SECO-LARM ENFORCER SL-1301-EAQ Manual

ENFORCER LED Strobe Lights
Configuring Flash Pattern
(SL-1301-BAQ/SL-1301-SAQ series only)
IMPORTANT: Before changing flash pattern, disconnect power. Change flash pattern before
reconnecting power.
Visit www.seco-larm.com for animated flash pattern samples.
DIP Switch Description of
Position Flash Pattern
1
LEDs flash on and off continuously. (Default setting)
Rotate Clockwise
2
Light rotates clockwise in a circular fashion continuously.
3
All LEDs stay on. Ideal for continuous lighting applications.
Flash with Progressive ON
4
LEDs turn on progressively clockwise until all LEDs are lit
(sweep), and then turn off.
Rotate Back and Forth
5
LED groups light up one at a time, rotating clockwise and
counterclockwise.
Flash with Progressive ON/OFF
6
LEDs turn on progressively clockwise (sweep), then turn off
progressively counterclockwise.
Also Available from SECO
SECO SECO- - - - LAR SECO LARM M M M LAR LAR
Replacement Mounting Options
Lenses
Conduit Drop
SL-126LQ/X
SL-1901-DAQ
(Replace 'X' with the first
letter of the desired color)
Application Photos
Conduit Drop
Available in Red, Blue,
Amber, Clear, or Green
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right to
change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2015 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or
in part, without the written permission of SECO-LARM.
®
U.S.A., Inc.
SECO-LARM
16842 Millikan Avenue, Irvine, CA 92606
Phone: (949) 261-2999 | (800) 662-0800
4
:
(SL-1301-BAQ Shown)
Strobe
(Beacon)
Steady ON
® :
Conduit Box
SL-126Q Series
SL-1901-JAQ
Conduit Box Both
Available in Red, Blue,
Amber, Clear, or Green
Website: www.seco-larm.com
Email: sales@seco-larm.com
MiSL-1301-xAQ_150123.docx
SECO-LARM U.S.A., Inc.
Top View
Color
Xeon Tube
Strobe Lights
All Models:
• Operating life of over 50,000 hours
(over 5.7 years)
• Same size as the SL-126Q strobe light
• Simple 2-wire installation
• 5 lens colors available for each model
• Weather resistant
• High-impact resistant case
• High-impact and heat-resistant lens
• Reverse polarity protection
• Visible in all directions
®
PITSW1
Order Part# 762-509-4%
LED Strobe Lights
Manual
LEDs
Bright Brighter
Red SL-1301-EAQ/R SL-1301-BAQ/R
Blue SL-1301-EAQ/B SL-1301-BAQ/B
Amber SL-1301-EAQ/A SL-1301-BAQ/A
Clear SL-1301-EAQ/C SL-1301-BAQ/C
Green SL-1301-EAQ/G SL-1301-BAQ/G
*Includes a built-in 100dB siren
BAQ and SAQ series also include:
• 6 different flashing options
• Adjustable flashing speed
• Backup battery available for continuous
lighting applications
• Vertical LED strips increase visibility from
various directions
SAQ series also includes:
• Built-in 100dB siren (programmable)
(SL-1301-SAQ shown)
Brightest
SL-1301-SAQ/R*
SL-1301-SAQ/B*
SL-1301-SAQ/A*
SL-1301-SAQ/C*
SL-1301-SAQ/G*
