize the data conversion channel. 10BASE-T1S is the standard for 10 Mbit/s automotive Ethernet. The physical connection consists of an unshielded twisted pair cable over which two connected nodes transmit and receive simultaneously in point-to-point half-duplex operation.

  • Page 12: Ivn-8563 Front Panel

    IVN-8563 Front Panel IVN-8563 IVN-8563 Front Panel Front Panel The IVN-8563 front panel includes a 2-pin terminal block connector, RJ45 Ethernet connector, USB connectors for power and configuration, a grounding screw, and LED status indicators. Figure 3. IVN-8563 Front Panel...

  • Page 13: Ivn-8563 Pinout

    IVN-8563 Pinout IVN-8563 Pinout IVN-8563 Pinout Refer to the following tables for descriptions of the terminal block (10BASE-T1S) and RJ45 (10/100BASE-TX) pin assignments. Table 4. 10BASE-T1S Terminal Block Pin Assignments Connector Signal 10BASE-T1S Positive (+) 10BASE-T1S Negative (-) Table 5. 10/100BASE-TX RJ45 Pin Assignments...

  • Page 14: Ivn-8563 Leds

    IVN-8563 LEDs IVN-8563 LEDs IVN-8563 LEDs LEDs on the left side of the front panel indicate Link and Activity on the 10BASE-T1S automotive Ethernet port. LEDs on the RJ45 connectors indicate Link, Activity, and 100 Mbit speed on the 10/100BASE-TX Ethernet port.

  • Page 15: Preparing The Environment

    Preparing the Environment Preparing the Environment Preparing the Environment Ensure that the environment in which you are using the IVN-8563 meets the following specifications. Ambient temperature 0 °C to 55 °C (Tested in accordance with IEC 60068-2-1 and IEC range 60068-2-2.)

  • Page 16: Unpacking The Kit

    Never touch the exposed pins of connectors. Note Do not install a device if it appears damaged in any way. 3. Unpack any other items and documentation from the kit. Note Store the device in the antistatic package when the device is not in use. ni.com...

  • Page 17: Verifying The Kit Contents

    Verifying the Kit Contents Verifying the Kit Contents Verify that the following components are in your kit. • IVN-8563, 10BASE-T1S Media Converter • USB cable assembly, Type-C (male) to USB 3.1 Type-A (male), 1 m • Connector plug • Screwdriver, 2 mm, flathead •...

  • Page 18: Safety Guidelines

    Des tensions supérieures à celles mentionnées dans les spécifications peuvent endommager le produit ou provoquer un choc électrique. Rated Voltages Port 1 30 VDC, maximum Current Rating Port 1 92 mA, maximum ni.com...
  • Page 19 Safety Guidelines Note For safety certifications, refer to the product label or the Product Certifications and Declarations section. © National Instruments...

  • Page 20: Din Rail Mounting

    The NI 9913 DIN rail mounting kit (part number 781740-01) contains one clip for mounting the IVN-8563 on a standard 35 mm DIN rail. The four holes on the bottom of the IVN-8563 allow for mounting the device in multiple orientations.

  • Page 21: Connecting The Ivn-8563

    3. Use the included USB cable to supply power. Connect the USB type-C connector to the IVN-8563 and connect the type-A connector to a USB type-A port on your PC or controller. 4. Optionally, attach a grounding cable to the ground screw on the IVN-8563.

  • Page 22: Ivn-8563 Multidrop Network Configuration

    1. Connect the USB type-C cable connector to supply power to the IVN-8563. 2. Connect a USB cable from a PC to the CONFIG port of the IVN-8563. The CONFIG port requires a USB cable with a USB mini-B (miniUSB) connector. The IVN-8563 appears as a mass-storage device on the connected PC.
  • Page 23 7. Once all file transfers are complete, disconnect the IVN-8563 from the PC. 8. Disconnect the USB type-C connector connector to remove power to the IVN-8563. 9. Connect the USB type-C connector to supply power to the IVN-8563. The IVN-8563 powers on and uses the modified configuration.
  • Page 24 IVN-8563 Multidrop Network Configuration JSON Field Name Valid Values Description a new packet before moving to the next node. A group of name-value pairs termination_configuration JSON object to configure the automotive ethernet port termination. Enables or disables termination for the automotive ethernet port.

  • Page 25: Updating Ivn-8563 Firmware

    2. Disconnect the USB type-C cable connector to remove power from the IVN-8563. 3. Remove the rear panel of the IVN-8563 by unscrewing the fasteners on each side of the panel.
  • Page 26 Updating IVN-8563 Firmware ◦ The LINK LED glows steady red approximately 20 seconds after the IVN-8563 powers on. 6. Wait for the firmware update to finish. Once the update process completes, the IVN-8563 shuts down and all LED indicators turn off.
