Summary of Contents for Sheriff 04.3119
- Page 1 INSTALLATION MANUAL SKID PLATE FOR ENGINE BAY and TRANSMISSION CASE ENGINEUNDERSHIELD 2016 - MINI Clubman (F54) (1,5 АТ) 2016 - MINI Countryman (F60) (1.5, 2,0 AT FullWD) 6142 15/04/24...
- Page 2 ocation PositionArrow MovementArrow Screw Arrow 6142 15/04/24...
- Page 3 M8х12 M10х30 M10х40 M5х16 6142 15/04/24...
- Page 4 Regular fasteners 6142 15/04/24...
- Page 5 M8 = 24 Nm vid 4 vid 5 6142 15/04/24...
- Page 6 А M8 = 24 Nm M5 = 6.3 Nm M10 = 47 Nm 6142 15/04/24...
- Page 7 INSTALLATION: Engine bay and transmission elements skid plate has been designed particularly for a certain vehicle. It should be mounted according to the producer's installation instruction by a dedicated dealer or on certified service stations. The skid plate is fixed to regular apertures located on vehicle's body load-bearing elements. In case of correct installation the skid plate should not interfere with any vehicle's units and components.
